T2 SERIES POWER RACKS
T2RACK71, T2RACK83
401079, 401080
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!

Advertisement

loading
Need help?

Need help?

Do you have a question about the T2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan Fitness T2 Series

  • Page 1 T2 SERIES POWER RACKS T2RACK71, T2RACK83 401079, 401080 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
  • Page 2 T2RACK71 PARTS DIAGRAM / EXPLODED VIEW...
  • Page 3 T2RACK83 PARTS DIAGRAM / EXPLODED VIEW...
  • Page 4 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION BASE FRAME REAR BASE FRAME UPRIGHT FRAME UPPER CONNECTING FRAME CONNECTING FRAME PULL UP BAR J-HOOK (L) J-HOOK (R) SAFETY BAR (10) OUTER PROTECTIVE PIPE (11) LONG PLASTIC PLATE (12) SHORT PLASTIC PLATE 58*48*5 (13) FRONT PLASTIC PLATE 48*40*5 (14)
  • Page 5 ASSEMBLY INSTRUCTIONS STEP 1 Connect the BASE FRAME (1) and REAR BASE FRAME (2), using FLAT WASHER Φ13.5*Φ24*2.5 (17), M12 NUT (18) and HEX BOLT M12*80 (20). STEP 2 Connect the BASE FRAME (1) and UPRIGHT FRAME (3), USING FLAT WASHER Φ13.5*Φ24*2.5(17), M12 NUT (18) and CARRIAGE BOLT M12*70 (21).
  • Page 6 ASSEMBLY INSTRUCTIONS STEP 3 Connect the UPPER CONNECTING FRAME (4) and UPRIGHT FRAME (3), using FLAT WASHER Φ13.5*Φ24*2.5 (17), M12 NUT (18), HEX BOLT M12*75 (19) and HEX BOLT M12*80 (20).
  • Page 7 ASSEMBLY INSTRUCTIONS STEP 4 1. Connect the CONNECTING FRAME (5) and UPRIGHT FRAME (3), using FLAT WASHER Φ13.5*Φ24*2.5 (17), M12 NUT (18), and HEX BOLT M12*75 (19). 2. Install the PULL UP BAR (6) on the UPRIGHT FRAME (3), using FLAT WASHER Φ13.5*Φ24*2.5(17), M12 NUT (18), and HEX BOLT M12*75(19).
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 5 1. Insert the SAFETY BAR (9) into the hole on the UPRIGHT FRAME (3). 2. Hang the J-HOOK L & R (7 & 8) on the UPRIGHT FRAME (3).
  • Page 9: Pay Attention

    ASSEMBLY INSTRUCTIONS PAY ATTENTION: The uprights of the extension uprights have a round opening on the bottom plate to slide the uprights over the weight holders for easy installation and reduce the amount of disassembly need to upgrade to the extension.
  • Page 10 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
  • Page 11 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2021 Titan Brands...
