Taylor 340 Operating Instructions Manual
  1. Manuals
  2. Brands
  3. Taylor Manuals
  4. Freezer
  5. 340
  6. Operating instructions manual
Taylor 340 Operating Instructions Manual

Taylor 340 Operating Instructions Manual

Slush freezers
Hide thumbs Also See for 340:
Table of Contents

Advertisement

Quick Links

See also: Operator's Manual
Models 340, 341, 342
Slush Freezers
Operating Instructions
028764- -M
1/97

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 340 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Taylor 340

Summary of Contents for Taylor 340

  • Page 1 Models 340, 341, 342 Slush Freezers Operating Instructions 028764- -M 1/97...
  • Page 2 Minimum Wire Ampacity: E January, 1997 Taylor All rights reserved. 028764--M Taylor Company The word Taylor and the Crown design 750 N. Blackhawk Blvd. are registered trademarks in the United States Rockton, IL 61072 of America and certain other countries.

  • Page 3: Table Of Contents

    ............Note: Continuing research results in steady improvements; therefore, information in this manual is subject to change without notice. Table of Contents Models 340, 341, 342...
  • Page 4 Notes: Table of Contents Models 340, 341, 342...

  • Page 5: To The Installer

    Beater rotation must be clockwise as viewed looking Air Cooled Units into the freezing cylinder. The model 340 air cooled unit requires a minimum of Note: The following procedures should be performed 6” (152 mm) of clearance around both sides of the by a trained service technician.

  • Page 6: To The Operator

    It should also be noted that Taylor does not warrant the refrigerant used in its equipment. For example, if the In the event you should require technical assistance, refrigerant is lost during the course of ordinary service please contact your local authorized Taylor Distributor.

  • Page 7: Safety

    Models 341/342: 3” (76 mm) minimum air space on all sides. DO NOT operate the freezer unless it is Model 340: 6” (152 mm) minimum air space on sides properly grounded. and 0” at the rear. It is recommended to install a skirt...

  • Page 8: Operator Parts Identification

    X38458 Panel-Right Side 047007 Gasket-Hopper Cover 038375 Panel-Rear 047008 Tube-Feed 015176-9 Panel-Left Side 047006 Skirt-Air Flow 049069 Leg-4” 013458 Pan-Drip 19-1/2 Long 035034 Louver-Side 013631 Tray-Drip 013690 Panel A.-Front X46881 Shield-Splash 022763 020729 Operator Parts Identification Models 340, 341, 342...
  • Page 9 Gasket-Hopper Cover 038375 Panel A.-Lower Side (Left/Right) X24397 Tube-Feed 015176-9 Wheel-Caster 018794 Panel-Upper Side (Left/Right) 024576 Panel-Service 013638-SP1 Pan-Drip 035034 Louver-Side (Left/Right) 013631 Tray-Drip 013690 Panel A.-Front X46881 Shield-Splash 022763 Adapter A.-Caster X18915 020729 Models 340, 341, 342 Operator Parts Identification...
  • Page 10 Louver-Side (Left/Right) 017471 Panel-Upper Left Side 028700 Panel-Rear 017563 Pan-Drip 027503 Panel-Upper Right Side 028701 Tray-Drip 014533 Panel A.-Lower Left Side X44853 Shield-Splash 037041 Panel A.-Front X25807 Panel-Service 024439-SP1 Adapter A.-Caster X18915 020729 Operator Parts Identification Models 340, 341, 342...
  • Page 11 Models 340, 341, 342 Beater Door Assembly Item Description Part No. Item Description Part No. Door A.-Partial X39248 Bearing-Front 013116 Handle A.-Draw-Slush X25124 Beater A.-7 QT-1 Pin Support X46233 Valve-Draw 047734 Clip-Scraper Blade*8.75”* 046238 Valve A.-Handle Pin X25929 Torque Arm 014500 O-Ring-1 OD x .139 W...
  • Page 12 Accessories Item Description Part No. Kit A.-Tune Up X39969 Brush-Rear Bearing 013071 Brush-Double Ended 013072 Brush-Mix Pump Body 023316 Lubricant-Taylor Lube 047518 Brush-Draw Valve 013073 Cap-Restrictor 020213 Operator Parts Identification Models 340, 341, 342...

  • Page 13: Important: To The Operator

    To better communicate in the International arena, the words on many of our operator switches and buttons The Models 340 and 341 come equipped with an have symbols to indicate their functions. Your Taylor optional rack assembly and four syrup jars. Each syrup equipment is designed with these International jar holds 16 ounces (453.6 grams) of syrup.

