Titan Fitness DBRACK 3 Operator's Manual

3 tier dumbbell weight rack

3 TIER DUMBBELL WEIGHT RACK

DBRACK_3

400192

Operator's Manual

Read the Operator's Manual entirely. When you see this

symbol, the subsequent instructions and warnings are

serious follow without exception. Your life and the lives

of others depend on it!

Table of Contents

Need help?

Do you have a question about the DBRACK 3 and is the answer not in the manual?

Page 1 3 TIER DUMBBELL WEIGHT RACK DBRACK_3 400192 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
Page 2 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION LEFT STAND FRAME RIGHT STAND FRAME PLATE M10X20 HEX BOLT M10 WASHER M10 HEX NUT...
Page 3 ASSEMBLY INSTRUCTIONS 1. ATTACH THE PLATES (3) TO THE LEFT STAND FRAME (1): Attach the Plate (3) to the Left Stand Frame (1) using M10x20 Hex Bolt (4), M10 Washer (5), and M10 Hex Nut (6). The order for assembly is M10x20 Hex Bolt (4), then M10 Washer (5), then put the bolt through the Plate (3) and Left Stand Frame (1), and finally attaching the M10 Washer (5) and M10 Hex Nut (6) on the back.
Page 4 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non-economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims, demands, damages,...

400192
