F-SCTXL / F-SCTXL-G / F-SCTXL-T / F-SCTXL-W / F-SCTXL-C
MANDATORY
LEAVE THIS MANUAL WITH OWNER
Read and follow all instructions.
Lift safety can only be ensured if the lift is
installed and operated according to these
instructions.
• FOR SAFETY REASONS
•
NEVER
swim alone
•
NEVER
use the lift with a dry pool
•
NEVER
apply direct water
pressure to the electronics
•
NEVER
permit children to play on
or around the lift
•
DO NOT
lift without adult supervision
READ CAREFULLY
Check entire box and all packing
materials for parts. Before beginning
assembly, read the instructions and
identify parts using the figures and
parts listed in this document.
It is critical that all parts be carefully
inspected prior to installation. If any
damage occurred in transit, Aqua Creek
Products, LLC must be notified within
three days of receipt of unit.
Proper installation cannot be
overstressed, as an improper
installation voids Aqua Creek's warranty
and may affect the safety of the user.
USE THIS MANUAL FOR PART #'s:
allow children to use the
SCOUT EXCEL - BLUE
CATALOG NO. F-SCTXL
Aqua Creek Products, LLC
9889 Garrymore Lane
Missoula, MT 59808
Toll Free: (888) 687-3552
Local/Intnl: (406) 549-0769
www.aquacreek.com
6/27/2022 8:55:18 AM PAGE - 1
Advertisement
Related Manuals for Aqua Creek Products F-SCTXL
Summary of Contents for Aqua Creek Products F-SCTXL
- Page 1 SCOUT EXCEL - BLUE CATALOG NO. F-SCTXL USE THIS MANUAL FOR PART #’s: F-SCTXL / F-SCTXL-G / F-SCTXL-T / F-SCTXL-W / F-SCTXL-C MANDATORY LEAVE THIS MANUAL WITH OWNER Read and follow all instructions. Lift safety can only be ensured if the lift is installed and operated according to these instructions.
- Page 2 LIFTING ARM & ACTUATOR WARRANTY ASSEMBLY CONTROL ARM & SEAT POLE CARE ASSEMBLY SEAT & FOOTREST ASSEMBLY BATTERY PLACEMENT & REMOTE OPERATION IMPORTANT SAFETY INSTRUCTIONS INSPECTION REPORT VISUAL INSPECTION SCOUT EXCEL - BLUE - CATALOG NO. F-SCTXL 6/27/2022 8:55:18 AM PAGE - 2...
- Page 3 BH - 1/2"-13X1 3/4" HEX HEAD BOLT INV01169 WF - 1/2" FLAT WASHER INV01583 ANCHOR - KIT INSERT - 1.00"X4.00" EXP01725 BOX - 18.00X12.00X6.00 EXP03135 MANUAL - F-SCTXL 15 STOCK BOX - NOT SHOWN 6/27/2022 8:55:18 AM PAGE - 3...
- Page 4 Aqua Creek Products PRODUCT ASSEMBLY LIFT THE SCOUT EXCEL MAST ASSEMBLY FROM THE SHIPPING CONTAINER. INSERT THE 1.90" [48mm] POST OF THE MAST ASSEMBLY INTO THE DECK ANCHOR. EASE THE MAST ASSEMBLY DOWN UNTIL IT RESTS ON THE DECK SURFACE. ROTATE THE BASE UNTIL THE FIXING ANCHOR HOLE LINES UP WITH THE FIXING ANCHOR.
- Page 5 Aqua Creek Products PRODUCT ASSEMBLY CONNECT THE LIFTING ARM BETWEEN THE MAST AND THE ACTUATOR. TIGHTEN NYLOCK NUTS. NOTE: BE CAREFUL NOT TO OVER- TIGHTEN BOLTS. OVER-TIGHTENING CAN CAUSE DAMAGE AND COMPROMISE THE SAFETY OF YOUR LIFT. FIG. 04 INSTALL THE SEAT POLE AT THE ENDS OF THE LIFTING AND CONTROL ARMS.
- Page 6 Aqua Creek Products PRODUCT ASSEMBLY THE SEAT ASSEMBLY WILL ARRIVE ATTACHED TO THE SEAT POLE ADJUSTED TO ITS HIGHEST POSITION (HOLE 05). TO ADJUST THE SEAT ASSEMBLY TO A LOWER POSITION HOLE 05 REMOVE THE FASTENERS SHOWN IN FIG. 05. SLIDE THE SEAT ASSEMBLY TO ITS DESIRED POSITION (4"...
- Page 7 Aqua Creek Products PRODUCT ASSEMBLY REMOVE THE FULLY CHARGED BATTERY FROM THE CHARGER AND INSTALL THE BATTERY TO THE CONTROL BRACKET, ON TOP OF THE CONTROL BOX. ONCE SECURE, CONNECT THE BATTERY CABLE TO THE CONTROL BOX CABLE. THE LIFT WILL ONLY OPERATE WHEN THE BATTERY IS CONNECTED PROPERLY.
- Page 8 Aqua Creek Products IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING WARNING - To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. This appliance is not intended for use by persons (including children) with reduced...
- Page 9 Aqua Creek Products Annual Pool Lift Safety INSPECTION REPORT LIFT / INSPECTION INFORMATION Test Date: For Additional Support Assistance Call: Pool Lift Model: Serial Number: Toll Free: 888-687-3552 International: 1+406-549-0769 Inspected By: Find additional trouble shooting info. and videos at: https://aquacreekproducts.com/help-center/troubleshooting/...
- Page 10 Aqua Creek Products Annual Pool Lift Safety INSPECTION REPORT 1. OVERALL VISUAL INSPECTION Corrosion is common with anything in a swimming pool environment; even stainless steel. Proper and regular maintenance and cleaning will prevent most instances of corrosion. Replace any components that have corrosion caused pitting, cracking, thinning of the base metal, or other instances of corrosion that can't be eliminated and/or minimized through thorough cleaning.
- Page 11 Aqua Creek Products Annual Pool Lift Safety INSPECTION REPORT 1. PHYSICAL POOL LIFT TEST A physical test of the lift function is required when doing an annual inspection. NOTE: The lift should always be fun through a completed cycle without a load prior to each use. The annual test should be ran both empty and with a typical load weight to test the lifts functions.
- Page 12 Aqua Creek Products Annual Pool Lift Safety INSPECTION REPORT 1. ELECTRONICS INSPECTION Most electronic issues are due to pool electrical connections and/or a defective battery. Always remove the battery and place on the charger when the lift is not in use. NOTE: Even if your lift is equipped with a solare charger, it is a good idea to place the battery on the wall charger periodically or during extended periods of non-use or storage.
- Page 13 Local/Intnl: (406) 549-0769 www.aquacreek.com Aqua Creek Products, LLC (a.k.a. Aqua Creek) warrants to the original end user purchaser that products manufactured by Aqua Creek, when properly installed in accordance with assembly and installation instructions, and properly used and maintained, shall...
- Page 14 Aqua Creek Products PROPER CARE OF LIFTS For service and/or replacement parts, contact Toll free: (888) 687-3552 DAILY WEEKLY MONTHLY BEFORE PROCEDURE EACH USE Check battery level indicator on control box. Run the lift through a complete test cycle (fully extend actuator) to verify it is functioning properly.
- Page 15 Aqua Creek Products TROUBLE SHOOTING 6/27/2022 8:55:18 AM PAGE - 15...
