For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3156PT
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 10
(Included)
(Not Included)
Rev: 11-06-23
Advertisement
Related Manuals for Furniture of America CM3156PT
Summary of Contents for Furniture of America CM3156PT
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3156PT ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 10...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #8 x 1pc Table Top Short Stretcher #9 x 1pc #2 x 1pc Top Panel Side panel and back panel #3 x 1pc...
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 8pcs #H x 5pcs Bolt Ø5/16"x2-3/8" Flat Washer Ø1/4"x13 #I x 2pcs #B x 8pcs Screw #4x50mm Lock Washer Ø5/16"...
- Page 5 Exploded View Unfold side/back panel (#2). #D x 4pcs #F x 4pcs #G x 4pcs Secure by using bolts (#D) with washers (#F,G). Align top and bottom panel (#9,10) to the side/back panel (#2). Page 5 of 10...
- Page 6 Align panel (#12) to the unit. #E x 1pc #F x 1pc #H x 1pc #K x 2pcs Align middle panel (#11) to the holes of panels (#9,10,12). Secure hole of middle panel (#11) to top panel (#9) by using bolts (#E) with washers (#F,H).
- Page 7 Align the shelving unit (#2) to the holes of the table legs (#4,5), then secure by using bolts (#D) with washers (#F,H). #D x 4pcs #F x 4pcs #H x 4pcs Secure shelving unit (#2) to table top (#1) by using bolts (#D) with washers (#F,G).
- Page 8 Align table leg (#6) to the table top (#1), then secure by using bolts (#A) with washers (#B,C). #A x 2pcs #B x 2pcs #C x 2pcs Align stretcher (#7,8) to the holes and brackets as shown in the diagram. Secure long stretcher to shelving unit (#2) by using bolts (#E) with washers (#F,G).
- Page 9 Align table leg (#3) to the table top (#1) and short stretcher (#8). Secure short stretcher (#8) to table legs (#3,6) by using screws (#I). #A x 2pcs #B x 2pcs #C x 2pcs #I x 2pcs Secure table leg (#3) to table top (#1) by using bolts (#A) with washers (#B,C).
- Page 10 Attach panels (#14) together, then slide the panels (#14) into the shelving unit. ASSEMBLY IS COMPLETED Page 10 of 10...
