BRITAX RÖMER DUALFIX M i-SIZE User Manual page 9

2. Place the child seat on the selected car seat.
3. Fold the support leg 1 completely away from the child
seat.
4.1.4 Adjust shock bar
1 Adjustment button
1. Keep the adjustment handle 1 depressed.
2. Pull the shock bar 2 up and away.
P The shock bar 2 can now be adjusted.
3. Adjust the shock bar 2 to the backrest of the car seat.
4. Release the adjustment handle 1.
P The shock bar 2 audibly locks in place.
5. Check that the shock bar 2 is securely locked in place
by pulling at it.
IP10002 | 1.4 | 2000037036
2 Shock bar
DUALFIX M i-SIZE | BRITAX RÖMER
Autogoods "130"
4.1.5 Fastening the ISOFIX
1 Grey fabric loop
2 ISOFIX locking arms
3 Red release button
1. Extend the ISOFIX locking arms 2 by pulling on the
grey fabric loop 1.
P The ISOFIX locking arms 2 are fully extended.
Before you connect the ISOFIX locking arms of the
child seat to the ISOFIX installation brackets of the
car seat, you must make sure that they are opened
and ready to use. The ISOFIX locking arms are
open if the green indicator on the side is not visi-
ble.
To open the ISOFIX locking arms 2, press
u
the grey fastening button 5 and the red
red release button 3 together.
2. Connect the ISOFIX locking arms 2 to the ISOFIX in-
stallation bracket on the car seat.
P Both ISOFIX locking arms 2 audibly lock in place.
P The green indicator 4 is visible on both
ISOFIX locking arms 2.
WARNING Risk of injury from unsecured child seat.
Make sure that both ISOFIX locking arms are fully
locked in place. Both green indicators must be visible.
3. Forcefully push the child seat as far back as possible.
4 Grey fastening button
5 Green indicator
