VERSION # 20-03-10
1 / 7
MODEL #
CM3152PC-2PK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Table of Contents
Related Manuals for Furniture of America Meagan CM3152PC-2PK
Summary of Contents for Furniture of America Meagan CM3152PC-2PK
- Page 1 MODEL # CM3152PC-2PK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 7...
- Page 5 HEIGHT CHAIR CM3152PC-2PK PARTS PARTS PARTS #1 1pc #2 1pc #3 2pcs #4 1pc #5 2pcs Chair Back Cushion Seat Leg(L&R) Front Leg Support Leg Support (L&R) HARDWARE HARDWARE #A 4pcs #B 4pcs #C 3pcs #D 11pcs Lock washer Bolt Ø1/4"x3-1/4" Bolt Ø1/4"x2-1/4"...
- Page 6 ASSEMBLY INSTRUCTIONS Prepare 3 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#C). Align seat cushion (#2) to the holes of the chair back (#1), then secure with bolts (#C). Part #1 x1pc Part #2 x1pc Hardware #C x 3pcs Hardware #D x 3pcs Hardware #E x 3pcs...
- Page 7 ASSEMBLY INSTRUCTIONS Prepare 4 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#B). Align front legs (#3R/L) to the holes of the cushion seat (#2), then align the leg supports (#4,5) to the Part #3 x2pcs gaps of the legs.
