Dormakaba SIO-DR Mounting Instructions

Contents
1 About this document
2 Safety
3 Product description
4 Mounting
5 Disassembly and disposal
1 About this document
1.1 Contents and purpose
This document describes the mounting of the SIO-DR
module.
1.2 Target group
This document is intended for assembling technicians
and specialists authorized for mounting by
dormakaba.
1.3 Other applicable documents
• Instructions for devices intended for networking
1.4 Symbols used
1. 2. Sequence of action steps
6
Reference to a chapter
Components may be damaged by
electrostatic discharge. Ground
your own body before touching a
component!
SIO-DR
Mounting instructions
2 Safety
1
2.1 Intended use
1
1 The SIO-DR module is used to connect analog switch
2 contacts to the dormakaba system bus. Messages are
4 output via contacts or control signals are read in.
2.2 Personnel qualification
Mounting may only be carried out by persons
authorized by dormakaba.
3 Product description
The SIO-DR module is a DCW® component. Status
messages are output potential-free via relays. Control
signals are read in via optocouplers.
The mounting takes place on a 35 mm DIN rail in
a housing. The housing must at least meet the
requirements of IP 30.
3.1 Parts included
10 6
65
92
WN 059731 45532 – 2019-04
EN
