What You Need; You May Also Need - modway EEI-4894 Assembly Instructions Manual

Read through all of
the instructions
before starting
Approx. 90 minutes
assembly time
2 people recommended
for assembly
Furniture components:
1
2 Right Side Panel
3 Bottom Panel
4 Back Panel 1
5 Back Panel 2
6 Front Support
7 Support Panel
8 Center Panel
9
10 Door Panel Right
Provided hardware:
A Wood Dowel M8 x 25mm
B
Cam Bolt Ø6 x 24mm
C
Cam Lock Ø15
D
Screw 9 x 38mm
E Screw 4 x 25mm
F Screw 4 x 14mm
G Door Hinge (Full Overlay)
Missing parts or hardware? Need assistance?
Contact us before returning your item. We're here to help!
609.256.9000 • cs@modway.com
780-161MD2-0
Care instructions are
listed in the last step
of this manual
Make sure you have all
parts and components
before discarding any
packing materials
x1 Drawer Front 1
1 x 2 1 Drawer Front 2
1 x 3 1 Drawer Front 3
x1 14 Drawer Side L 1
x1 15 Drawer Side R 1
x1 16 Drawer Back
x1
17 Drawer Panel 1
x1 18 Drawer Side L 2
x1 19 Drawer Side R 2
x1 20 Drawer Panel 2
H
x16
x19
I
x11 J
x16 K
x2 L
x40 M
x2 N
Only use hand tools to assemble this item. Do not use power tools.
Do not tighten bolts or screws completely until all hardware is lined up
and inserted into the holes.
Do not over-tighten screws and bolts to avoid stripping the hardware
or cracking the item.
For vanity and plumbing installation, we suggest hiring a professional
contractor and plumber.
Assemble your item on a fl at, carpeted area, with plenty of space to work.
This will prevent damage and scratches to your fl oors or the item while
you're assembling the product.
Keep all components and packaging out of reach of children or animals
to avoid risk of choking or suff ocation.
x1
x1
x1
x1
x1
x2
x1
x1
x1
x1
Corner Bracket
Bracket-L/Hanger
Bracket-R/Hanger
Screw 4 x 28mm
Bearing Runner
x1 Pair
400mm
Screw 4 x 12mm
Cam Lock Ø12
x4 O Wood Dowel M6 x 25mm
x1 P Door Hinge (Half Overlay)
Bearing Runner
x1 Q
300mm
R
x4 Rubber Pad

What you need:

x26
Phillips

You may also need:

x8
+ Power Drill
+ Level
+ Silicone Adhesive or Caulk
+ Drywall Anchors and Screws
+ Other Wall-Mounting Hardware
x4
x2
x1 Pair
x6
Phillips Head Screwdriver
PAGE 2 OF 13
