- Page 1 Technical Manual ReSound A/S Global Technical Operations RS SYDNEY RIE Platform http://gto.gnresound.com Lautrupbjerg 7 DK-2750 Ballerup Denmark...
-
Page 2: Table Of Contents
Colour overview - HSG parts ........................5-6 Part list ................................. 7 Part list - test equipment ........................... 8 Part list - Service/engine modules - ALERA ....................9 Part list - Service/engine modules - VERSO ....................10 Part list - HSG parts - VERSO ........................11-12 Part list - HSG parts - ALERA ..........................13... -
Page 3: Form-Factor-Matrix & Product Information
Form-Factor-Matrix & Product Information - VERSO Models C4.5 Doc 0197030 rev. K Data Sheet Platform (C4.5) Product Name Model Doc No VERSO 9 VO960-DR SYDNEY VERSO 7 VO760-DR 400136000 (Batt 10A zinc air - non WL) VERSO 5 VO560-DR VERSO 9 VOT960-DR SYDNEY 400200000... - Page 4 Form-Factor-Matrix & Product Information - ALERA Models C4.1 Doc 0197030 rev. K Data Sheet Platform (C4.1) Product Name Model Doc No ALERA 9 AL960-DR SYDNEY ALERA 7 AL760-DR 17377900 (Batt 10A zinc air - non WL) ALERA 5 AL560-DR SYDNEY...
-
Page 5: Colour Overview - Hsg Parts
Colour Overview for Housing Parts - VERSO Doc 0197030 rev. K HOUSING PARTS - COLOUR HI COLOUR FRAME BAT DOOR MIC BAR HSG L/R LIGHT BLONDE (LBL) MEDIUM BLONDE (MBL) DARK BROWN (DBR) MONZA RED (MON RED) MON RED ANTHRACITE (ANT) METAL (MET) PEARL WHITE (PRL WHT) PRL WHT... - Page 6 Colour Overview for Housing Parts - ALERA Doc 0197030 rev. K HOUSING PARTS - COLOUR HI COLOUR FRAME BAT DOOR MIC BAR HSG L/R LIGHT BLONDE/MEDIUM BLONDE (MBL/LBL) MEDIUM BLONDE (MBL) DARK BROWN/BLACK (DBR/BLK) BLACK (BLK) ANTHRACITE/BLACK (ANT/BLK) ANT2 ANT2...
-
Page 7: Part List
Part List Doc 0197030 rev. K Description Part No INSERTION TOOL,S10A (incl mic filter) 17327300 INSERTION TOOL,S312 (incl mic filter) 17327900 PIN, Ø0.6 X 4.0 (bat door size10A) 16885400 PIN Ø0,60 X 4,50 (bat door size 312) 17010500 MULTI-TOOL (to separate HSG parts) 17327600 KIT, COLOUR MARKERS, SIZE10A 17294500... -
Page 8: Part List - Test Equipment
Part List - Test Equipment Doc 0197030 rev. K FLEX ADAPTOR CS53 Description Part No to be used together with a CS44 prog cable. An alternative solution to CS63 prog cable and flexstrip FLEX ADAPTOR CS53 GNR 17041100 FRAME (for HI test) 16902800 PROGRAMMING CABLE,RED (CS63) 15206700... - Page 9 Part List - Prog Service/Engine Modules - VERSO (C4.5) Doc 0197030 rev. K Serv Modules (312) Serv Modules (312) Part No Part No Engine Module (10A) Part No TINNITUS VO961-DRW,LBL 18617201 VOT961-DRW,LBL 18617401 VO960-DR 18616800 VO961-DRW,MBL 18617202 VOT961-DRW,MBL 18617402 VO760-DR 18616900 VO961-DRW,DBR 18617204...
-
Page 10: Part List - Service/Engine Modules - Alera
Part List - Prog Service/Engine Modules - ALERA (C4.1) Doc 0197030 rev. K Service Module/ASM FRAME, PROG (312) ENGINE MODULE, PROG (10A) Part No Part No ALERA ALERA AL960-DR 17418900 AL961-DRW,MBL 17419200 AL760-DR 17419000 AL961-DRW,BLK 17419300 AL560-DR 17419100 AL961-DRW,GREY3 17419400... -
Page 11: Part List - Hsg Parts - Verso
18092130 18092330 18085920 18085520 BLK GLOSS 18092125 18092325 * Printed “ReSound” All HSG parts are nano coated. Please also see “Colour Overview” page for colour of each HSG part Page 11 of 28 Not subject to issue control when printed... - Page 12 18089430 18089530 18653020 17777320 BLK GLOSS 18089425 18089525 * Printed “ReSound” All HSG parts are nano coated. Please also see “Colour Overview” page for colour of each HSG part Page 12 of 28 Not subject to issue control when printed...
