T2 SERIES POWER RACK EXTENSIONS
T2EXT71, T2EXT83
401209, 401210
Operator's Manual
Read the Operator's Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!
Advertisement
Related Manuals for Titan Fitness T2 Series
Summary of Contents for Titan Fitness T2 Series
- Page 1 T2 SERIES POWER RACK EXTENSIONS T2EXT71, T2EXT83 401209, 401210 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
-
Page 2: Description Qty
T2EXT71 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION DESCRIPTION UPRIGHT FRAME Φ48 END CAP EXTENDED END CAP Φ50*2 CONNECTING FRAME WEIGHT PLATE FLAT WASHER HOLDER (L) Φ13.5*Φ24*2.5 WEIGHT PLATE M12 NUT HOLDER (R) CONNECTING FRAME (10) HEX BOLT M12*75... - Page 3 T2EXT83 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION DESCRIPTION UPRIGHT FRAME Φ48 END CAP EXTENDED END CAP Φ50*2 CONNECTING FRAME WEIGHT PLATE FLAT WASHER HOLDER (L) Φ13.5*Φ24*2.5 WEIGHT PLATE M12 NUT HOLDER (R) CONNECTING FRAME (10) HEX BOLT M12*75...
- Page 4 ASSEMBLY INSTRUCTIONS STEP 1 1. Install the CONNECTING FRAME (5) ON THE UPRIGHT FRAME (1), using FLAT WASHER Φ13.5*Φ24*2.5(8), M12 NUT (9) and HEX BOLT M12*75(10). 2. Connect EXTENDED CONNECTING FRAME (2) and UPRIGHT FRAME (1), using FLAT WASHER Φ13.5*Φ24*2.5(8), M12 NUT (9) and HEX BOLT M12*75(10).
-
Page 5: Upright Frame
ASSEMBLY INSTRUCTIONS STEP 2 Insert the WEIGHT PLATE HOLDER L&R (3 & 4) into the hole on the UPRIGHT FRAME (1). - Page 6 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...
- Page 7 NEED HELP? CONTACT US FIRST. 1-888-410-1503 info@titan.fitness www.titan.fitness © 2021 Titan Brands...
