- Page 1 AHD SPEED DOME CAMERA Quick Guide HCP-6320A/HCP-6320HA...
-
Page 2: Safety Information
safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER CAUTION: SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit. - Page 3 5. Keep out of direct sunlight and heat radiation sources. It may cause fire. 6. Install it in a place with good ventilation. 7. Avoid aiming the camera directly towards extremely bright objects such as sun, as this may damage the CMOS image sensor.
-
Page 4: Important Safety Instructions
important safety instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 5: What's Included
What’S InCLuDeD Check if the following items are included in the product package. Appearance Item Name Quantity Description Applicable Model Indoor Model (HCP-6320A) Main Body Environmental Model (HCP-6320HA) Multilingual User Manual and CD Manual Quick Guide User Manual or Quick... -
Page 6: Component Names And Functions
COMPOnent naMeS anD FunCtIOnS hCP-6320a hCP-6320ha Item Description Main unit Protects the internal PTZ mechanism from the direct sunlight or external impact. Dome Cover Dome cover for the lens and unit protection. After Service Port This is for the repair purpose only that is not available for the user. - Page 7 Bottom View of Installation Base Inner View of Installation Base Response Item Description Alarm I/O Port Used to connect the alarm I/O cable. Power Port Used to connect the power. Communications Used for RS-485/422 communications. Ports Video Out Port Analog video output port. (for installation) Communications Set the transfer rate and protocols.
-
Page 8: Osd Menu Chart
OSD Menu Chart You can have an overall view of the menu structure. For more information, refer to the applicable page or section in the manual. Zoom/Focus White Balance Exposure Back Light Camera Setting SSNR SSDR Day & Night Preset Others Swing SEQ Group SEQ Sequence Setting Tour SEQ PTZ Trace Auto Run... - Page 9 Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Techwin's devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
