Installation, Operation and Maintenance Instructions
Please read all instructions before attempting installation or operation of these units
SAVE THESE INSTRUCTIONS FOR FUTURE USE
P
N
.
UBLICATION
O
6 5 1 7 5 2 5 8 9
Soccer Goal
Model: SG20 Series
Revised
April 20, 2010
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PSS SG20 Series
Summary of Contents for PSS SG20 Series
- Page 1 Soccer Goal Model: SG20 Series Installation, Operation and Maintenance Instructions Please read all instructions before attempting installation or operation of these units SAVE THESE INSTRUCTIONS FOR FUTURE USE Revised UBLICATION 6 5 1 7 5 2 5 8 9 April 20, 2010...
- Page 2 Maintenance Introduction/Liability Disclaimers Thank you for your purchase of the SG20 Series Soccer Goal. To ensure that our equipment will provide years of use to you, we are including this installation, operation, and maintenance guide. This guide will provide information on the proper assembly and installation methods, operating procedures, and preventative maintenance of your soccer goal.
- Page 3 SG20 Series Soccer Goal Parts Checklist Verify all parts listed on packing list are present prior to installation. Soccer goal frame components Check the chart for the proper parts that match the Goal P/N received. 8’ x 24’ 7’ x 21’...
- Page 4 SG20 Series Soccer Goal (Master Illustration) Use the above illustration to identify the main parts of your SG20 style soccer goal. *NOTE: Balloon numbers throughout this manual will match the Item numbers in the Parts Checklist.
- Page 5 SG20 Series Soccer Goal Goal Frame Assembly *Use the following step by step instructions to assemble your SG20 series soccer goal. Attach a Backstay Mounting Bracket (7) to each end of the Top Rail (4) as shown in the following illustration. Use 3/8” x 3/4” bolts (13), and 3/8” lock washers to attach the bracket.
- Page 6 SG20 Series Soccer Goal Next attach the Side Rails. Position the Connecting Tube (6) between the Side Rail and Top Rail. Align the four holes. Attach the Side Rail (5) with 3/8” x 1-1/2” bolts (12), 3/8” flat washers (16), and 3/8” lock washers (17). Use the illustration below as a guide. When...
- Page 7 SG20 Series Soccer Goal Now attach the lower Backstay Mounting Bracket (7) as shown in the illustration below. Use the same hardware as the top bracket. Then place the Rectangular Vinyl Endcap (10) onto the end of the side rail. The backstay bracket will overlap the endcap as shown. Mount the bottom end of the Backstay Pipe (2) to the bracket using two 3/8”...
- Page 8 SG20 Series Soccer Goal Attach the top end of the Backstay Pipe (2) to the top of the Backstay Mounting Bracket (7) as shown in the illustration below. Use the same hardware as the lower bracket. The height of the backstay pipe will determine the final position of the top mounting bracket.
- Page 9 SG20 Series Soccer Goal Attach the Backstay Brace Pipe (3) near the back of the two side backstay pipes. (see the following illustration). Use two Brace Clamp halves (8) to attach each end of the brace pipe. Insert a 5/16” x 2-1/2” carriage bolt (11) from the bottom as shown. Secure with a 5/16” flat washer (18) and a 5/16”...
- Page 10 SG20 Series Soccer Goal Install net using plastic clips (item 15). Insert the clips over the edge of the net as shown. Rotate the clip 90 degrees and insert it into the channel. When fully inserted, rotate it back 90 degrees to lock it into the channel.
- Page 11 SG20 Series Soccer Goal Maintenance 1) General inspection of equipment when used should be performed to ensure no catastrophic failures have occurred during the course of use between yearly inspections. 2) It is recommended that yearly inspections be conducted to determine if any bolts or other hardware has become worn or loosened.
- Page 12 Gared Holdings, LLC Performance Sports Systems Gared Sports 9200 E. 146 Street 707 North 2 Street Noblesville, IN 46060 St. Louis, MO 63102 800-848-8034 800-325-2682 www.perfsports.com www.garedsports.com...
