Page 1 G&D Target and User Modules Installation and Operation DP-HR variants A9200140-1.30...
Page 2 © Guntermann & Drunck GmbH 2022. All rights reserved. Version 1.30 – 29/09/2022 Guntermann & Drunck GmbH Obere Leimbach 9 57074 Siegen Germany Phone +49 271 23872-0 +49 271 23872-120 www.gdsys.com sales@gdsys.com i · Target and user modules (DP-HR)
Page 3  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. Target and user modules (DP-HR) · ii...
Page 4: Table Of Contents
User module »DP-HR-CON-2-Fiber« ............113 User module »DP-HR-CON-Fiber-MC2« ............. 121 User module »DP-HR-CON-Fiber-MC4« ............. 129 User module »DP-HR-CON-DH« ..............139 User module »DP-HR-CON-2-DH« .............. 146 User module »DP-HR-CON-Fiber-DH« ............154 User module »DP-HR-CON-2-Fiber-DH« ............ 162 iii · Target and user modules (DP-HR)
Page 5 Enabling/disabling the user module’s Generic HID mode ......170 Enabling/disabling the target module’s Generic HID mode ......171 Chapter D: Extender mode Opening the on-screen display in extender mode ........... 173 Configuration ....................174 Target and user modules (DP-HR) · iv...
Page 6: Safety Instructions
When installing the devices, ensure that the devices’ mains plugs remain accessible at all time. Do not cover the ventilation openings For device variants with ventilation openings, it must always be ensured that the ventilation openings are not covered. 1 · Target and user modules (DP-HR)
Page 7 Failure to observe this precautionary measure can result in injuries and damage to the device. Operate the device exclusively in the intended field of application The devices are designed for indoor use. Avoid extreme cold, heat or humidity. Target and user modules (DP-HR) · 2...
Page 8 The guarantee of complying with all relevant instructions can only be given by applying original components. Therefore, the devices have to be operated with G&D certified transmission modules only. 3 · Target and user modules (DP-HR)
Page 9: Chapter A: Target Modules
 1 × Power cable (only with variants incl. PowerPack)  1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  1 × Category 5e (or better) twisted pair cable to connect the target module to the matrix switch 4 · Target and user modules (DP-HR)
Page 10 You can also connect the target module directly to a compatible user module. Power supply Insert the power pack’s connection cable to this interface. Power In: Connect the power cable to the power pack and a power socket. 5 · Target and user modules (DP-HR)
Page 11 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. Target and user modules (DP-HR) · 6...
Page 12 Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Audio Transmission type: transparent, bidirectional Resolution: 24 Bit Refresh rate: 96 kHz Bandwidth: 22 kHz 7 · Target and user modules (DP-HR)
Page 13 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 8...
Page 14: Target Module "Dp-Hr-Cpu-Uc
 1 × Power cable (only with variants incl. PowerPack)  1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  2 × Category 5e (or better) patch cables to connect the target module to two different matrix switches 9 · Target and user modules (DP-HR)
Page 15 Only connect one Trans. interface of the target module per matrix switch. NOTE: Use category 5e twisted pair cables (or better) to connect the devices. Power Trans. 2 Trans. 1 Service Power In Target and user modules (DP-HR) · 10...
Page 16 You can also connect the target module directly to up to two compatible user modules. Power supply Plug the power cable of the power pack in this interface. Then connect the Power In: power cable to the power pack and a power outlet. 11 · Target and user modules (DP-HR)
Page 17 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. Target and user modules (DP-HR) · 12...
Page 18 Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Audio Transmission type: transparent, bidirectional Resolution: 24 bits Sampling rate: 96 kHz Bandwidth: 22 kHz 13 · Target and user modules (DP-HR)
Page 19 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 14...
Page 20: Target Module "Dp-Hr-Cpu-Mc2
 1 × Power cable (only with variants incl. PowerPack)  1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  2 × Category 5e (or better) twisted pair cables to connect the target module to the matrix switch 15 · Target and user modules (DP-HR)
Page 21 Use the green plug of an optional Twin-PS/2 cable to connect the computer’s PS/2 mouse interface to this interface. Connection to the matrix switch NOTE: Only use category 5e (or better) twisted pair cables to connect the devices. Power Trans. Service Power In Target and user modules (DP-HR) · 16...
Page 22 NOTE: You can adjust any channel groups that were created automatically or manually. More information about channel groups is given in the separate manu- als of the matrix switch web applications. 17 · Target and user modules (DP-HR)
Page 23 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. Target and user modules (DP-HR) · 18...
