Wisenet SNH-V6435DN User Manual

Smartcam d1
Hide thumbs Also See for SNH-V6435DN:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
SMARTCAM D1
User Manual
SNH-V6435DN
0678
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SNH-V6435DN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wisenet SNH-V6435DN

Summary of Contents for Wisenet SNH-V6435DN

  • Page 1 SMARTCAM D1 User Manual SNH-V6435DN 0678...

  • Page 2: User Manual

    SPECIFY SERVICE INSTRUCTIONS AND WARRANTY TERMS FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 Instructions & Warranty • Accessories and small parts of the product should be stored keeping out of children’s reach. The manufacturer is not responsible for any loss or radio/TV interference caused by • The product is not designed to replace responsibility of human supervision on children. unauthorized modification of the product.

  • Page 4: Table Of Contents

    Contents GEttInG StaRtEd appEndIx Features ……………………………………………………… 5 Specifications ………………………………………………… 17 What’s Included ……………………………………………… 6 Troubleshooting ……………………………………………… 21 Part Names and Functions …………………………………… 7 InStallatIon & nEtwoRk ConnECtIon Installation …………………………………………………… 9 Network Connection and Settings …………………………… 15...

  • Page 5: Features

    Features • Easy to install - The Wi-Fi Direct button allows easy connection to a wireless router. • Remote monitoring - You can monitor your SmartCam D1 remotely, at any time and from any location, using your smartphone. • Real-time alarm - When the bell rings, a push alarm is sent to the smartphone.

  • Page 6: What's Included

    What’s Included Check for components when opening the product package. SmartCam D1 Quick Start Guide (Option by region) Warranty Card GPL Lisence Faceplate (Gold/Silver/Black) Faceplate Screws Security Screws / Plastic Anchors Drill bit Screw Driver Power Stabilizer Power Stabilizer Cable Power Extender Cables Connector 6 ·...

  • Page 7: Part Names And Functions

    Part Names and Functions Front Rear Faceplate It can be replaced with a cover, which is additionally provided. Microphone lEd Status Indicator power Input Bell Button Connect it to an AC power cable.

  • Page 8: Side

    Side Components Illumination Sensor wiFi direct Button Wi-Fi is used for wireless communication between product and smartphone. Reset Button Resets the product settings to the factory default. The system restarts if you press the button for 10 seconds using a pointed object such as a needle.

  • Page 9: Installation

    Installation precautions As this product works on a Wi-Fi network, video receiving may be unstable if & there is an obstacle (metal, wall, door) in the use environment, or if the nStallation product is receiving interference from another Wi-Fi device nearby. Install the station hub and the camera at a position that ensures good video reception, considering the Wi-Fi network environment.

  • Page 10: Items To Check Before Installation

    Items to check before installation Cautions before installation Before you start, you must turn off the circuit breaker for safety • Question Answer purposes. • It only can be installed at 16-24V AC power with the existing chime bell. What types of walls Wood, Brick, Concrete, and Stucco walls are appropriate.
  • Page 11 Use a screwdriver to loosen the screws Repeat Step 5 for the [trans] cable. on the [FRont] and [tRanS] terminals and then remove the cables. Make sure to label the terminal cables before disconnecting them. You will need to connect them to the terminal blocks later.

  • Page 12: Mounting The Smartcam D1

    Mounting the SmartCam d1 Unscrew one of the power terminals on the back of your SmartCam D1, and wrap the existing wiring from your doorbell around the terminal, and then tighten the screw. disassembling It doesn't matter which cable you use on which side of the terminal back.
  • Page 13 Check the Diagrams below to make sure the Power Stabilizer and SmartCam D1 are properly installed. Trans ❖ power connection structure 110V - In the existing installation structure, a power stabilizer is removed from Transformer the figure. Front - Connect two cables (black/white) with two terminals of the Chime Bell, Power 16V~24V/10VA Stabilizer...

  • Page 14: Web Install

    Install In a location with a strong Wi-Fi signal and no interference, use Wi-Fi communication. With the Wisenet SmartCam+ app, users can monitor the SmartCam D1 from a mobile device. ❖ lEd status Go to Google Play/App Store and search for “wisenet SmartCam+”.
  • Page 15 assemble ❖ Bell lEd Status Bell LED indicator shows operational status with blinks. Once you are finished with the in-app setup for the Refer to table below for detailed meaning of the LED indicator. SmartCam D1, attached the faceplate back on. Bell LED Status Normal Status...

  • Page 16: Network Connection And Settings

    Connection using the wi-Fi direct function Network Connection and Settings What is Wi-Fi Direct? precautions If you use Wi-Fi Direct, the product can be connected to the router without using wires. Connect the power adapter to the product. • The wireless network access may fail, depending on the communications environment.

  • Page 17: Specifications

    Specifications Specifications Item Description Video ppendix Imaging Device 1/2.8" CMOS Min. Illumination B/W : 0 Lux with IR Lens Angular Field of View(H / V / D) H : 125˚ / V : 94.8˚ / D : 150˚ Lens Distortion Correction Support Specifications Operational...
  • Page 18 Item Description Item Description Environmental Digital Zoom 4x(Mobile) Flip / Mirror Off / On Operating Temperature / Humidity -20°C ~ 40°C / Less than 90% RH Intelligent Video Analytics Face Recognition, Human Detection, Motion Zone Selection Storage Temperature / Humidity -30°C ~ +50°C / Less than 90% RH Abnormal sound detection Siren, Glass breaking, Screaming...
  • Page 19 product appearance unit: mm (inch)
  • Page 20 Home Chime Compatibility list ❖ Compatible chime ❖ Incompatible chime Chime type Manufacturer Model Description Chime type Manufacturer Model Description C210 Heath-Zenith SL-2796 Edwards C210-W Mechanical DH506 Carlon Nicor 18888 DH120 Craftmade C102X2L Electrical NuTone LA174WH Edwards C212W-2L (for RCW110N) Common : AC16(1), Smartcam D1(1) RCW100N Transformer : AC16(3), Power...

  • Page 21: Troubleshooting

    Problem Action I want to change my - Change the account information after logging into Wisenet SmartCam+. - Move to “Log-in page  Forgot your ID/Password?”, and enter the password and/or For more details, refer to the mobile guide.
  • Page 22 Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Techwin's devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive. Correct Disposal of This Product (Waste Electrical &...
  • Page 23 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.wisenetlife.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Tel +1.877.349.3149 www.wisenetlife.com Hanwha Techwin Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom Tel#1 00800.801.08022 Tel#2 +31.77.326.1580 www.wisenetlife.com...
