ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM5233
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
Rev: 16-10-07
Advertisement
Related Manuals for Furniture of America CM5233
Summary of Contents for Furniture of America CM5233
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM5233 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 12pcs #1 x 1pc TV stand Wood Screws M4 x 3/4" #B x 11pcs #2 x 1pc Left Hucth Allen Bolts Ø1/4"...
- Page 4 Align the center rails (#8) to the holes along the bottom rail (#7), then insert the allen bolts (#C) into each hole. Secure using the Allen wrench (#D). #C x 2pcs 1. Place the right and left hutch (#2,3) onto the TV stand (#1).
- Page 5 Slide the back panels (#4) and center back panel (#5) along the ridges. #C x 2pcs Align the top rail (#6) to the top, then insert the Allen bolts (#C) into each hole and secure. Page 5 of 6...
- Page 6 Place the top hutch (#9) on top, align the holes, then insert the Allen bolts (#B) and secure using the Allen wrench. #B x 8pcs #A x 8pcs #B x 3pcs #E x 4pcs Align the brackets (#E) to the holes along the back, then insert the wood screws (#A) and secure using a screwdriver.
