Wisp
User Manual
Email: support.fr@potensic.com
Email: support.it@potensic.com
Email: support.es@potensic.com
DANGER
Only suitable
for age 14+
Email: support.jp@potensic.com
Web: www.potensic.com
FB: www.facebook.com/Potensic
Advertisement
Table of Contents
Related Manuals for Potensic Wisp
Summary of Contents for Potensic Wisp
- Page 1 DANGER Only suitable for age 14+ Wisp User Manual Email: support.fr@potensic.com Email: support@potensic.com Email: support.jp@potensic.com Email: support.it@potensic.com Email: support.uk@potensic.com Web: www.potensic.com Email: support.es@potensic.com Email: support.de@potensic.com FB: www.facebook.com/Potensic...
-
Page 2: Table Of Contents
Contents 01 Package List 01 Download Potensic Toy 02 Drone Overview Drone Diagram Remote Control Diagram 04 About Aircraft Aircraft Overview Drone Indicator Status Intelligent Flight Battle Mode 06 Battery 06 Propellers Installation 07 Remote Control 09 Potensic Toy APP... -
Page 3: Package List
AAA battery x3 Download Potensic Toy For smart phone with Android 5.0+ or windows system: Search and download "Potensic Toy" from Google Play. For smart phone with iOS 9.0+: Search and download "Potensic Toy" from App Store. - 01 -... -
Page 4: Drone Overview
Thank you for purchasing Potensic products. This chapter mainly introduces the features of Wisp and the names of various parts of aircraft and remote control. In order to make it easier for you to use the aircraft, please read this instructions carefully before you operate the aircraft. -
Page 5: Remote Control Diagram
Remote Control Diagram Fast 360° Rotate Battery Slot Battle Mode Speed Switch Headless Mode Control Stick Level Calibration Power Button Front Trimming One-key Take off/Land Right Trimming Take a Picture Back Trimming Emergency Stop Take a Video Left Trimming (Hold and press 2s) Phone Clip - 03 -... -
Page 6: About Aircraft
About Aircraft Aircraft Overview Wisp is mainly composed of flight control, communication system, infrared transceiver system, power system, and flight battery. The flight time can be up to 10 minutes. This chapter will introduce the basic functions of the aircraft. -
Page 7: Battle Mode
Land Protection The aircraft has two landing-protection functions: Low power landing protection: when the aircraft has 20% power, the low power alarm will be triggered, and rear light will flash red slowly. When the aircraft has 10% power, it will trigger low power landing and drone will fly on the ground at a constant speed and the propellers stop turning. -
Page 8: Battery
Battery When the aircraft's power is too low, it should land in time and the battery be charged. As shown in the Picture, connect the adapter correctly to charge the battery. When charging, the indicator lights red, and after full charging, the indicator lights green. The charging time is about 2 hours. -
Page 9: Remote Control
Remote Control Wisp adopts a 2.4Ghz remote controller with complete function buttons, which can complete various operations and settings between the aircraft and the camera within the maximum communication distance of 50 meters. It can also display high-defini- tion images on mobile devices in real time through Potensic-Toy app (smoothly image transmission within 30m with no interference environment). - Page 10 Level Calibration After frequency linking, place the aircraft on the horizontal ground and press the level calibration key of the remote control for calibration. Then, the drone tail light "flashes alternately red and green" and turns green after calibration. Taking Off and Landing Manual take-off: Turn the left and right stick to the inside downwards at the same time (Picture 1), and push the throttle stick(left stick) upward.
-
Page 11: Potensic Toy App
Potensic Toy APP Connecting with Smart Phone Wisp can also directly control the aircraft through the mobile phone. Please note that the remote control distance is 50m(under no interference environment). 1. Turn on the drone, then enter the mobile phone “setting-WiFi” and connect "Potensic P7_xxxxxx", no passward is needed. -
Page 12: Specification
Specification Drone Take off weight: 68g Maximum rising speed: 2m/s Maximum descent speed: 1m/s Maximum horizontal flight speed: 5m/s Flight time: about 10 minutes Working environment temperature: 0°C ~ 40°C Positioning system: optical flow positioning Operating frequency: 2.402 - 2.483GHz Camera Lens: FOV 78°... -
Page 13: Appendix
Appendix Solutions Problems Causes Turn on the aircraft and the The frequency of the remote Do the frequency matching remote control, the tail light will control is not matched with the again. keep on red. But there is no aircraft successfully. reaction during operation. -
Page 14: Disclaimer And Notice
Disclaimer and Notice The product is not a toy, but a precise equipment integrating mechanical, electronic, aerodynamics, high-frequency emission and other professional knowledge. It needs correct assembly and debugging to avoid accidents. The user must use a safe way to operate the drone. Improper operation may cause serious personal injury or property damage. -
Page 15: Warning And Tips
Warning and Tips 1. The package and instructions contain important information and should be properly kept. 2. It is your responsibility to ensure that this drone will not cause injury and property loss. 3. Our company and retailers shall not be responsible for any loss, damage and human injury caused by improper use or operation. - Page 16 This equipment should be installed and operated with a minimum distance of 20cm between the radiator&your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Name Wisp Model DSDR07A Manufacturer Deepsea Excellence Technology Co., Ltd.
- Page 17 Contents "flashes alternately red and green" and turns green after calibration. features of Wisp and the names of various parts of aircraft and remote control. In As shown in the Picture, connect the adapter correctly to charge the battery. When...
