INSTRUCTION MANUAL
UPHOLSTERED KING
Model No:
HEADBOARD
DA6402BG-K (Beige)
UPC CODE:
0-65857-16346-9
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS
IMPORTANT
SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer
service department. We will replace the part FREE of
charge.
Tel #: 1-800-295-1980
E-Mail: das@dorel.com
Fax #: 514-353-7819
Advertisement
Table of Contents
Related Manuals for Dorel Signature DA6402BG-K
Summary of Contents for Dorel Signature DA6402BG-K
- Page 1 _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE. If a part is missing or damaged, contact our customer service department. We will replace the part FREE of charge. Tel #: 1-800-295-1980 E-Mail: das@dorel.com Fax #: 514-353-7819...
-
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase. -
Page 3: Hardware List
UPHOLSTERED KING HEADBOARD DA6402BG-K HARDWARE LIST Ø5/16" X 50mm Ø22 X 1.8mm Ø12.5 X 1.2mm HEX SOCKET HEAD BOLT FLAT WASHER SPRING WASHER 8 PCS 16 PCS 12 PCS Ø1/4" X 90mm Ø16 X 1.8mm Ø10.5 X 1.2mm HEX SOCKET HEAD BOLT FLAT WASHER SPRING WASHER 2 PCS... -
Page 4: Parts List
UPHOLSTERED KING HEADBOARD DA6402BG-K PARTS LIST HEADBOARD LEFT LEG 1 PC 1 PC RIGHT LEG STRETCHER 1 PC 1 PC NOTE: LEGS (B & C) AND STRETCHER (D) ARE PACKED INSIDE THE HEADBOARD (A). PULL BACK THE FABRIC LINING BEHIND THE HEADBOARD TO COLLECT ALL PARTS. - Page 5 UPHOLSTERED KING HEADBOARD DA6402BG-K STEP 1: Place all parts on a clean, smooth surface. Attach the stretcher (D) to the left leg (B) and right leg (C) with flat washers (5), spring washers (6) and hex socket head bolts (4). Use Allen Key (9) to tighten the bolts. Note: Do not over tighten the bolts.
- Page 6 UPHOLSTERED KING HEADBOARD DA6402BG-K STEP 2: Pull back the fabric lining on the back of the headboard (A). Attach the assembled legs to the headboard (A) using flat washers (2), spring washers (3) and hex socket head bolts (1). Use Allen Key (10) to tighten the bolts. Place the fabric lining back into place.
- Page 7 UPHOLSTERED KING HEADBOARD DA6402BG-K NOTE: THE BED FRAME IS NOT INCLUDED AND MUST BE PURCHASED SEPARATELY. THE FOLLOWING ILLUSTRATIONS ARE FOR REFERENCE ONLY. Attach the bed frame (purchased separately) to bed posts using bolts (7), spring washers (3), flat washers (2) and nuts (8). Use Allen Key (10) to tighten bolts and use the open end wrench (11) to tighten the nuts (8).
- Page 8 That's it! You've finished assembling your headboard. DO NOT RETURN PRODUCT TO THE STORE. If a part is missing or damaged, contact our customer service department. We will replace the part FREE of charge. Tel #: 1-800-295-1980 E-Mail: das@dorel.com Fax #: 514-353-7819...
- Page 9 PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name: Shipping Address: Street &...
