- Page 1 OPERATOR’S MANUAL Granita Merchandising Freezers Model 369 (FBM 1P) Model 370 (FBM 2) Model 371 (FBM 3) ROCKTON, ILLINOIS 61072...
- Page 2 Complete this page for quick reference when service is required: Taylor Distributor:__________________________________________________________ Address:_________________________________________________________________ Phone:___________________________________________________________________ Service:__________________________________________________________________ Parts:___________________________________________________________________ Date of Installation:_________________________________________________________ Model Number:____________________________________________________________ Information found on identification label: Serial Number:____________________________________________________________ Information found on data plate: Electrical Specs: Voltage ____________________________ Cycle________________________________ Phase__________________________________________________________________...
-
Page 3: Table Of Contents
Note: Continuing research results in steady improvemenets; therefore, information in this manual is subject to change without notice. This dispenser is manufactured under one or more of the following U.S.patents and/or other pending patents: U.S.A. 4,900,158 U.S.A. 4,696,417 U.S.A. 5,713,214 U.S.A. 5,906,105 Models 369/370/371... -
Page 4: Technical Characteristics
( c h a p t e r 1 - Remove the corrugated container and packing materials 5.3 CLEANING AND SANITIZING PROCEDURES). Models 369/370/371... -
Page 5: To Operate Safely
2 5 OPERATING PROCEDURES In addition all the models except 369 are equipped with an automatic safety pressure switch to prevent damages to the 1 - Clean and sanitize the unit according to the instructions in compressor. -
Page 6: Operation Helpful Hints
Overnight operation in drink mode also 1 - Remove cover from the bowl. eliminates possible ice accumulation from condensation around the bowls. 2 - On 369 MODEL remove the lateral tray by lifting its outer Models 369/370/371... - Page 7 4 - Slide the outer spiral out (see figure 9) and then the inside figure 6 auger (see figure 10). 3 - Remove the bowl by lifting its faucet side up and off the fastening hooks (see figure 7) and slide it out (see figure figure 9 figure 7 figure 10 Models 369/370/371...
-
Page 8: Cleaning
Prior to any cleaning or sanitizing procedure hands washing is required. figure 13 1 - Prepare at least two gallons of a mild cleaning solution of warm (45-60 °C / 120-140 °F) potable water and 3 - Assemble the faucet by reversing the disassembly steps Models 369/370/371... -
Page 9: In-Place Sanitization
(see figure 14). figure 17 figure 14 8 - On 369 MODEL install the lateral tray by reversing the disassembly steps (see figure 6). 5 - Carefully insert the auger into the evaporator use caution 9 - Use fresh product to chase any remaining sanitizer from to prevent it from hitting the rear wall (see figure 15). -
Page 10: Maintenance (To Be Carried Out By Qualified Service Personnel Only)
1 - Set the time of the day by rotating the dial clockwise (arrow Condenser fins are very sharp. Use extreme caution A). Never rotate the timer counterclockwise as this when cleaning. would damage the internal machanism. Align the current Models 369/370/371... - Page 11 15 minutes. A minimum of four to eight hours are required to defrost frozen beverage (depending on ambient conditions). Note: when all the tabs are pushed in the defrost function is OFF (the machine operates as if it were not equipped with Defrost Timer). Models 369/370/371...
- Page 12 OPERATOR PARTS IDENTIFICATION 2471_01 V 3.5 04I09 MODEL 369/370/371...
- Page 13 046461-1 Pin-Pivot (Black) 31 053151-27 Coil-Solenoid Valve (220V 60Hz) 057878 O-Ring - Gear Shaft (4th) 062250 rubber cap 059558 Damper-vibration *369-371 048872 Stainless steel fixing screw for panel Thrust washer 046463 Gasket-Hopper 046486 Screw-Viscosity Adjustment 66 052213-34 Gear-Motor-Generation III (230V 50Hz)
- Page 14 GEAR MOTOR 052213-12 Motor-Gear *369,370,371* GEN 3 052213-27 (Magnetic Drive - BR 0067955/Up) 052213-34 052213-44 Include: 052042 Bracket-Gear Motor w/Bushing 052047 Cap-Ball Bearing 052052 Gasket-Gear Motor 057900 Stator-Gear Motor (230V / 50Hz) 057878 O-Ring-Gearshaft 052053 Cover-Gear box 057901 Stator-Gear Motor (220V / 60Hz)
- Page 15 Inspect & Replace as Necessary Draw Valve O-Ring IMPORTANT: The display light bulb must be replaced with the factory authorized replacement bulb. Failure to comply may result in component damage or severe personal injury due to broken glass. Models 369/370/371...
- Page 16 046445-M 2471_01 R0.4 04I09...
