Ordering Information; User Information; Power; Configuration - Avnet Xilinx Virtex-II User Manual

1.4

Ordering Information:

The following table lists the Development system part numbers and available software options. Internet link at:
http://www.ads.avnet.com
2.0

User Information

This section provides the user with information on how to get started using the Virtex-II Development board. It discusses
how to apply power to the board, configure the FPGA devices and set-up the jumpers.
2.1

Power

The Virtex-II Development Board is powered via the +5.0 volt PCI. However, it may be operated in stand-alone mode. In
stand-alone mode the Virtex-II board may be powered by an external power supply connected to the J1 barrel socket
connector. The supply should have a minimum of 2 AMP, +5.0 Volts regulated to +/- 5%. The current requirements for
the board are application specific.
2.2

Configuration

The Virtex-II Development board supports Boundary-scan as well as System ACE Multi-Package Module (MPM) solution. All
configuration pins are brought out to "J2", should the user wish to program with an alternate method.
Copyright © 2003 Avnet, Inc. AVNET and the AV logo are registered trademarks of Avnet, Inc. All other trademarks are property of their respective owners.
Avnet Design Services
Released
Part Number
ADS-XLX-V2-DEV1500
ADS-XLX-MB-DEV1500 with Communications/Memory Module and
ADS-XLX-V2-DEV1500XP
ADS-V2-MB-DEV1500XP
ADS-XLX-V2-DEV4000
ADS-XLX-MB-DEV4000 with Communications/Memory Module and
ADS-XLX-V2-DEV4000XP
ADS-V2-MB-DEV4000XP
ADS-XLX-V2-DEV6000XP
ADS-V2-MB-DEV6000XP

Table 1: Ordering Information

5 of 25
Hardware
Xilinx Virtex-II Development Kit populated
with an XC2V1500 device
Xilinx Virtex-II Development Kit bundled
MicroBlaze Core License
Xilinx Virtex-II Development Kit populated
with an XC2V1500 device & high-current
power supply
Xilinx Virtex-II Development Kit bundled
with Communications/Memory Module,
MicroBlaze Core License & high-current
power supply
Xilinx Virtex-II Development Kit populated
with an XC2V4000 device
Xilinx Virtex-II Development Kit bundled
MicroBlaze Core License
Xilinx Virtex-II Development Kit populated
with an XC2V4000 device & high-current
power supply
Xilinx Virtex-II Development Kit bundled
with Communications/Memory Module,
MicroBlaze Core License & high-current
power supply
Xilinx Virtex-II Development Kit populated
with an XC2V6000 device & high-current
power supply
Xilinx Virtex-II Development Kit bundled
with Communications/Memory Module,
MicroBlaze Core License & high-current
power supply
Rev 1.0 06/08/2004
Literature # ADS-xxxx04
