UNIQUIN
electromodule
Mounting instructions
2
4
5
10
11
18
24
25
WN 059606 45532/13259
2020-10
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the UNIQUIN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dormakaba UNIQUIN

Summary of Contents for Dormakaba UNIQUIN

  • Page 1: Table Of Contents

    Contents About this manual Safety Product description Storage and transport Installation preparation Installation Maintenance and care Dismantling and disposal UNIQUIN electromodule WN 059606 45532/13259 2020-10 Mounting instructions...

  • Page 2: About This Manual

    About this manual About this manual Information about the manual This manual describes the mounting of a UNIQUIN electromodule as part of a UNIQUIN partition wall system and includes maintenance and care information. For the complete installation of the UNIQUIN partition wall system, further unit components and installation manuals may be required as specified in the project-related unit drawing, e.g.
  • Page 3 Mounting instructions About this manual Symbols used 1.4.1 Safety instructions Safety instructions are marked with symbols. The safety instructions are introduced by signal words that express the extent of the hazard, e.g.: CAUTION This signal word indicates a situation of potential risk, which could lead to minor or slight injury if not averted.

  • Page 4: Safety

    UNIQUIN door frame system. The product may only be installed with unit components designed by dormakaba for the installation situation and approved according to the project-related unit drawing. • The product may only be installed undamaged and in accordance with the requirements of the assembly location.

  • Page 5: Product Description

    Mounting instructions Product description Product description Example of a UNIQUIN unit This UNIQUIN unit is an example of a UNIQUIN partition wall system. Other combinations with different unit components are possible. Abb. 2 Example of a UNIQUIN unit (1) Side panel...
  • Page 6 Mounting instructions Product description Parts included Abb. 3 Parts included with the UNIQUIN electromodule (1) Drilling template (2) Screws for the electromodule (3) Electromodule (4) Installation manual UNIQUIN electromodule WN 059606 45532 2020-10...
  • Page 7 Mounting instructions Product description Example of an installed electromodule on the door frame system Abb. 4 Example of an installed UNIQUIN electromodule on the door frame system (1) Electromodule (2) Side panel, e.g., glass (3) Strain relief (4) Cable bushing...
  • Page 8 Mounting instructions Product description Example of a dual cable configuration in the mounting profile Abb. 5 Example of a dual cable configuration in the mounting profile (1) dual cable configuration (2) cover profile for the mounting profile (3) clamp (4) base profile for the mounting profile (5) Side panel, e.g., glass...
  • Page 9 Mounting instructions Product description Example of a dual cable configuration in electromodule Abb. 6 Example of a dual cable configuration in the door frame system and the electromodule (1) M5x16 screw for the electromodule (2) Electromodule (3) dual cable configuration...

  • Page 10: Storage And Transport

    Mounting instructions Storage and transport Technical information Abb. 7 Dimensions of the UNIQUIN electromodule Storage and transport ATTENTION Risk of damage during transport. Unsecured components may be damaged during transport. • Secure components adequately during transport. UNIQUIN electromodule WN 059606 45532...

  • Page 11: Installation Preparation

    Mounting instructions Installation preparation Installation preparation CAUTION Risk to life due to electric shock. Cables that are not isolated can lead to injury through electric shock and fire. • Disconnect the cable from the mains. • Do not trap the cable.
  • Page 12 Mounting instructions Installation preparation Tools for installation • Metal saw • Drill • Deburring tools, e.g. files • Hexagonal socket set Plan cable routing Requirements • The base profile for the mounting profile is installed. • The side panels are installed.
  • Page 13 Mounting instructions Installation preparation Abb. 8 Example of cable routing through the mounting profile and the door frame profile (1) Electromodule on the door frame profile on the opposite side to the hinge, e.g. for a light switch (2) Electromodule on the door frame profile on the opposite side to the hinge, e.g.
  • Page 14 Mounting instructions Installation preparation TIPS AND RECOMMENDATIONS • The cable cannot be routed on the hinge side through the door frame profile. • Plan the wiring so that the cables are routed through the door frame profile from below into the electromodule.
  • Page 15 Mounting instructions Installation preparation TIPS AND RECOMMENDATIONS The recess that may already have been cut out during installation of the mounting profile with dimensions 15 mm x 15 mm is not sufficient for the cable bushing. Cut out the recesses on the cover profiles as required, e.g. for joint mounting (Abb. 9).
  • Page 16 Mounting instructions Installation preparation Abb. 10 Mark the required drill holes on a cover profile for the door frame with the drilling template. If applicable remove the silicone seals from the cover profile for the door frame. Drill and deburr the external drill holes through both sides of the cover profile according to the planned cable routing using the correct methods with a metal drill.
  • Page 17 Increase the size of the drill holes on the opposite side to a diameter of 10 mm and deburr them (Abb. 11). Abb. 11 Increasing the size of the pre-drilled holes for the UNIQUIN electromodule on the opposite side TIPS AND RECOMMENDATIONS...

  • Page 18: Installation

    Mounting instructions Installation 10. Drill and deburr the central drill hole on the installation side of the cover profile only for cable routing. Ensure that the entire cable route has been deburred and is free from sharp edges. →...
  • Page 19 Mounting instructions Installation CAUTION Risk of injury due to sharp edges. Contact with cut edges can lead to cuts. • Wear protective gloves. • Protect cut edges against accidental contact. Requirement • The installation preparation is completed. • The cable is voltage-free.
  • Page 20 Mounting instructions Installation Installing the electromodule Align the electromodule to the intended cable bushing (Abb. 12). Fix the electromodule in place on the cover profile for the door frame from the opposite side using screws. Abb. 12 Fixing the electromodule in place on the cover profile for the door frame...
  • Page 21 Mounting instructions Installation Carrying out the electrical installation Requirement • The electromodule is installed. Install the cable according to the planned cable routing e.g. through the mounting profile and the door frame system (Abb. 13). Abb. 13 Example of a cable installed according to the planned cable routing...
  • Page 22 Mounting instructions Installation Route the cable through the cover profile for the door frame into the electromodule (Abb. 14). Attach the cover profile for the door frame with the electromodule and secure to the clamping pieces. Abb. 14 Insert the cable through the cover profile into the electromodule and...
  • Page 23 Mounting instructions Installation Attach the silicone seals onto the cover profiles for the door frame again if applicable. Connect the ground conductor for the installed cables to the intended product using the correct methods (Abb. 15). Abb. 15 Connect the cable to the intended product, e.g. to a grounded socket.

  • Page 24: Maintenance And Care

    Mounting instructions Maintenance and care 10. Ensure that the electrical installation is additionally protected with an RCD protector (according to DIN VDE 0100-410:2007-06) as well as the circuit breaker. Complete the electrical installation on site before commencing operation ad check according to DIN VDE 0100-600:2017-06.

  • Page 25: Dismantling And Disposal

    Mounting instructions Dismantling and disposal Dismantling and disposal Dismantling is carried out in the reverse order of the installation manual instructions and must be done by qualified personnel. Refer to the relevant national standards and guidelines for disposal. Dispose of the product in an environmentally friendly manner.
  • Page 26 Mounting instructions UNIQUIN electromodule WN 059606 45532 2020-10...
  • Page 27 Mounting instructions UNIQUIN electromodule WN 059606 45532 2020-10...