Page 24 Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Audio Transmission type: transparent, bidirectional Resolution: 24 Bit Refresh rate: 96 kHz Bandwidth: 22 kHz 19 · Target and user modules (DP-HR)
Page 25 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 20...
Page 26: Target Module "Dp-Hr-Cpu-Mc2-Uc
 1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  4 × Category 5e (or better) twisted pair cables to connect the target module to two different matrix switches 21 · Target and user modules (DP-HR)
Page 27 Connections to the matrix switches IMPORTANT: Connect only one of the target module’s Trans. interfaces for each matrix switch! NOTE: Only use category 5e (or better) twisted pair cables to connect the devices. Target and user modules (DP-HR) · 22...
Page 28 NOTE: You can adjust any manually or automatically created channel group. More information about channel groups is given in the separate manuals of the matrix switch web applications. 23 · Target and user modules (DP-HR)
Page 29 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. Target and user modules (DP-HR) · 24...
Page 30 Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Audio Transmission type: transparent, bidirectional Resolution: 24 Bit Refresh rate: 96 kHz Bandwidth: 22 kHz 25 · Target and user modules (DP-HR)
Page 31 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 26...
Page 32: Target Module "Dp-Hr-Cpu-Fiber
 1 × Power cable (only with variants incl. PowerPack)  1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  1 × Compatible optical fibre cable to connect the target module to the matrix switch 27 · Target and user modules (DP-HR)
Page 33 Use the purple plug of an optional Twin-PS/2 cable to connect the computer’s PS/2 keyboard interface to this interface. Use the green plug of an optional Twin-PS/2 cable to connect the computer’s Mouse: PS/2 mouse interface to this interface. Target and user modules (DP-HR) · 28...
Page 34 You can also connect the target module directly to a compatible user module. Power supply Power In: Connect the cable of the power pack to this interface. Now connect the power cable to the power pack and a power socket. 29 · Target and user modules (DP-HR)
Page 35 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. Target and user modules (DP-HR) · 30...
Page 36 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz 31 · Target and user modules (DP-HR)
Page 37 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 32...
Page 38: Target Module "Dp-Hr-Cpu-Fiber-Uc
 1 × Power cable (only with variants incl. PowerPack)  1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  2 × Compatible optical fibre cable to connect the target module to two matrix switches 33 · Target and user modules (DP-HR)
Page 39  Only use G&D certified transmission modules on page 3 NOTE: Use optical fibres with LC plugs to connect the devices. The cables are available as accessories. IMPORTANT: For each matrix switch, connect only one Trans. interface of the tar- get module! Target and user modules (DP-HR) · 34...
Page 40 You can also connect the target module directly to a compatible user module. Power supply Power In: Connect the cable of the power pack to this interface. Now connect the power cable to the power pack and a power socket. 35 · Target and user modules (DP-HR)
Page 41 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. Target and user modules (DP-HR) · 36...
Page 42 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz 37 · Target and user modules (DP-HR)
Page 43 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 38...
Page 44: Target Module "Dp-Hr-Cpu-Fiber-Mc2
 2 × Audio cable  1 × Power pack (12V/2A, only with variants incl. PowerPack)  1 × Power cable (only with variants incl. PowerPack)  1 × EasyStart flyer  1 × »Safety instructions« flyer 39 · Target and user modules (DP-HR)
Page 45 Use the purple plug of an optional Twin-PS/2 cable to connect the computer’s Keyb.: PS/2 keyboard interface to this interface. Mouse: Use the green plug of an optional Twin-PS/2 cable to connect the computer’s PS/2 mouse interface to this interface. Target and user modules (DP-HR) · 40...
Page 46 Dynamic Port provided at the matrix switch. ADVICE: You can also connect the target module directly to a compatible user mod- ule. Power supply Power In: Insert the power pack’s connection cable to this interface. 41 · Target and user modules (DP-HR)
Page 47 NOTE: You can adjust any channel groups that were created automatically or manually. More information about channel groups is given in the separate manu- als of the matrix switch web applications. Target and user modules (DP-HR) · 42...
Page 48 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. 43 · Target and user modules (DP-HR)
Page 49 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Target and user modules (DP-HR) · 44...
Page 50 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS 45 · Target and user modules (DP-HR)
Page 51: Target Module "Dp-Hr-Cpu-Fiber-Mc2-Uc
At consoles with one monitor only, the image of the computer’s second video out- put is not displayed. Target and user modules (DP-HR) · 46...
