DESK
Thank you for purchasing the DESK！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
2.Owing to the size and weight of the desk, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 45 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or the instruction until you have checked all the components and
hardware and the furniture is fully assembled. Please ensure that the packaging is disposed of in a safe and
environmentally friendly way.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all fitting out of reach of children.
Components:
1
Desk Top
x1
4
Leg
Ⅱ
x2
6
5
4
3
5
Hardware:
A
B
C
D
E
F
G
1
2
6
3
2
Rail
x2
End Panel
x2
Long Bolt M6x75mm
Medium Bolt M6x65mm
Medium Bolt M6x55mm
Short Bolt M6x20mm
Spring Washer M6
Flat Washer M6
Allen Wrench M4
5
4
3
Ⅰ
Leg
6
Metal Support Rail
x4
x2
x4
x1
x11
x11
x1
x2
x2
Page 1 of 4
Advertisement
Related Manuals for modway EEI-2784
Summary of Contents for modway EEI-2784
- Page 1 DESK Thank you for purchasing the DESK！ Before you start, here is some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions. 2.Owing to the size and weight of the desk, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
- Page 2 DESK STEP 1: Put Desk Top (1) upside down on a carpeted or padded surface. Place 2 pieces of Rail (2) to Desk Top (1) as shown. Insert 4 pieces of Long Bolt (A) with 4 pieces of Spring Washer (E) and 4 pieces of Flat Washer (F) into the pre-drilled holes on Desk Top (1) through the pre-drilled holes on Rails (2).
- Page 3 DESK STEP 3: Place the remaining 1 piece of Leg I (3), 1 piece of Leg II (4) , and End Panels (5) to the assembled Desk Top (1) , Rails (2), Leg I (3), and Leg II (4) as shown. Insert 2 pieces of Medium Bolt (C) with 2 pieces of Spring Washer (E) and 2 pieces of Flat Washer (F) into the pre-drilled holes on the end of Rail (2) through the pre-drilled holes on End panels (5).
- Page 4 DESK STEP 5: Carefully turn over the assembled desk. Assembly is complete. Your desk is ready to be used now! Page 4 of 4...
