VERSION # 19-08-09
1 / 11
MODEL #
CM5677TV
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Phillips
Screwdriver
(Not Included)
2 - Persons
Recommended
EASY
DIFFICULT
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
Advertisement
Related Manuals for Furniture of America CM5677TV
Summary of Contents for Furniture of America CM5677TV
- Page 1 MODEL # CM5677TV Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Phillips Screwdriver (Not Included) 2 - Persons Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 11...
- Page 5 TV CHEST CM5677TV #1 1pc #2 1pc #3 1pc #4 1pc Back Panel Partition Panel Left Side Panel Right Side Panel #8 1pc #7 1pc #5 2pcs #6 1pc Bottom Frame Upper Board Top Panel Front Frame #11 2pcs #10 4pcs...
-
Page 6: Exploded View
Exploded View 6 / 11... - Page 7 ASSEMBLY INSTRUCTIONS Attach legs (#10) to the bottom frame (#8). Part #8 x1pc Part #10 x4pcs Align and attach side panels (#1,4) and partition panel (#3) to the bottom frame (#8). Part #1 x1pc Part #3 x1pc Part #4 x1pc 7 / 11...
- Page 8 ASSEMBLY INSTRUCTIONS Align and attach front frame (#7) to the panels (#1,4). Part #7 x1pc Align and attach back panel (#2) to the partition panel (#3). Part #2 x1pc 8 / 11...
- Page 9 ASSEMBLY INSTRUCTIONS Align and slide the side rear panels (#11) through the gaps of the side panels (#1,4) and back (#2). Part #11 x2pcs Attach shelf pins (#C) to the desired height of the shelves (#9). Part #9 x2pcs Hardware #C x8pcs 9 / 11...
- Page 10 ASSEMBLY INSTRUCTIONS Attach shelf pins (#C) to the product, then place shelves (#5) onto shelf pins. Part #5 x2pcs Hardware #C x8pcs Part #6 x1pc Align and attach the top panel (#6) through the latches. 10 / 11...
- Page 11 ASSEMBLY INSTRUCTIONS Adjust levelers of the legs according to ground level. Secure knobs (#A) to doors by Part #A x2pcs using bolts (#B). Part #B x2pcs 11 / 11...
