ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3152RPT
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 5
(Included)
Rev:16-12-05
Advertisement
Table of Contents
Related Manuals for Furniture of America CM3152RPT
Summary of Contents for Furniture of America CM3152RPT
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3152RPT ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult). For some Allen Wrench products, two persons are recommended.
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 16pcs Bolt Ø5/16" x 2-1/4'' Table Top #2 x 2pcs #B x 16pcs Lock Washer Ø5/16"...
- Page 4 Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align 3 legs (#3) to the holes of the table top (#1). Secure with bolts (#A). #A x 6pcs #B x 6pcs #C x 6pcs Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A).
- Page 5 Prepare 4 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align leg (#3) onto the holes of the shelves (#2) and table top (#1). Secure with bolts (#A). #A x 4pcs #B x 4pcs #C x 4pcs Once table to expanded, make sure to pull the slider to the extra table space to hold it.
