Crestron CSA-DECOR3-BRKT-163-EC-MTL Quick Start Manual

CSA-DECOR3-BRKT-163-EC-MTL
Crestron Shades with Brushed Metal Brackets, Motorized Operation
Getting Started
Scan the QR code to get started.
Certification and Compliance
These CSM-QMTDC shade motors are designed to operate with the
CSA-DECOR3-BRKT-163-EC-MTL:
CSM-QMTDC-163-Y-EX-BLK
l
CSM-QMTDC-163-Y-CN-BLK
l
For proper installation, operation, and maintenance of these
products, refer to the Crestron manual at
www.crestron.com/docs/9254.
Observe the following:
This appliance is not intended for use by persons (including
l
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with
l
the appliance.
Use Crestron power supplies only.
l
The shade motor must only be supplied safety extra low voltage
l
(SELV) corresponding to the marking on the appliance.
When performing service or replacing parts, be sure to disconnect
l
the shade motor from its power source by removing the power
plug. Label the plug location with a note indicating its location
must be clearly visible while performing service.
Do not allow children to play with fixed controls. Keep remote
l
controls away from children.
Examine the installation frequently for imbalance and signs of
l
wear or damage to cables, springs and fixings. Do not use if repair
or adjustment is necessary.
Do not operate when maintenance, such as window cleaning, is
l
being carried out in the vicinity.
Disconnect the drive from the supply, or switch off the automatic
l
controls when maintenance, such as window cleaning, is being
carried out in the vicinity.
Do not use an extension cord. If the power supply cord is too short,
l
have a qualified electrician install an outlet near the drapery
operator.
The A-weighted emission sound pressure level of the drive is less
l
than 70 db(A).
WARNING: Important safety instructions. Follow all instructions
since incorrect installation can lead to severe injury.
The device should be installed using compatible mechanical parts
l
that are needed to couple the drive to the driven part.
NOTE: Mechanical parts are selected using the Crestron CDT
application. A list of parts are also available on the Crestron
website at www.crestron.com.
Before installing the drive, remove any unnecessary cords or
l
components and disable any equipment not needed for powered
operation.
Install the actuating member of any manual release at a height
l
less than 5.91 ft (1.8 m).
The motor is intended to be installed at a height of at least 8.2 ft
l
(2.5 m) above floor level or other access level.
For motors supplied without a driven part:
The motor must be used with compatible parts at the rated load
l
and operating time.
The motor must be used with the correct diameter roller tube or
l
the correct drapery track.
Follow installation instructions supplied with the mounting
l
brackets, motor, roller tube, and drapery track.
The following symbols are used on the product:
Direct Current:
l
Class III Appliance:
l
For All Motor Models:
This product is Listed to applicable UL® Standards and requirements
tested by Underwriters Laboratories Inc.
Ce produit est homologué selon les normes et les exigences UL
applicables par Underwriters Laboratories Inc.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is
subject to the following conditions:
(1) This device may not cause harmful interference and (2) this device
must accept any interference received, including interference that
may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user's
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
l
Increase the separation between the equipment and receiver.
l
Connect the equipment into an outlet on a circuit different from
l
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
l
For CSM-QMTDC-163-Y-EX-BLK Motors:
Industry Canada (IC) Compliance Statement
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce
potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated
power (e.i.r.p.) is not more than that necessary for successful
communication.
Industrie Canada (IC) Déclaration de conformité
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement. Conformément à
la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou
inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le
but de réduire les risques de brouillage radioélectrique à l'intention
des autres utilisateurs, il faut choisir le type d'antenne et son gain de
sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne
dépasse pas l'intensité nécessaire à l'établissement d'une
communication satisfaisante.