Page 52 Use the USB device cable to connect one of the computer’s USB interfaces to this interface. Use the purple plug of an optional Twin-PS/2 cable to connect the computer’s Keyb.: PS/2 keyboard interface to this interface. 47 · Target and user modules (DP-HR)
Page 53 Trans. 1|Channel 2|Rx: Insert the LC plug of a compatible optical fibre cable. Connect the other end of the cable to the interface of the same Dynamic Port provided at the first matrix switch. Target and user modules (DP-HR) · 48...
Page 54 NOTE: You can adjust any manually or automatically created channel group. More information about channel groups is given in the separate manuals of the matrix switch web applications. 49 · Target and user modules (DP-HR)
Page 55 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. Target and user modules (DP-HR) · 50...
Page 56 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz 51 · Target and user modules (DP-HR)
Page 57 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 52...
Page 58: Target Module "Dp-Hr-Cpu-Dh
Use one of the supplied video cables to connect the computer’s first Display DP CPU 1: Port video output to this interface. Use one of the supplied video cables to connect the computer’s second Dis- DP CPU 2: play Port video output to this interface. 53 · Target and user modules (DP-HR)
Page 59 Insert the power pack’s connection cable to this interface. Start-up Connect the power cable to the power pack and a power socket. The target module starts as soon as it is supplied with power. Target and user modules (DP-HR) · 54...
Page 60 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. 55 · Target and user modules (DP-HR)
Page 61 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Target and user modules (DP-HR) · 56...
Page 62 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS 57 · Target and user modules (DP-HR)
Page 63: Target Module "Dp-Hr-Cpu-Dh-Uc
Line In Line Out DP CPU 1 DP CPU 2 USB K/M PS/2 Keyb. DP CPU 1: Use one of the supplied video cables to connect the computer’s first Display Port video output to this interface. Target and user modules (DP-HR) · 58...
Page 64 Connect this interface to a Dynamic Port (RJ45) of the second matrix switch. Trans. 2: ADVICE: You can also connect the target module directly to up to two compatible user modules. Power supply Insert the power pack’s connection cable to this interface. Power In: 59 · Target and user modules (DP-HR)
Page 65 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. Target and user modules (DP-HR) · 60...
Page 66 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz 61 · Target and user modules (DP-HR)
Page 67 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 62...
Page 68: Target Module "Dp-Hr-Cpu-Fiber-Dh
 1 × Power cable (only with variants incl. PowerPack)  1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  1 × Compatible optical fibre cable to connect the target module to the matrix switch 63 · Target and user modules (DP-HR)
Page 69  Always connect optical connections or cover them with protection caps on page 3  Only use G&D certified transmission modules on page 3 NOTE: Use optical fibres with LC plugs to connect the devices. The cables are available as accessories. Target and user modules (DP-HR) · 64...
Page 70 Insert the power pack’s connection cable to this interface. Start-up Connect the power cable to the power pack and a power socket. The target module starts as soon as it is supplied with power. 65 · Target and user modules (DP-HR)
Page 71 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. Target and user modules (DP-HR) · 66...
Page 72 24 Bit Video bandwidth: 25 to 300 MP/s (Channel 1) 25 to 165 MP/s (Channel 2) Max. 330 MP/s (total) Vertical frequency: 24 Hz to 120 Hz Horizontal frequency: 25 kHz to 135 kHz 67 · Target and user modules (DP-HR)
Page 73 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 68...
Page 74: Target Module "Dp-Hr-Cpu-Fiber-Dh-Uc
 1 × Power cable (only with variants incl. PowerPack)  1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  2 × Compatible optical fibre cable to connect the target module to two different matrix switches 69 · Target and user modules (DP-HR)
Page 75  Only use G&D certified transmission modules on page 3 NOTE: Use optical fibres with LC plugs to connect the devices. The cables are available as accessories. IMPORTANT: For each matrix switch, connect only one Trans. interface of the tar- get module! Target and user modules (DP-HR) · 70...
Page 76 Insert the power pack’s connection cable to this interface. Start-up Connect the power cable to the power pack and a power socket. The target module starts as soon as it is supplied with power. 71 · Target and user modules (DP-HR)
Page 77 No user module is accessing. Flickering Keyboard and mouse inputs are forwarded by the accessing user module. The flickering is defined by the user’s entries. Yellow Flashing A firmware update is carried out. Target and user modules (DP-HR) · 72...
Page 78 24 Bit Video bandwidth: 25 to 300 MP/s (Channel 1) 25 to 165 MP/s (Channel 2) Max. 330 MP/s (total) Vertical frequency: 24 Hz to 120 Hz Horizontal frequency: 25 kHz to 135 kHz 73 · Target and user modules (DP-HR)
Page 79 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 74...
