Floodlight Range Installation Guide
This installation guide provides instructions for installing the Infra-Red and
White-Light WARRIOR series of industrial floodlights.
Text in Bold is specific for emergency variants
Overview
Important information
The WARRIOR series of industrial floodlights are specialist devices, for use in
industrial operating environments.
The units must be installed in accordance with these instructions and must be installed
by suitably qualified personnel.
Emergency floodlights will require the fuse to be reconnected upon
installation and the floodlight subjected to three 24 hour charge/discharge
cycles to bring the battery up to peak capacity.
If you have any queries about the installation or the certification of the unit – please
contact Raytec for immediate assistance and advice.
1
Safety Instructions
2
Installation
3
Maintenance
4
Technical Specification
5
Trouble Shooting
Advertisement
Table of Contents
Related Manuals for Raytec WARRIOR 24
Summary of Contents for Raytec WARRIOR 24
- Page 1 24 hour charge/discharge cycles to bring the battery up to peak capacity. If you have any queries about the installation or the certification of the unit – please contact Raytec for immediate assistance and advice.
-
Page 2: Safety Instructions
Check the certification to ensure that the, mains supply and the ambient temperature present is suitable for the unit being installed. If the WARRIOR unit is to be installed in areas of high vibration, please consult with Raytec. Externally the WARRIOR unit housing is constructed from marine grade aluminium, and toughened glass, stainless steel brackets/fasteners and silicone gaskets, internally there are many non metallic components. -
Page 3: Installation
Mounting WARRIOR Unit 1. To meet the requirements of certification a MINIMUM of 2 fixing points must be used, the fixing points must be suitable for the conditions of use. Raytec recommend using M8 Marine Grade A4 Stainless Steel fixings (not supplied) - Page 4 The unit must be aligned first before securing the bracket, and bolts tightened to 15Nm. On WARRIOR 24 and 48 units a locking screw is provided to lock the luminaire at various angles, which should be tightened to 4Nm.
- Page 5 Typical wiring diagram – standard luminaires Typical wiring diagram – emergency luminaires UK / Europe Tel: +44 (0) 1670 520055 www.raytecled.com Americas Tel: +1 613 270 9990...
- Page 6 3. Open the rear compartment to access terminal block. Wire the Mains cable into the terminal block. Provision has been made for this and identified as the E (Earth), L1 (switched live) and L2 (permanent live) and N (Neutral) terminals. There are two pairs of contacts for each of these to facilitate a mains cable that can be looped in and out of the unit.
-
Page 7: Maintenance
3. Maintenance 1. It is essential that all WARRIOR units are maintained in accordance with local standards. 2. IMPORTANT. No modifications are permitted to the unit, all spare parts must be purchased from the manufacturer, unauthorized modifications or spare parts will invalidate certification and make the equipment dangerous. -
Page 8: Technical Specification
4. Technical Specification WARRIOR 24 WARRIOR 48 Input Voltage 110-254V AC or 18-48V AC/18-69V DC or 12V DC Consumption 68W max 136W max Consumption 139W max 71W max (Emergency variant) Power Factor >0.95 Mains Frequency 50/60Hz Inrush Current (Ipeak @ 50%) 40A ∆t <... -
Page 9: Troubleshooting
5. Trouble Shooting 1. Ensure the two LED boards are correctly wired to terminal block. White to White : White/Red to White/Red 2. Ensure Mains input is correctly connected. 3. Ensure Mains Input is turned on at the source 4. On emergency variants check fuse to ensure it has not blown 5. - Page 10 Raytec Global (excluding Americas) Raytec Americas Tel: +44 (0) 1670 520055 Tel: +1 613 270 9990 sales@raytecled.com sales@raytecled.com Raytec Ltd. Raytec Systems Inc. Unit 15 Wansbeck Business Park, Rotary Parkway 800-300 Terry Fox Drive, Ottawa, Ontario Ashington, Northumberland, NE63 8QW, United Kingdom 2K 0E3, Canada raytecled.com...
