- Page 1 MODEL # CM3150SC-2PK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product. VERSION # 20 - 02 -1 2 1 / 8...
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 8...
- Page 5 SIDE CHAIR CM3150SC-2PK #1 1pc x2 #2 1pc x2 #3 2pcs x2 Chair Back Font Leg Seat #A 4pcs x2 #B 4pcs x2 #C 1pc x2 #D 9pcs x2 Bolt Ø5/16 x 3" Bolt Ø5/16" x 2" Bolt Ø5/16" x 1-5/8" Lock washer Ø5/16"...
- Page 6 Exploded View 6 / 8...
- Page 7 ASSEMBLY INSTRUCTIONS Align seat (#2) to the chair back (#1), then secure by using bolts (#A) with washers (#D,E). Part #1 x1pc Part #2 x1pc Hardware #A x4pcs Hardware #D x4pcs Hardware #E x4pcs Hardware #C x1pc Secure middle hole of the seat to chair Hardware #D x1pc back by using bolts (#C) with washers...
- Page 8 ASSEMBLY INSTRUCTIONS Align front legs (#3) to the seat, then secure by using bolts (#B) with washers (#D,E). Part #3 x2pcs Hardware #B x4pcs Hardware #D x4pcs Hardware #E x4pcs 8 / 8...
