- Page 1 SIDE FOLD WALL MOUNT Models: 2500 Operation and Maintenance Instructions Please read all instructions before attempting operation of these units SAVE THESE INSTRUCTIONS FOR FUTURE USE Issued UBLICATION 501756261 Rev. B 07-20-2021...
- Page 2 SIDE FOLD WALL MOUNT Table of Contents Section Page No. Introduction Parts List Installation Instructions 3-18 Unit Operation Maintenance Introduction Thank you for your purchase of a Model 2500 Side Folding Wall Mount Backstop. To ensure that our equipment will provide years of use to you, we are including this operation, and maintenance guide.
- Page 3 SIDE FOLD WALL MOUNT 2500 WALL MOUNT PARTS LIST 4060 4064 6090 6094 9120 9124 ITEM PART NUMBER DESCRIPTION 504151591 WOOD PAD, 3.5" HC, 48” (NARROW) 504151590 WOOD PAD, 3.5" HC, 72” (WIDE) 504156224 WOOD PAD, TOP 48” (NARROW) 504156223 WOOD PAD, TOP 72”...
-
Page 4: Installation Preparation
SIDE FOLD WALL MOUNT 4060 4064 6090 6094 9120 9124 ITEM PART NUMBER DESCRIPTION 5741 MTG KIT, AAG TO WM 63” (WIDE FRAME) 5742 MTG KIT, AAG TO WM 35” (NARROW FRAME) 4404 MTG KIT, 63X36 RECT BOARD TO AAG 4405 MTG KIT, 35X20 FAN TO AAG Optional accessories: 9120-11-08 Crank Extension Arm... - Page 5 SIDE FOLD WALL MOUNT UNIT LOADING INFORMATION FOB = FACE OF BANK/ BACKBOARD...
-
Page 6: Tools Required
SIDE FOLD WALL MOUNT TOOLS REQUIRED Plumb Bob or Laser Level Electric Drill Drill bits – 7/16”, 9/16”, 5/8” Hammer Wrenches – 1/2", 9/16”, 11/16, and 3/4" Ratchet Wrenches with 1/2", 9/16”, 11/16, and 3/4" sockets File 4’ Level 25’ Tape measure Duct Tape Block of wood (for tapping) Broom... -
Page 7: Installation
SIDE FOLD WALL MOUNT INSTALLATION Installation instructions below are general in nature. Your exact installation needs to follow the parts and any specific instruction included in your specific project’s production drawings. 1. Before installing the wood pads on the wall, you must first preassemble the hinge brackets and chain brackets onto the wood bucks. - Page 8 SIDE FOLD WALL MOUNT WOOD PAD LOCATIONS Always refer to specific dimensions outlined in the production drawings shipped for the specific project. Dimensions of the specific project may vary from the dimensions outlined below. UNITS INSTALLED WITH OR WITHOUT HEIGHT ADJUSTER DIM "A"...
- Page 9 SIDE FOLD WALL MOUNT WOOD PAD WALL ATTACHMENT When attaching the wood pads to the wall, it is important to place the anchors in a location that will not reduce the strength of the wood. Anchors should be ½” diameter and the holes in the wood pads should be no larger than 9/16”...
- Page 10 SIDE FOLD WALL MOUNT Install the outer pipe weldments to the hinge points on the lower two wood pads. Install the bushings (Item 7) into both sides of the pipe before installing the pipe into the hinge bracket. Once the pipe has been installed into the hinge bracket and the ½”...
- Page 11 SIDE FOLD WALL MOUNT Slide the inner extension pipes into the outer extension pipes. Install a flange bushing (Item 7) on each side of the inner extension tubes. Install the hinge brackets onto each inner pipe and See illustration at left for proper location of the different hinge brackets.
- Page 12 SIDE FOLD WALL MOUNT INSTALLING THE BACKBOARD WITHOUT A HEIGHT ADJUSTER Install the 5O chains on each side of the unit. Attach the chain to the upper chain supports with the 5/16” quick links. Make sure the links are fully closed and tightened.