Page 80: Chapter B: User Modules
 1 × Power cable  1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  1 × Category 5e (or better) twisted pair cable to connect the user module to the matrix switch Target and user modules (DP-HR) · 75...
Page 81 Generic socket. LED Out: If you expanded the functional range of the matrix switch by purchasing the TradeSwitch function, connect the optional TS-LED-2 (order number A6100041) to this interface. Target and user modules (DP-HR) · 76...
Page 82 Start-up Start the user module by pressing the Main Power button of the power pack. ADVICE: The active hotkey configuration is displayed during the System Startup of the matrix switch. 77 · Target and user modules (DP-HR)
Page 83 A local keyboard was detected. No power at PS/2 interface or USB bus. Flashing The CPU input (PS/2 or USB) is active and ready. A local keyboard was not detected. Target and user modules (DP-HR) · 78...
Page 84 NOTE: Keyboard and mouse signals can only access another user module or a tar- get computer if you activated the TradeSwitch function for the matrix switch. 79 · Target and user modules (DP-HR)
Page 85 Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Audio Transmission type: transparent, bidirectional Resolution: 24 Bit Sampling rate: 96 kHz Bandwidth: 22 kHz Target and user modules (DP-HR) · 80...
Page 86 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS 81 · Target and user modules (DP-HR)
Page 87: User Module "Dp-Hr-Con-2
 1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  2 × Category 5e (or better) twisted pair cables to connect the user module to two the matrix switches Target and user modules (DP-HR) · 82...
Page 88 OSD with a keyboard connected to the Generic socket. LED Out: If you purchased and added the TradeSwitch feature to the matrix switch, con- nect the optional TS-LED2 here (order number A6100041). 83 · Target and user modules (DP-HR)
Page 89  Press the button of the desired channel to activate it. How to switch channels via key combinations:  On the console keyboard, press local hotkey+Select key In the default settings, the select keys are (channel 1) and (channel 2). Alt+1 Alt+2 Target and user modules (DP-HR) · 84...
Page 90 A local keyboard was not detected. Trans. Active Active channel. Inactive channel. Status The communication to the counterpart station is estab- lished successfully. The communication to the counterpart station could not be established. 85 · Target and user modules (DP-HR)
Page 91 NOTE: Keyboard and mouse signals can only access another user module or a tar- get computer if you purchased the TradeSwitch feature for the matrix switch. Target and user modules (DP-HR) · 86...
Page 92 Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Audio Transmission type: transparent, bidirectional Resolution: 24 Bit Sampling rate: 96 kHz Bandwidth: 22 kHz 87 · Target and user modules (DP-HR)
Page 93 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 88...
Page 94: User Module "Dp-Hr-Con-Mc2
 1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  2 × Category 5e (or better) twisted pair cables to connect the user module to a KVM matrix switch 89 · Target and user modules (DP-HR)
Page 95 OSD with a keyboard connected to the Generic socket. LED Out: If you purchased and added the TradeSwitch feature to the matrix switch, connect the optional TS-LED2 here (order number A6100041). Target and user modules (DP-HR) · 90...
Page 96  Turn on the power pack. Main Power  Use an optional power pack to supply the socket with power. Red. Power 91 · Target and user modules (DP-HR)
Page 97 NOTE: You can adjust adjsut any channel groups that were created automatically or manually. More information about channel groups is given in the separate manuals of the matrix switch web applications. Target and user modules (DP-HR) · 92...
Page 98 No signal at second video input, or the signal quality is too weak to be processed by the system. Trans. 2 The communication to the counterpart station is estab- lished successfully. The communication to the counterpart station could not be established. 93 · Target and user modules (DP-HR)
Page 99 NOTE: Keyboard and mouse signals can only be switched to another user module or target computer if you purchased the TradeSwitch function for the matrix switch Target and user modules (DP-HR) · 94...
Page 100 Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Audio Transmission type: transparent, bidirectional Resolution: 24 bits Refresh rate: 96 kHz Bandwidth: 22 kHz 95 · Target and user modules (DP-HR)
Page 101 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 96...
Page 102: User Module "Dp-Hr-Con-Mc4
 1 × Power cable  1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  4 × Category 5e (or better) twisted pair cables to connect the user module to the matrix switch 97 · Target and user modules (DP-HR)
Page 103 Generic HID with a keyboard connected to the socket. Generic If you purchased and added the TradeSwitch feature to the matrix switch, con- LED Out: nect the optional TS-LED2 here (order number A6100041). Target and user modules (DP-HR) · 98...
