Summary of Contents for PowerWalker BPH P36R-6
- Page 1 PowerWalker How to assemble a BPH P36R-6...
- Page 2 Important Safety Warnings Please comply with all warnings and operating instructions in this instruction strictly. Read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. • Do not try to assemble or repair the unit yourself, contact your local supplier, seek for a qualified technician for professional assistance.
- Page 3 The following precaution should be observed when working on batteries: 1. Remove watches, rings, or other metal objects. 2. Use tools with insulated handles. 3. Wear rubber gloves and boots. 4. Do not lay tools or metal parts on top of batteries. 5.
- Page 4 SOP – How to assemble BPH P36R-6 Please assemble 6 batteries into the BP housing. Remark: 3x Fuse 15A 250V 6x Battery 12V 7-9 Ah...
- Page 5 Please connect the 6 batteries with the wires as shown below • Connect BAT1 (+) and BAT6 (-) with the black wiring. • Connect BAT6 (+) and BAT5 (-) with the black wiring. • Connect BAT2 (+) and BAT3 (-) with the black wiring. •...
- Page 6 • Connect BAT5 (+) and FUSE with the black wiring. • Connect BAT4 (+) and FUSE with the black wiring. • Connect BAT1 (-), BAT2 (-) and Output with the long black wiring. Remark: 3x Fuse 15A 250V...
- Page 7 Please fix the batteries and lay them down as shown below Anderson connector: 600V/ 45A...
