6

Cleaning and maintenance

6.1

Cover

6.1.1 Remove cover from the headrest
1 headrest
2 Rubber loops
3 Harness buckle
4 Adjustment button
1. To loosen the belt, press the adjustment button 4 and
pull both shoulder straps 6 forwards at the same time.
The shoulder pads are not connected to the shoul-
der straps. If you pull on the shoulder pads, the
belt is not loosened. Only pull on the shoulder
straps.
2. Open the harness buckle 3 by pressing the red button.
3. Adjust the head rest 1 to the highest position (see "Ad-
just headrest", page 5).
4. Loosen the rubber loops 2 on the bottom edge of the
headrest.
5. Remove the hooks 7 at the top edge of the headrest.
6. Remove the cover.
IP10002 | 1.4 | 2000037036
5 Shoulder pads
6 Shoulder strap
7 Hooks
DUALFIX M i-SIZE | BRITAX RÖMER
Autogoods "130"
6.1.2 Remove cover from the seat
1 headrest
2 Pushbuttons
3 Velcro
1. Adjust the seat to the flattest position (see "Adjusting
the seat angle", page 5).
2. Adjust the headrest 1 to the lowest position (see "Ad-
just headrest", page 5).
3. Open the pushbuttons 2 left and right of the rear of the
cover.
4. Undo the Velcro 3 on the padded crotch.
5. In the leg area, remove the rubber loops 4 and the
plastic cards 5.
6. Remove the elastic seam of the cover from the edge of
the seat.
7. Thread the shoulder straps through the cutout.
8. Pull the cover from the child seat from bottom to top.
4 Rubber loops
5 Plastic cards
13