Page 104 Use category 5e (or better) twisted pair cables to connect the devices. Connect this interface to another Dynamic Port (RJ45) of the matrix Transmission 3: switch. Transmission 4: Connect this interface to another Dynamic Port (RJ45) of the matrix switch. 99 · Target and user modules (DP-HR)
Page 105 NOTE: You can adjust adjsut any channel groups that were created automatically or manually. More information about channel groups is given in the separate manuals of the matrix switch web applications. Target and user modules (DP-HR) · 100...
Page 106 No signal at second video input, or the signal quality is too weak to be processed by the system. Trans. 2 The communication to the counterpart station is estab- lished successfully. The communication to the counterpart station could not be established. 101 · Target and user modules (DP-HR)
Page 107 No data connection to the counterpart station. Flashing Data connection to the counterpart station established. Green No user is logged in at the user module. A user is logged in at the user module. Target and user modules (DP-HR) · 102...
Page 108 NOTE: Keyboard and mouse signals can only be switched to another user module or target computer if you purchased the TradeSwitch function for the matrix switch 103 · Target and user modules (DP-HR)
Page 109 Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Audio Transmission type: transparent, bidirectional Resolution: 24 bits Refresh rate: 96 kHz Bandwidth: 22 kHz Target and user modules (DP-HR) · 104...
Page 110 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS 105 · Target and user modules (DP-HR)
Page 111: User Module "Dp-Hr-Con-Fiber
 1 × Power cable  1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  1 × Compatible optical fibre cable to connect the user module to the matrix switch Target and user modules (DP-HR) · 106...
Page 112 Generic socket. LED Out: If you expanded the functional range of the matrix switch by purchasing the TradeSwitch function, connect the optional TS-LED-2 (order number A6100041) to this interface. 107 · Target and user modules (DP-HR)
Page 113 Start-up Start the user module by pressing the Main Power button of the power pack. ADVICE: The active hotkey configuration is displayed during the System Startup of the matrix switch. Target and user modules (DP-HR) · 108...
Page 114 A local keyboard was detected. No power at PS/2 interface or USB bus. Flashing The CPU input (PS/2 or USB) is active and ready. A local keyboard was not detected. 109 · Target and user modules (DP-HR)
Page 115 NOTE: Keyboard and mouse signals can only access another user module or a tar- get computer if you activated the TradeSwitch function for the matrix switch. Target and user modules (DP-HR) · 110...
Page 116 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz 111 · Target and user modules (DP-HR)
Page 117 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 112...
Page 118: User Module "Dp-Hr-Con-2-Fiber
Instead of a matrix switch, you can also connect a compatible target module to each of the two channels. Package contents  1 × DP-HR-CON-2-Fiber user module  1 × Power cable  1 × EasyStart flyer  1 × »Safety instructions« flyer 113 · Target and user modules (DP-HR)
Page 119 OSD with a keyboard connected to the Generic socket. LED Out: If you purchased and added the TradeSwitch feature to the matrix switch, con- nect the optional TS-LED2 here (order number A6100041). Target and user modules (DP-HR) · 114...
Page 120 If required, connect the power cable of the optional power pack to this Red. Power: interface. This provides a redundant power supply. Connect the power cable with the power pack and a power outlet of a different power circuit. 115 · Target and user modules (DP-HR)
Page 121  Press the button of the desired channel to activate it. How to switch channels via key combinations:  On the console keyboard, press local hotkey+Select key In the default settings, the select keys are Alt+1 (channel 1) and Alt+2 (channel 2). Target and user modules (DP-HR) · 116...
Page 122 A local keyboard was not detected. Trans. Active Active channel. Inactive channel. Status The communication to the counterpart station is estab- lished successfully. The communication to the counterpart station could not be established. 117 · Target and user modules (DP-HR)
Page 123 NOTE: Keyboard and mouse signals can only access another user module or a tar- get computer if you purchased the TradeSwitch feature for the matrix switch. Target and user modules (DP-HR) · 118...
Page 124 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz 119 · Target and user modules (DP-HR)
Page 125 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 120...
Page 126: User Module "Dp-Hr-Con-Fiber-Mc2
In this case, add both target modules in the web application to channel group. Package contents  1 × User module DP-HR-CON-Fiber-MC2  1 × Power cable  1 × EasyStart flyer  1 × »Safety instructions« flyer 121 · Target and user modules (DP-HR)
Page 127 OSD Generic HID with a keyboard connected to the socket. Generic If you purchased and added the TradeSwitch feature to the matrix switch, LED Out: connect the optional TS-LED2 here (order number A6100041). Target and user modules (DP-HR) · 122...
