NETWORK CAMERA
User Manual
ZNE-8020RV/ZNO-8020RV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZNE-8020RV and is the answer not in the manual?

Questions and answers

Related Manuals for Wisenet ZNE-8020RV

Summary of Contents for Wisenet ZNE-8020RV

  • Page 1 NETWORK CAMERA User Manual ZNE-8020RV/ZNO-8020RV...

  • Page 2: Table Of Contents

    Overview of Camera Contents overview of Camera Safety Instruction What’s Included (ZNE-8020RV) What’s Included (ZNO-8020RV) Part Names and Functions (ZNE-8020RV) Part Names and Functions (ZNO-8020RV) installation & ConneCtion Precautions Installing The Camera (ZNE-8020RV) Installing The Camera (ZNO-8020RV) Connect NVR network ConneCtion and setup...

  • Page 3: Safety Instruction

    safety instruCtion Please carefully read the following safety instruction so as to avoid personal injuries and prevent the equipment and other connection devices from being damaged. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5.

  • Page 4: What's Included (Zne-8020Rv)

    Overview of Camera what’s inCluded (Zne-8020rv) Please check if your camera and accessories are all included in the product package. Appearance Item Name Quantity Description Camera Instruction book, Installer S/W CD Quick Guide Template Product installation guide Tapping Screw Used for installation on the wall or ceiling...

  • Page 5: What's Included (Zno-8020Rv)

    what’s inCluded (Zno-8020rv) Please check if your camera and accessories are all included in the product package. Appearance Item Name Quantity Description Camera Instruction book, Installer S/W CD Quick Guide Tapping Screw Used for installation on the wall or ceiling For fixing a screw, Inserted in a hole Plastic Anchor (reinforced anchoring force)

  • Page 6: Part Names And Functions (Zne-8020Rv)

    Overview of Camera part names and funCtions (Zne-8020rv) Name Description Head A part that contains the lens and the internal body. Fixing Cover A cover placed over to fix its position after the head direction has been adjusted. Bottom case This is used to install a camera on the ceiling.

  • Page 7: Part Names And Functions (Zno-8020Rv)

    part names and funCtions (Zno-8020rv) Name Description Lens 4mm focal length enables you to monitor at a wider field of view Illumination Sensor Detects incoming light to control the IR LED. Power Cable Connect with the power supply DC12V. Network Port Used to connect the PoE or Ethernet cable for network connection.

  • Page 8: Precautions

    • For safety purposes, keep anyone else away from the installation site. And put aside personal belongings from the site, just in case. installing the Camera (Zne-8020rv) 1. Choose an installation site that can sufficiently support the weight of the camera to be installed.
  • Page 9 how to connect the rJ45 waterproof cable to a lan cable 1. Insert it through the arrow direction. 2. Connect the LAN connector (male) to the cable. 3. Connect the RJ45 modular jack (female) to the RJ45 connector (male). RJ45 connector (male) Please, keep each of the parts separated.

  • Page 10: Installing The Camera (Zno-8020Rv)

    installation & connection installing the Camera (Zno-8020rv) The camera can be installed on the wall, ceiling, shelf or a desired position using the provided mounting bracket. 1. Choose an installation site that can sufficiently support the weight of the camera to be installed. 2.

  • Page 11: Connect Nvr

    3. Connect the RJ45 modular jack (female) to the RJ45 connector (male). RJ45 connector (male) Please, keep each of the parts separated. RJ45 modular jack (female) Rubber ring 4. Assemble by rotating the RJ45 modular jack (female) and the RJ45 protection cover RJ45 connector protection cover clockwise (Follow the arrow).

  • Page 12: Device Connection

    network connection and setup network connection and setup deviCe ConneCtion IP camera can be connected in two ways: Connection to pC Connect IP camera to PC via straight-through network cable, with power input connected to a DC 12V adaptor, and set the IP addresses of the PC and IP camera in one network segment.

  • Page 13: Device Operation Instructions

    deviCe operation instruCtions Check Connection 1. The default factory IP address for IP camera is 192.168.1.168 and the subnet mask is 255.255.255.0. Allocate to your computer an IP address in the same network segment as the IP camera, for example, 192.168.1.69, and a same subnet mask as that of the IP camera.
  • Page 14 network connection and setup online device searching procedure 1. Run Device Search by double clicking icon [ ]. It will search and display any online network camera and its IP address, port number, number of channels, device type and version, subnet mask, gateway, MAC address and connection pattern.

  • Page 15: Installing Webviewer Plugin

    web viewer installing webviewer plugin Before using IE (Internet Explorer) browser to access the IP camera for the first time, related plug-in components must be installed by following the procedure below: Access IP address of the IP camera to automatically load the controls from it. In a pop-up plug-in installation dialog box, choose an installation option to perform the installation process.

  • Page 16: Using The Live Screen

    using the live sCreen hij klm Component Name Function Live Moves to the Live screen. Remote Setting Access to device setting menu, for customized setting of various device parameters. Local Settings For setting of snapshot, video file type and storage path. Help Information (including current user, Web browser and plug-in versions) Logout...
  • Page 17 local settings 1. Click <local settings> button to pop up the following dialog box 2. In this dialog box you can set video storage location, paths for download of remote file and storage of image snapshot, file type (RF by default, in H.265 encoding), capture type (BMP by default) and video recording duration.

