6 4 3 2 V 5 S x l
64X32 RGBHV MATRIX SWITCHER WITH BALANCED STEREO AUDIO
Video Features - R/G/B Video Boards
High Video Bandwidth (RGB) - 500MHz (- 3dB) fully loaded.
Very Low Crosstalk - 80dB @ 1MHz.
Matrix Mapping™ Universal Breakaway Switching - A
unique and valuable benefit of Sierra Pro routing switchers.
This feature allows the switching of every level of every input
of the routing switcher independently. Switch a single level
or any combination of levels of the R, G, B, H, V, left audio
and right audio levels of any input. For example, input a
composite video signal on the R level of input one and an s-
Video (Y/C) signal on the G and B levels of input one and
switch only the composite video signal on the R level, switch
only the s-Video Y and C signals on the G and B levels, or
switch all three levels together.
Room Grouping Capability - Several inputs may be grouped
and operated independently of other input groups on the
routing switchers. This allows one routing switcher to be used
for multiple "rooms" where the control system for each room
will address only the inputs and outputs assigned to that
room.
Video Follow Sync™ Switching - The H and V channels of
an RGBHV signal are switched in advance of the RGB video
channels of the signal to provide clean, glitch-free switching
between most non-synchronous sources.
Video Mute Capability. -
Output Disconnect Feature. -
Genlock Input - Looping sync input for vertical interval
switching.
Sync Features - H/V Sync Boards
Selectable Termination - 510 or 75 Ohm (each input).
Digital Sync Channels (HV) - USP™ Sync Technology. Input
Detection 200mv. Re-shapes and re-squares sync to output
correct TTL level.
Audio Features -
Sierra Yosemite Audio - 2 mono frames at 3U each.
Digital Volume Control. -
Bittree Wiring Assemblies Included. -
Other Features -
Flexible Control Options - RS-232, RS-422, RS-485 (for
optional control panels) & IP (Ethernet).
Firmware Updates - Downloadable.
Local Control Panel (Standard) - Local front panel control
(red channel frame) with 64x64 I/O label-capable buttons, a
take button plus 6 additional buttons.
Remote Control Panels - Optional
Redundant Power Supplies - Standard (each frame) with
primary & redundant status indicators and dual AC inlets.
6 4 x 3 2
DESCRIPTION
The Sierra Pro 64 XL series are high bandwidth routing switchers for RGBHV, RGBS, RGB and s-Video (Y/C)
signals up to 64x64. Each 20 RU system includes 5 compact 4 RU frames, one each for the R, G, B, H & V signals.
SPECIFICATIONS
VIDEO
BANDWIDTH
HORIZONTAL FREQUENCY
VERTICAL FREQUENCY
VIDEO GAIN
CROSSTALK
SWITCHING SPEED
VIDEO INPUT
- LEVEL
HUMIDITY
- IMPEDANCE
- RETURN LOSS
- CONNECTOR TYPE
VIDEO OUTPUT
- VIDEO LEVEL
- IMPEDANCE
- RETURN
- CONNECTOR TYPE
POLARITY
CONTROL
SERIAL
- PROTOCOLS
ETHERNET
- PROTOCOLS
- WEB SERVER
LOCAL CONTROL PANEL
REMOTE CONTROL PANELS
LEGASY SVS PRODUCT CONTROL
GPI / GPO
GENERAL
RACK UNIT
DIMENSIONS (INCHES) 19 (W) x 7 (H) x 20 3/8 (D). Dimensions do not inlcude front panel hardware or rear cabling
POWER
- REDUNDANT POWER SUPPLIES
STORAGE TEMPERATURE
WARRANTY
INVESTMENT PTOTECTION
CUSTOMER SERVICE
© www.kramerelectronics.com 2008
SIERRA PRO 64 XL 64 SERIES ROUTING SWITCHERS
RGBHV, RGBS, RGBsB, RsGsBs. Generates composite sync from any video input.
3 general purpose 9-pin-D, each switcheable RS-232 or RS-422 at 9600, 38,400 or 115,200 baud
Suports full line of programmable, XY & single bus remote control panels
SIERRA PRO 64 XL 6432 SERIES
0.05 to 5.0V p-p, 4.0 normal
10% to 90% non condensing
75 or 510 Ohm, Switchable
RGBHV, RGBS, RGBsB, RsGsBs.
AGC to TTL: 4V-5V p-p, unterminated
Positive or negative (polarity insensitive)
SVS host, simple Kramer & select others
10/100 Base-T, full duplex on a RJ-45 connector
ARP, ICMP, TCP/IP, Telnet & HTTP
For full configuration and control
Standard (Red Channel Frame)
25-pin-D expansion port, up to 8 additional signal levals
4 RU per signal (20 RU for RGBHV)
90V AC -240V AC 50/60Hz (<150 Watts) auto detecting
Standard. Dual AC inlets per frame
-40 to +15 degrees Fahrenheit
Trade-In & trade-Up Program
24 hours a day, 7 days a week
500MHz (-3dB)
15-150KHz
50-150Hz
Unity
-80dB @ 1MHz
Deterministic
< -30dB @ 5MHz
BNC
75 Ohm
-30dB @ 5MHz
BNC
5 Inputs / 5 Outputs
7 Years