Page 128 Insert the LC plug of a compatible optical fibre cable. Connect the other end of the cable to the interface of the same Dynamic Port provided at the matrix switch. ADVICE: You can also connect the user module directly to a compatible target module. 123 · Target and user modules (DP-HR)
Page 129 NOTE: You can adjust adjsut any channel groups that were created automatically or manually. More information about channel groups is given in the separate manuals of the matrix switch web applications. Target and user modules (DP-HR) · 124...
Page 130 No signal at second video input, or the signal quality is too weak to be processed by the system. Trans. 2 The communication to the counterpart station is estab- lished successfully. The communication to the counterpart station could not be established. 125 · Target and user modules (DP-HR)
Page 131 NOTE: Keyboard and mouse signals can only be switched to another user module or target computer if you purchased the TradeSwitch function for the matrix switch Target and user modules (DP-HR) · 126...
Page 132 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz 127 · Target and user modules (DP-HR)
Page 133 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 128...
Page 134: User Module "Dp-Hr-Con-Fiber-Mc4
When accessing the system with a target module with only one graphics input, only the first monitor shows an image. Package contents  1 × User module DP-HR-CON-Fiber-MC4  1 × Power cable  1 × EasyStart flyer  1 × »Safety instructions« flyer 129 · Target and user modules (DP-HR)
Page 135 OSD with a keyboard connected to the Generic socket. If you purchased and added the TradeSwitch feature to the matrix switch, con- LED Out: nect the optional TS-LED2 here (order number A6100041). Target and user modules (DP-HR) · 130...
Page 136 Transmission 2|Rx: Insert the LC plug of a compatible optical fibre cable. Connect the other end of the cable to the interface of the same Dynamic Port provided at the matrix switch. 131 · Target and user modules (DP-HR)
Page 137 Connect the supplied power cable. Insert the cable’s Schuko plug in a power socket. Connect the connection cable of a compatible power pack to provide the Red. Power: user module with a second, redundant power supply. Target and user modules (DP-HR) · 132...
Page 138 NOTE: You can adjust adjsut any channel groups that were created automatically or manually. More information about channel groups is given in the separate manuals of the matrix switch web applications. 133 · Target and user modules (DP-HR)
Page 139 No signal at second video input, or the signal quality is too weak to be processed by the system. Trans. 2 The communication to the counterpart station is estab- lished successfully. The communication to the counterpart station could not be established. Target and user modules (DP-HR) · 134...
Page 140 No data connection to the counterpart station. Flashing Data connection to the counterpart station established. Green No user is logged in at the user module. A user is logged in at the user module. 135 · Target and user modules (DP-HR)
Page 141 NOTE: Keyboard and mouse signals can only be switched to another user module or target computer if you purchased the TradeSwitch function for the matrix switch Target and user modules (DP-HR) · 136...
Page 142 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz 137 · Target and user modules (DP-HR)
Page 143 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS Target and user modules (DP-HR) · 138...
Page 144: User Module "Dp-Hr-Con-Dh
 1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  1 × Category 5e (or better) twisted pair cable to connect the user module to a KVM matrix switch 139 · Target and user modules (DP-HR)
Page 145 OSD with a keyboard connected to the Generic socket. LED Out: If you purchased and added the TradeSwitch feature to the matrix switch, connect the optional TS-LED2 here (order number A6100041). Target and user modules (DP-HR) · 140...
Page 146 Main Power redundant power pack to establish the power supply:  Turn on the power pack. Main Power  Use an optional power pack to supply the socket with power. Red. Power 141 · Target and user modules (DP-HR)
Page 147 A local keyboard was detected. No power at PS/2 interface or USB bus. Flashing The CPU input (PS/2 or USB) is active and ready. A local keyboard was not detected. Target and user modules (DP-HR) · 142...
Page 148 NOTE: Keyboard and mouse signals can only be switched to another user module or target computer if you purchased the TradeSwitch function for the matrix switch 143 · Target and user modules (DP-HR)
Page 149 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Target and user modules (DP-HR) · 144...
Page 150 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS 145 · Target and user modules (DP-HR)
Page 151: User Module "Dp-Hr-Con-2-Dh
 1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  2 × Category 5e (or better) twisted pair cables to connect the user module to two the matrix switches Target and user modules (DP-HR) · 146...
Page 152 Generic HID with a keyboard connected to the socket. Generic If you purchased and added the TradeSwitch feature to the matrix switch, con- LED Out: nect the optional TS-LED2 here (order number A6100041). 147 · Target and user modules (DP-HR)
Page 153  Use an optional power pack to supply the socket with power. Red. Power ADVICE: The active hotkey configuration is displayed during the System Startup of the matrix switch and the user module. Target and user modules (DP-HR) · 148...