  • Page 18: Remote Setting

    Camera Menu remote setting On the network, you can set up display, record, alarm, network and system. 1. On the live screen, click the <remote setting> button. 2. The Setup screen appears. display In this section, you are allowed to configure the camera, live view display, adjust IP camera’s image, Motion setup, privacy zone, and more.
  • Page 19 motion Go to "Remote Setting" ; "Motion" to enter into the interface. • enable : You can select whether or not to use the use. • sensitivity : Support 1-8 level, 8 is the highest level. privacy Zone Go to "Remote Setting" ; "Privacy Zone". Privacy Zone is to block certain area(s) in the camera's field of view on live video.
  • Page 20 Camera Menu record This menu allows you to configure the recording parameters. encode Go to "Remote Setting" ; "Record" ; "Encode" to enter into the interface. • resolution : This parameter defines how large the recorded image will be. • fps : This parameter defines the number of frames per second the camera will record.
  • Page 21 network general Go to "Remote Setting" ; "Network" ; "General" to enter the interface. Select the network connection option (DHCP, Static) to set the port. User can view and do the recording or backup of the video remotely. Take DHCP as an example. In this mode, the router automatically assigns IP address for the camera. After restarting the camera or DHCP server, the IP address obtained by the camera may be different.

  • Page 22: Registering With Ddns

    Camera Menu registering with ddns to register your product with the wisenet ddns 1. Visit the Wisenet DDNS web site (http://ddns.hanwha-security.com) and sign in with a registered account. 2. From the top menu bar, select <my ddns>. 3. Click the [register product] tab.
  • Page 23 e-mail Go to "Remote Setting" ; "Network" ; "Email" to enter into the menu interface. Receive or Send camera alarm Email and set parameters like Email address, SSL, Email Enable, and Interval. • email : Check to enable. • encryption: Disable, SSL, TLS and Auto optional. Auto means it can detect the encryption type automatically.
  • Page 24 Camera Menu rtsp Go to "Remote Setting" ; "Network" ; "RTSP" to enter the interface. • rtspenable : Enable or disable RTSP. RTSP is enabled by default. After it is disabled, it will not be found with ONVIF. • rtsp port : The default port number is 554, and can be changed to another value between 1024 and 65535.
  • Page 25 system general Go to "Remote Setting" ; "System" ; "General" to enter into the interface. User may set Date, Time, Date Format, Time Format and Time Zone. ntp settings • enable ntp : Enable/Disable NTP function. • server address : Select NTP server (time.windows.com, time.nist.gov, pool.
  • Page 26 Camera Menu maintenance Go to "Remote Setting" ; "System" ; "Maintenance" ; "Log". User may search log information in different period of time. load default Go to "Remote Setting" ; "System" ; "Maintenance" ; "Load Default" to enter into the interface. If [Load Default] is selected, you can initialize the system to the ex-factory default.
  • Page 27 auto reboot Go to "Remote Setting" ; "System" ; "Maintenance" ; "Auto Reboot" to enter into the interface. Enable the auto maintenance function to reboot system regularly at every day/ week/month. When Auto Reboot is enabled, camera should be in the main interface and no user operation.

  • Page 28: Troubleshooting

    Appendix Appendix troubleshooting PROBLEM SOLUTION • On the authentication popup window prompted when initially accessing https, click "View Authentication Certificate" and select the "Always trust when connecting to the designated webviewer IP" check box. No video is displayed when accessing the • If the webviewer continues failing to display a video after you select "Next"...

  • Page 29: Specifications

    Details Item ZNE-8020RV ZNO-8020RV Imaging Device 1/2.7 Effective Pixels 2592(H) x 1944(V) Video Scanning System Progressive Min. Illumination 0Lux (IR LED ON) Focal Length (Zoom Ratio) Fixed 4mm Max. Aperture Ratio F2.0 Lens Angular Field of View D:100 H:76° V:57°...
  • Page 30 Appendix Details Item ZNE-8020RV ZNO-8020RV Streaming Method Unicast Max. User Access Max 7 (admin+user) Application Programming Network ONVIF Profile S, CGI(raysharp protocol) Interface Supported Browser : Microsoft Internet Explorer (Ver. 11,10,9,8), Mozilla Firefox Ver 51.x or lower, Google Web Viewer Chrome Ver 44.x or lower, Safari®11.1.1 or lower...

  • Page 31: Dimension

    Zne-8020rv Unit: mm (inch) Ø75(2.95") Ø100(3.94") Ø100(3.94") English _31...
  • Page 32 Appendix Zno-8020rv Unit: mm (inch) 114.3(4.5") 64.8(2.55") 32_ Appendix...
  • Page 33 Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Techwin's devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
  • Page 34 Compuage Infocom LTD Head Office Address : D-601/602&G-601/602, Lotus Corporate Park, Graham Firth Steel Compound, Western Express Highway, Goregaon (E), Mumbai -400 063. India Phone : +91-22-67114444 www.compuageindia.com Compuage Infocom LTD Service Center Address : Geetha Industrial Estate, Gala No: 8,9,10 & 11, First Floor, Navghar, Vasai East, District- Palghar, Pin: 401210, India.
