Furniture of America CM3152T Assembly Instructions

Download this manual

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

DIFFICULT

CM3152T

Tools Required For Assembly:

Allen Wrench

2 PERSONS RECOMMENDED

Page 1 of 5

(Included)

Rev:16-12-05

Need help?

Do you have a question about the CM3152T and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3152T ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult). For some Allen Wrench products, two persons are recommended.
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 16pcs Bolt Ø5/16" x 2-1/4'' Table Top #2 x 1pc #B x 16pcs Shelf Lock Washer Ø5/16"...
Page 4 Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align 3 legs (#3) to the holes of the table top (#1). Secure with bolts (#A). #A x 6pcs #B x 6pcs #C x 6pcs Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A).
Page 5 Prepare 4 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align leg (#3) to the holes of the shelf (#2) and table top (#1). Secure with bolts (#A). #A x 4pcs #B x 4pcs #C x 4pcs ASSEMBLY IS COMPLETED Page 5 of 5...