Page 154  Press the button of the desired channel to activate it. How to switch channels via key combinations:  On the console keyboard, press local hotkey+Select key In the default settings, the select keys are (channel 1) and (channel 2). Alt+1 Alt+2 149 · Target and user modules (DP-HR)
Page 155 The communication with the connected matrix switch or the target module of this channel was established success- fully. The communication with a matrix switch or target module of this active channel could not be established. Target and user modules (DP-HR) · 150...
Page 156 NOTE: Keyboard and mouse signals can only access another user module or a tar- get computer if you purchased the TradeSwitch feature for the matrix switch. 151 · Target and user modules (DP-HR)
Page 157 However, the support cannot be guaranteed for all monitor models. Audio Transmission type: 2 channel LPCM, stereo  DisplayPort Digital Resolutions: 16/20/24 bit Sampling rates: up to 48 kHz Target and user modules (DP-HR) · 152...
Page 158 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS 153 · Target and user modules (DP-HR)
Page 159: User Module "Dp-Hr-Con-Fiber-Dh
 1 × EasyStart flyer  1 × »Safety instructions« flyer Required accessories  1 × Compatible optical fibre cable to connect the user module to a KVM matrix switch of the ControlCenter-Digital series Target and user modules (DP-HR) · 154...
Page 160 OSD Generic HID with a keyboard connected to the socket. Generic LED Out: If you purchased and added the TradeSwitch feature to the matrix switch, connect the optional TS-LED2 here (order number A6100041). 155 · Target and user modules (DP-HR)
Page 161 Insert the LC plug of a compatible optical fibre cable. Connect the other end of the cable to the interface of the same Dynamic Port provided at the matrix switch. ADVICE: You can also connect the user module directly to a compatible target module. Target and user modules (DP-HR) · 156...
Page 162  Turn on the power pack. Main Power  Use an optional power pack to supply the socket with power. Red. Power 157 · Target and user modules (DP-HR)
Page 163 A local keyboard was detected. No power at PS/2 interface or USB bus. Flashing The CPU input (PS/2 or USB) is active and ready. A local keyboard was not detected. Target and user modules (DP-HR) · 158...
Page 164 NOTE: Keyboard and mouse signals can only be switched to another user module or target computer if you purchased the TradeSwitch function for the matrix switch 159 · Target and user modules (DP-HR)
Page 165  1280 × 1024 @ 85 Hz  1080p60 (Full HD)  640 × 480 @ 60 Hz  Further VESA and CTA standardised resolutions possible within video bandwidth/pixel rate and horizontal/vertical frequency. Target and user modules (DP-HR) · 160...
Page 166 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS 161 · Target and user modules (DP-HR)
Page 167: User Module "Dp-Hr-Con-2-Fiber-Dh
Instead of a matrix switch, you can also connect a compatible target module to each of the two channels. Package contents  1 × User module DP-HR-CON-2-Fiber-DH  1 × Power cable  1 × EasyStart flyer  1 × »Safety instructions« flyer Target and user modules (DP-HR) · 162...
Page 168 Connect the console PS/2 mouse. Mouse: Keyb./Mouse: Connect the console USB keyboard and/or USB mouse. By default ( mode), you can use this interface to connect another Generic: Keyb./Mouse USB input device or supported displays or tablets. 163 · Target and user modules (DP-HR)
Page 169 Transmission 1|Rx: Insert the LC plug of a compatible optical fibre cable. Connect the other end of the cable to the interface of the same Dynamic Port provided at the matrix switch. Target and user modules (DP-HR) · 164...
Page 170  Press the button of the desired channel to activate it. How to switch channels via key combinations:  On the console keyboard, press local hotkey+Select key In the default settings, the select keys are Alt+1 (channel 1) and Alt+2 (channel 2). 165 · Target and user modules (DP-HR)
Page 171 The communication with the connected matrix switch or the target module of this channel was established success- fully. The communication with a matrix switch or target module of this active channel could not be established. Target and user modules (DP-HR) · 166...
Page 172 NOTE: Keyboard and mouse signals can only be switched to another user module or target computer if you purchased the TradeSwitch function for the matrix switch 167 · Target and user modules (DP-HR)
Page 173  1280 × 1024 @ 85 Hz  1080p60 (Full HD)  640 × 480 @ 60 Hz  Further VESA and CTA standardised resolutions possible within video bandwidth/pixel rate and horizontal/vertical frequency. Target and user modules (DP-HR) · 168...