-
Page 13: Part List - Hsg Parts - Alera
Part List - HSG Parts - ALERA Doc 0197030 rev. K ALx60-DR (Size 10A) ALx61-DRW (Size 312) COLOUR MIC BAR HSG L * HSG R * BAT DOOR MIC BAR HSG L * HSG R * BAT DOOR w/PB 18092101... -
Page 14: Part List - Replacement Pack - Alera
Part List - Replacement Pack - ALERA Doc 0197030 rev. K REPLACEMENT PACK - Nano coated COLOUR AL60 (10A) AL61 (312) 17354401 17354501 17354402 17354502 DBR/BLK* 17354403 17354503 17354404 17354504 AL60 REPL PK CREAM 17354405 17354505 CREAM/BLK* 17354406 17354506 17354408... -
Page 15: Part List - Rec Tubes & Domes
Part List - Rec Tubes Doc 0197030 rev. K Rec Tube Blister Pack Size S (small) * HP2 ** 18581300 18582300 18520300 18521500 18581400 18582400 18520400 18521600 18581500 18582500 18520500 18521700 18581600 18582600 18520600 18521800 18581700 18582700 18520700 18521900 18581800 18582800 18520800 18522000... - Page 16 Part List - Domes for NP & HP Receiver Doc 0197030 rev. K DOMES USED WITH NP REC DOMES USED WITH HP REC Description Description (10 pcs) (10 pcs) DOME,REC,SZ5,SM 18501200 DOME,REC,PWR,SM 18501900 DOME,REC,SZ7,MDM 18501300 DOME,REC,PWR,MDM 18502000 DOME,REC,SZ10,LGE DOME,REC,PWR,LGE 18502100 18501400 DOME,REC,EXT,SZ5,SM * 18501500...
- Page 17 Part List - Thin Tube Domes for S & HP2 Receiver Doc 0197030 rev. K DOMES USED WITH S REC DOMES USED WITH HP2 REC Description Description (10 pcs) (10 pcs) DOME,THNTUB/REC,SZ5,SM 18500800 DOME,THNTB/REC,TULIP,STD 18501100 DOME,THNTUB/REC,SZ7,MDM 18500900 DOME,THNTUB/REC,PWR,SM 18265100 DOME,THNTUB/REC,SZ10,LGE DOME,THNTUB/REC,PWR,MDM 18265200 18501000...
-
Page 18: Part List - Custom Insert Option
Part List - Accessories Doc 0197030 rev. K Description Part No Note: For Custom Insert Option instead of Domes, follow Custom Insert RECEIVER TUBE REBENDING KIT 16475900 *Process Doc 0160240 posted in the GTO website SPORTLOCKS, BAG 10 PCS (for HP/NP/HP2 recs) 539-052-000-00 SPORT LOCK,S-REC,BAG,10 (for S recs only) 18964000... -
Page 19: Power Dome Tool
Power Dome Tool Doc 0197030 rev. K Power dome tool Prepare a HF3 Insert HF3 tool with HF3 all the way in the power dome until it passes tool with HF3 through the rectangular cavity of the power dome Place the longer length of the rectangular cavity of the power dome over Squeeze and hold bottom of the power As the HP rec is pushed the power dome tool. -
Page 20: Disassemble Procedure
Lift upwards a bit and slide mic bar as shown to loosen it from frame ALERA/VERSO 60 ALERA/VERSO 61 (size 10A) (size 312) Use the pin end of the multi tool to push out the batt pin and... -
Page 21: Transfer Of Id Plate To New Module/Frame
Transfer of ID Plate to New Module/Frame Doc 0197030 rev. K plate plate When replacing a frame, the Use the multi tool to gently push out the ID plate from inside the frame ID plate must be transfered to new frame. Note that ID plate is NOT available as spare part Lift out the ID plate and mount it to the new frame. -
Page 22: Replace Engine Module (Size 10A)
Replace Engine Module 10A Doc 0197030 rev. K After separating HSG parts from frame, push out the engine module from the frame Engine module 10A Frame 10A Old spring New spring Slide the new engine module into the frame and press it down until it is correct in place. Check that mic filters are not damaged. Mount the HSG parts. -
Page 23: Replace Asm Frame (Size 312)
Replace ASM Frame Wireless 312 Doc 0197030 rev. K ASM frame ALERA/VERSOx61 312 After removing the HSG parts from old ASM frame, they can be remounted a new ASM frame. Transfer ID plate to new frame. Note: The engine module is inside the frame and cannot - like the size 10A - be replaced due to wireless antenna mounting Place the batt pin and push it in place. -
Page 24: Replace Mic Filter
Replace Mic Filter Doc 0197030 rev. K Use the screwdriver end of multi Lift off the mic bar. Remove Pick a mic filter insertion tool from the 5 pcs blis- tool to separate mic bar. Pull slightly the defective mic filters by ter pack and remove the sledge as shown. -
Page 25: Replace Receiver Tube
Replacing Receiver Tube Doc 0197030 rev. K Use the screwdriver end of multi tool to Remove the defective receiver tube from Add on the new receiver tube to the device. separate mic bar. Pull slightly backward. the device Push it all the way in until it stops Lift upwards a bit and slide mic bar as shown to loosen it from frame The mic bar “tap”... -
Page 26: Test Equipment
Test Equipment Doc 0197030 rev. K Coupler Insert (brass) to be attached 2cc coupler NOAHLINK WL CPD-1 Test Rec (NP) 2cc coupler during final HI test p/n 30-4838800 p/n 20310800 p/n 17460000 for HI testing p/n 16169300 can be ordered with GTO (WL test) (shown from both sides) Dept/HQ Ballerup DK... -
Page 27: Hi Testing
HI Testing Doc 0197030 rev. K Use of the test fixture and test frame are mandatory for all BTE during DSA6000 testing. Slide in the the flex strip to the HI and add the battery pill. Attach the HI to the test rec tube mounted on the white fixture. Place the white fixture in the black frame. -
Page 28: Wireless Test
Wireless Test Doc 0197030 rev. K The wireless range test is a combined DSA6000 NOAHLINK SAS-3 Noahlink/SAS Range Check test using the SAS-3 with its MAC address entered into the DSA 6000 system configuration and a Noahlink mounted directly in any of the DSA 6000 units USB ports. No fixture is required performing a wireless range test How to get the MAC address of the SAS: It is not...