- Page 13 SIDE FOLD WALL MOUNT Check to make sure each side of the frame is still square to the wall. Measure the distance from the wall to the face of the back board on each side. Loosen the set screws in the outer tubes and slide the inner extension arm in or out until the face of bank (FOB) is reached.
- Page 14 SIDE FOLD WALL MOUNT INSTALLING THE BACKBOARD WITH A HEIGHT ADJUSTER Install the 5O chains on each side of the unit. Attach the chain to the upper chain supports with the 5/16” quick links. Make sure the links are fully closed and tightened. Square each side of the frame to the wall and support the outer portion of the extension arms with the...
- Page 15 SIDE FOLD WALL MOUNT Because the height adjuster mounting varies with the type of board, and the board to height adjuster mounting varies as well, specific instructions for mounting both the height adjuster and the board are supplied with the mounting kits. The illustration below is for reference only and may not be the exact representation of the board or wall mount in your application.
- Page 16 SIDE FOLD WALL MOUNT The final step of the assembly is to level the frame extension arm by adjusting the chain tension with the turnbuckles. It is important to not over adjust the chains as this causes undue stress on the chain anchor points.
- Page 17 SIDE FOLD WALL MOUNT Decal Locations...
- Page 18 SIDE FOLD WALL MOUNT ATTENTION: INSTALLER To confirm that you have received all the parts, and to better serve you if you contact us, please fill out the following information and fax or mail to the address below. Please refer to the facility name and/or the installation company below when you contact the factory and include it on any correspondence.
- Page 19 SIDE FOLD WALL MOUNT Model 2500 Installation Checklist Date: ________________ Unit Number Building structure has been approved for unit loads. Attachment anchor system has been approved for the unit loads and installed per the structural engineer’s specifications. Washers have been installed under wood pad’s carriage bolts.
- Page 20 SIDE FOLD WALL MOUNT OPERATING INSTRUCTIONS For all folding backstops, only trained personnel should operate the units. Keep the areas below and around the units clear at all times while the unit is in motion. Always use the equipment in the manner intended. The manufacturer does not assume any liability for improperly used or improperly maintained equipment.
- Page 21 SIDE FOLD WALL MOUNT...
-
Page 22: Maintenance Information
SIDE FOLD WALL MOUNT MAINTENANCE INFORMATION – PLEASE RETAIN FOR FUTURE REFERENCE!!! MODEL #2500 SIDE FOLD WALL MOUNT MAINTENANCE OVERVIEW !!!ALWAYS DISCONNECT POWER SOURCE BEFORE PERFORMING ANY MAINTENANCE CHECK OR OPERATION ON THIS EQUIPMENT!!! STRUCTURE: We recommend a yearly inspection (or more frequently depending on usage) of the nuts and bolts, checking for tightness. - Page 23 SIDE FOLD WALL MOUNT ATTENTION: MAINTENANCE DEPARTMENT To confirm that you have received maintenance and warranty information, and to better serve you if you contact us, please fill out the following information and fax or mail to the address below. Please refer to the facility name and/or the installation company below when you contact the factory and include it on any correspondence.
- Page 24 SIDE FOLD WALL MOUNT Maintenance Check Sheet Refer to the Maintenance Overview section (page 20) for recommended frequency of inspections. Date:________________ Unit:___________________ Wood Pads / Anchors -Wood pads, splitting, chipping, etc. Repair Replace -Anchors/Bolts Repair Replace Unit Supports / Brackets / Hinges -Tubes;...
- Page 25 Gared Holdings, LLC Performance Sports Systems Gared Sports 9200 E. 146 Street 9200 E. 146 Street Noblesville, IN 46060 Noblesville, IN 46060 800-848-8034 800-325-2682 www.perfsports.com www.garedsports.com...