  • Page 14: Operating Procedures

    “OFF” POSITION. Failure to do so may cause injury from electrocution or hazardous moving parts . Note: When lubricating parts, use an approved food grade lubricant (example: Taylor Lube). Step 1 Install the beater drive shaft. Slide the o-ring into the first groove on the drive shaft.
  • Page 15 Place the white, plastic guide bearing on the rear of the rotor shaft. DO NOT lubricate the guide bearing. Figure 8 020807 Models 340, 341, 342 Operating Procedures...
  • Page 16 Place the large rubber gasket into the groove on the back side of the freezer door. Figure 10 Insert the ice buster through the door spout and into Figure 13 the slot located just above the lower o-ring. Figure 11 Operating Procedures Models 340, 341, 342...
  • Page 17 Insert the torque arm between the draw valve spout supports and into the hole in the baffle assembly. Note: During operation, the torque arm rests on the spout support. Figure 18 Models 340, 341, 342 Operating Procedures...

  • Page 18: Sanitizing

    Kay-5R). USE WARM WATER AND FOLLOW THE MANUFACTURER’S SPECIFICATIONS. Step 2 Pour the two gallons (7.6 liters) of sanitizing solution into the hopper and allow it to flow into the freezing cylinder. Figure 23 Operating Procedures Models 340, 341, 342...

  • Page 19: Priming

    Stand the air When the slush product has stopped bubbling down tube in the corner of the hopper. into the freezing cylinder, install the air tube in the mix inlet hole. Figure 25 Figure 27 Models 340, 341, 342 Operating Procedures...

  • Page 20: Closing Procedure

    Step 4 Place the hopper cover into position. Figure 30 Closing Procedure To disassemble the Models 340, 341, and 342, the following items will be needed: Two cleaning pails Sanitized stainless steel rerun can with lid Necessary brushes (provided with the...

  • Page 21: Draining Product From The Freezing Cylinder

    If local health codes permit, empty the rerun into the rerun can. Cover the container and place it in Repeat this procedure until the rinse water being the walk-in cooler. drawn from the freezing cylinder is clear. Models 340, 341, 342 Operating Procedures...

  • Page 22: Cleaning

    Step 3 and place the control switch in the “OFF” position. While the solution is flowing into the freezing cylinder, brush clean the mix hopper and the mix inlet hole. Figure 36 Figure 38 Operating Procedures Models 340, 341, 342...

  • Page 23: Disassembly

    Note: To remove o-rings, use a single service towel to grasp the o-ring. Apply pressure in an upward direction Step 7 until the o-ring pops out of its groove. With the other Wipe clean all exterior surfaces of the freezer. Models 340, 341, 342 Operating Procedures...

  • Page 24: Important: Operator Checklist

    USE OF RERUN, make sure the rerun is stored maintenance purposes. Deteriorated in a sanitized, covered stainless steel container cracked water lines should be replaced only by and used the following day. an authorized Taylor mechanic. Important: Operator Checklist Models 340, 341, 342...

  • Page 25: Winter Storage

    Winter Storage Your local Taylor Distributor can perform this service for you. If the place of business is to be closed during the winter Wrap detachable parts of the freezer such as beater, months, it is important to protect the freezer by...

  • Page 26: Troubleshooting Guide

    Improper mixing of d. Carefully follow the -- -- directions for mixing product. product. e. There is insufficient e. Keep the hopper full of mix. product in the freezing cylinder. Troubleshooting Guide Models 340, 341, 342...
  • Page 27 “AUTO” position. the “COLD” position. Therefore, the compressor will not run. (Far Right) b. The torque arm is bent. b. Replace the torque arm. c. The condensers are dirty. c. Clean the condensers regularly. Models 340, 341, 342 Troubleshooting Guide...
  • Page 28 11. The door will not go into a. The beater assembly is a. The open end of the beater assembly should position easily. incorrectly positioned. be in the 11 o’clock position. Troubleshooting Guide Models 340, 341, 342...

  • Page 29: Parts Replacement Schedule

    Necessary White Bristle Brush, 3” x 7” Inspect & Replace Minimum if Necessary *Double quantity for the Model 342. Refer to the Parts List on page 26 when ordering the above parts. Models 340, 341, 342 Parts Replacement Schedule...

  • Page 30: Parts List

    Section 10 Parts List + Available Separately 020729 Parts List Models 340, 341, 342...
  • Page 31 + Available Separately Models 340, 341, 342 Parts List...
  • Page 32 + Available Separately Parts List Models 340, 341, 342...
  • Page 33 + Available Separately Models 340, 341, 342 Parts List...
  • Page 34 + Available Separately 040823 Parts List Models 340, 341, 342...
  • Page 35 + Available Separately 040823 Models 340, 341, 342 Parts List...

  • Page 36: Wiring Diagrams

    Models 340/341 049359 Rev. 7/02...
  • Page 37 Model 341 049359- -33 Rev. 7/02...
  • Page 38 Model 340 049359- -40 Rev. 7/02...
  • Page 39 Model 341 049359- -58 Rev. 7/02...
  • Page 40 Model 342 052720- -27 Rev. 7/02...
  • Page 41 Model 342 052720- -33 Rev. 7/02...
  • Page 42 Model 342 052720- -40 Rev. 7/02...
  • Page 43 Model 342 052720- -58 Rev. 7/02...
