Installation, Operation and Maintenance Instructions
Please read all instructions before attempting installation or operation of these units
SAVE THESE INSTRUCTIONS FOR FUTURE USE
P
N
.
UBLICATION
O
961751151
2.38 Rnd Badminton System
Model: 6740
02/26/2019
Advertisement
Table of Contents
Related Manuals for PSS GARED 6740
Summary of Contents for PSS GARED 6740
- Page 1 2.38 Rnd Badminton System Model: 6740 Installation, Operation and Maintenance Instructions Please read all instructions before attempting installation or operation of these units SAVE THESE INSTRUCTIONS FOR FUTURE USE UBLICATION 961751151 02/26/2019...
- Page 2 Please do not substitute for factory parts. Contact the Gared or PSS customer service department and allow them to determine if substitute parts are acceptable.
- Page 3 6740 Badminton System SPECIFICATIONS...
- Page 4 6740 Badminton System INSTALLATION Installation of the sleeves of the unit is the setting stones of the system. If this process is not correct the remainder of the install will be inaccurate. 1. Mark (2) spots on the floor exactly 22 feet apart (refer to most recent set of architectural prints for exact locations within the gym).
- Page 5 6740 Badminton System counter bore in one pass. Gradually work down to the depth until the floor plate is flush with surface floor. Place the floor plate down into the counter bore several times so as to not make the hole too deep. When installed, the plate must be perfectly flush with the top surface of the floor.
- Page 6 6740 Badminton System OPERATION 1. Now that the sleeves and covers are install and the grouting has cured, the system can be setup for playing badminton. a. Open the floor covers and place each post into the sleeves with the rope clasp positioned away from the court side.
- Page 7 6740 Badminton System 2. To take the system down; a. Untie top and bottom net straps b. Release net tension by pulling rope out of rope clasp and removed net. Fold net up for storage. c. Remove net posts and move to storage. d.
- Page 8 Gared Holdings, LLC Performance Sports Systems Gared Sports 9200 E. 146 Street 9200 E. 146 Street Noblesville, IN 46060 Noblesville, IN 46060 800-848-8034 800-325-2682 www.perfsports.com www.garedsports.com...
