Saxby Lighting 98440 Instruction Manual

Wiring

Having correctly identified the wiring from your existing light fitting, pull the mains wire through the hole and connect to the
quick fit connection block inside the product in the following way:
SUPPLY
NEUTRAL
EARTH (GREEN/YELLOW)
SWITCHED LIVE
Fitting/replacing bulbs: 1 x Max. 15W E27 GLS
• This fitting has been designed to use energy efficient LED bulbs. Ensure that the minimum
distance to the illuminated surface is not less than 0.5m (50cm).
• When changing a bulb, always switch off at the mains and allow the bulb to cool before handling. Dispose of used bulbs
carefully. Do not exceed the wattage stated or use a different shape bulb from that indicated on the fitting. Use of the incorrect
bulb will damage the product and invalidate the guarantee.

Technical data

Bulb
Supply
220-240 V~, 50 Hz
Voltage: Type:
Conformity with all relevant UKCA Directive requirements.
Conformity with all relevant EC Directive requirements.
This product is Class 1, must be connected to earth.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is suitable for dimming.
This product is rated at IP44.
44
IP

Care and Safety

We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before changing lightbulbs, or cleaning.
This LED's are protected by a PC shade. The shade part must be replaced immediately should it
become cracked or damaged. This fitting must not be used without the PC shade in place.
Replace Cracked Shade
V2 27/04/2022
UK Manufacturer: BH17 7BY
EU Manufacturer: Brilliant AG,
Brilliantstrasse 1, D-27442 Gnarrenburg
LIGHT FITTING
BLUE (N)
Check that...
You have correctly identified the wires.
GREEN/YELLOW
The connections are tight.
BROWN (L) No loose strands have been left out of
the connection block.
0.5m
1 x Max. 15W E27 GLS (required)
Instruction manual
Hayden Bollard
98440
