- Page 1 Item # : DW44JUN Assembly Instructions Please visit our website for the most current instructions, assembly tips, report damage, or request parts. www.walkeredison.com Revised 06/2017 Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
-
Page 2: General Assembly Guidelines
. Wipe away excess glue immediately. A Phillips head screwdriver is required for the assembly of this product . VII. Power tools should not be used to assemble this product . Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©... -
Page 3: Parts List
Parts List Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©... -
Page 4: Hardware List
Philips head screwdriver required for assembly (not included) The hardware quantities listed above are required for proper assembly. Some extra hardware may also have been included. Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©... - Page 5 Repeat this process for both drawer sliders ( U). Step 2 Secure drawer slider arms (U) to side panels (3,4,5,6) with screw (T). Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 6 Step 3 Insert wooden dowel (A) into side panel (3,4,5,6). Step 4 Secure cam bolt (B) to top panel (1). Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 7 Insert side panel (3,4,5,6) into top panel (1), then insert and secure cam lock (C) to side panel (3,4,5,6) to lock it. Step 6 Slide back panel (7) into grooves. Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 8 Step 7 E x8 Use wrench (P) to secure panel (2) to side panel (3,4,5,6) with bolt (E). Step 8 Place sticker (D) over holes as per diagram. Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 9 Use wrench (P) to secure part (10) to side frame (8,9) with bolt (N) and washer (S). Step 10 M x6 S x6 Use wrench (P) to secure part (10) and side frame (8,9) to panel (2) with bolt (M) and washer (S). Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 10 Secure cam bolt (B) to drawer front panel (12). Repeat for both drawers. Step 12 Secure drawer side panel (13,14) to drawer back panel (15) with screw (Q). Repeat for both drawers. P.10 Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 11 Insert drawer front panel (12) into drawer side panel (13,14), then insert and secure cam lock (F) to drawer side panel (13,14) to lock it. Repeat for both drawers. P.11 Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 12 Secure handle (G) to drawer front panel (12) with handle bolt (H). Repeat for both drawers. Step 16 Place sticker (D) over holes as per diagram. Repeat for both drawers. P.12 Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 13 Step 18 Slider arm Slider bracket Press down/up the slider lock on slider bracket, then insert the drawer into slider arm to lock it. Repeat for both drawers. P.13 Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 14 Step 19 Secure plastic wedge (K) to back panel (7) with screw (J). Step 20 Final Assembly P.14 Copyright 2017, by Walker Edison Furniture Co., LLC. All rights reserved. ©...
