- Page 4 1. Place the top panel (#1) face down onto a protected surface, then align the legs (#2) to the holes along the corners. 2. Insert 2 bolts (#A) into each corner and secure using the Allen wrench. Align the middle shelf (#3) face down to the holes along the sides of the legs (#2).
- Page 5 Align the bottom shelf (#4) face down to the holes along the bottom of the legs (#2). Insert a bolt (#B) into each corner, then secure using the Allen wrench (#C). Align the leg supporter (#5) to the holes along the bottom shelf, then insert 2 bolts (#A) and secure using the Allen...
- Page 6 Align the back supporters (#6) to the holes along the back of the TV stand, make an "X" formation, then insert a bolt (#A) into each end. Secure using the Allen wrench (#C). ASSEMBLY IS COMPLETED...
