TCL LinkZone User Manual page 5

5. SMS LED
6. Micro USB port
7. Power button
8. Reset button
9. Micro SIM card
slot
10. Micro SD card
slot
Power saving mode
If you do not use the router buttons for three minutes, all LEDs will automatically turn off.
• Blinking blue: there is an unread message.
NOTE Log in to the web UI (see the IP address on the label inside
the router), and locate the SMS tab to read the message.
• OFF: there is no unread message, or the router is in the power saving
mode.
Used to connect to a power supply (5 V/1 A) through the provided USB
cable.
• Press for 3 seconds to power on or off your router.
• Press to recover from the power saving mode.
Use a paperclip to press the button for 3 seconds to reset the router to
default factory settings, including the Wi-Fi name and password.
Insert a micro SIM card in the slot.
Insert a micro SD card in the slot. The router works with micro SD
cards with a maximum capacity of 32 GB.
2
