1.8
Formula spacer for reduction stroke:
Formula MOD is provided with 55 mm or 65 mm standard strokes. For frames who
require different one, Formula offers stroke reduction spacers in the following dimen-
sions: 2.5 mm, 5 mm and 7.5 mm.
Formula reduction stroke spacer can be easily installed and removed without aid of
tools.
WARNING: FORMULA strongly recommend to not use this spacer when it's not
required. Please follow the instruction below for the correct installation, do not
fit the spacer in other position.
The installation procedure is:
• Remove the spring preload;
• Remove the spring ring and the spring;
• Push up the washer with the bumper close to the cylinder;
• Insert the spacer along the stem by hand under the washer in the correct way as
showed in figure, this allows to connect these components each other;
• Install the spring;
• Insert the spring ring under the spacer with the flat surface facing the spring;
16