Page 174 +5 °C to +45 °C environment Air humidity: 20 % to 80 %, non-condensing Storage Temperature: -20°C to +55°C environment Air humidity: 15 % to 85 %, non-condensing Conformity CE, EAC, FCC Class B, RoHS 169 · Target and user modules (DP-HR)
Page 175: Chapter C: Generic Hid
Generic HID mode How to enable/disable the user module’s Generic HID mode: 1. Press Ctrl+Num (default) to open the on-screen display. 2. Press to open the Configuration menu. 3. Select Console and press Enter 170 · Target and user modules (DP-HR)
Page 176: Enabling/Disabling The Target Module's Generic Hid Mode
(default) to open the on-screen display. Ctrl+Num 2. Press to open the Configuration menu. 3. Select Target and press Enter 4. Select the target module whose settings you want to change and press 171 · Target and user modules (DP-HR)
Page 177 USB target modules additionally support certain USB input devices. After selecting the specific USB keyboard mode of such a device, you can use the special features of these USB input devices. 6. Click to save your changes. Target and user modules (DP-HR) · 172...
Page 178: Chapter D: Extender Mode
You can use the configured hotkey to open the on-screen display at the console. How to open the on-screen display: 1. Press Alt+Num (default) to open the on-screen display. Configuration Hotkey... EDID... Keyboard/Mouse... Mouse utility... Console utility... Information... ESC: Exit Target and user modules (DP-HR) · 173...
Page 179: Configuration
Modifier . Then, press Ctrl: Ctrl key Alt: Alt key Alt Gr: Alt Gr key Win: Windows key Shift: Shift key Target and user modules (DP-HR) · 174...
Page 180 Open OSD by pressing Alt twice Alt Gr: Open OSD by pressing Alt Gr twice Win: Open OSD by pressing Win twice Shift: Open OSD by pressing Shift twice Print: Open OSD by pressing Druck twice 175 · Target and user modules (DP-HR)
Page 181 ADVICE: In some cases it is recommended to send the EDID profile of the console monitor to the target module. Now the connected computer receives the EDID data of the console monitor. Target and user modules (DP-HR) · 176...
Page 182 PixelPower C: Special PixelPower Rapid Action keyboard SKIDATA1: Special SKIDATA1 keyboard ADVICE: Press Ctrl+F8 to show a list inclduing all options. Select the desired option and press Enter 4. Press to save your settings. 177 · Target and user modules (DP-HR)
Page 183 All USB devices are regularly reinitialised. only faulty: The status of USB devices is monitored. If the communica- tion with a USB devices is interrupted, the device is reini- tialised. 4. Press to save your settings. Target and user modules (DP-HR) · 178...
Page 184 Wacom Intuos3  Wacom Int.3 Wacom Intuos4 S  Wacom Int.4S Wacom Intuos4 M  Wacom Int.4M Wacom Intuos4 L  Wacom Int.4L Wacom Intuos4 XL  Wacom Int.4XL Wacom Intuos5  Wacom Int.5 179 · Target and user modules (DP-HR)
Page 185 You can use the emulation of »Solaris Shortcut Keys« in the SUN DE keyboard mode only. SUN US If the target module is provided with a Sun Keyboard, you can use Solaris Shortcut Keys after enabling their support. Target and user modules (DP-HR) · 180...
Page 186 IBM RS/6000 support Yes: Support for servers of IBM’s RS/6000 series is activated Support for servers of IBM’s RS/6000 series is deactivated 4. Press to save your settings. 181 · Target and user modules (DP-HR)
Page 187 How to reset the default settings of the matrix switch: 1. Press the (default) hotkey to open the on-screen display. Alt+Num 2. Select Console utility and press Enter 3. Select and press Set system defaults Enter Target and user modules (DP-HR) · 182...
Page 188 2. Select and press Information Enter 3. Use the arrow keys to select the desired menu item (see above). 4. Press Enter to show the desired information. 5. Press to leave the menu. 183 · Target and user modules (DP-HR)
Page 192 G&D. AND KVM FEELS RIGHT. Hauptsitz | Headquarter US-Büro | US-Office Guntermann & Drunck GmbH Systementwicklung G&D North America Inc. Obere Leimbach 9 | D-57074 Siegen | Phone +49 271 23872-0 4001 W. Alemada Avenue | Suite 100, Burbank, CA 91505 | Phone +1-818-748-3383 sales.us@gdsys.com | www.gdsys.com sales@gdsys.com | www.gdsys.com...

G&D DP-HR Installation And Operations

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for G&D DP-HR

Summary of Contents for G&D DP-HR

This manual is also suitable for:

Table of Contents
