(REVISION DATE: 03/10/2011)

OMFP6010 (60cm PIROLITIC OVEN)















Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OMFP6010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kleenmaid OMFP6010

Summary of Contents for Kleenmaid OMFP6010

  • Page 1                   Products documentation (REVISION DATE: 03/10/2011)   OMFP6010 (60cm PIROLITIC OVEN)                            ...

  • Page 2: Table Of Contents

    Ovens Service Manual Models OMFP6010 This document has been published to be used for service only. The contents are subject to change without notice CONTENTS 1. SERVICING REQUIREMENTS HEALTH & SAFETY 1.1.1 Electrical Safety 1.1.2 Good Working Practices 1.1.3 Insulation Test 1.1.4 Sheet Metal Edges...
  • Page 3 7. COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE OVEN REMOVAL COOLING FAN MOTOR SUBSTITUTION OVEN DOOR REMOVAL CONVECTION FAN MOTOR SUBSTITUTION RING ELEMENT SUBSTITUTION UPPER ELEMENT SUBSTITUTION LOWER ELEMENT SUBSTITUTION LOCK DOOR MOTOR SUBSTITUTION LOCK DOOR MOTOR SWITCH SUBSTITUTION SOLUTION 7.10 DOOR GASKET SUBSTITUTION 7.11 COOKING SAFETY THERMOSTAT SUBSTITUTION 7.12...

  • Page 4: Servicing Requirements

      Servicing Requirements Health & Safety Note: When servicing the oven, health and safety issues must be considered at all times. Specific safety issues are listed below with their appropriate icon. These are illustrated throughout the service information to remind service people of the health and safety issues 1.1.1 Electrical Safety WARNING! TO AVOID ELECTRIC SHOCK!

  • Page 5: Serial Plate

      Technical Overview Serial Plate 2.2.1 Location The product serial number plate is located on the left side profile trim. 2.2.2 Model & Serial Number The numbers printed on the plate contains the following information: Technical Overview Components Specifications 2.3.1 Heating Volts Freq.

  • Page 6: Electric Components

    2.3.3 Electric Volts Watts Note Components Door Lock Motor Switch Lamp Piro Safety Thermostat Cooking Safety Thermostat Cooling Fan Thermostat Probe Temperature   Technical Overview System Description  ELECTRONIC CONTROL. The control consists of a main power located on display board. ...

  • Page 7: Oven Model Configuration

      Technical Overview Oven Model Configuration The manual test procedure must be completed and confirmed as per the instructions in this section. At every POWER-UP, the control runs a latch auto-test cycle. The lock icon flashes while the latch is moving.

  • Page 8: Manual Test

    Picture 2     Technical Overview   Manual Test   IMPORTANT: The MANUAL TEST procedure can be activated only after power on.   To enter in the MANUAL TEST follow the same procedure as the Configuration section 2.5    2.6.1 How to verify the correct selection At power-up, the control runs a latch auto-test;...
  • Page 9 2.6.2 How to check Single oven hardware Turn the knob [MODE] to the cooking mode.     1. Press and release [TEMP & TIME] knob, the display automatically shows:  “Ther”   check that the heating elements are energized (2200W or 2500W for ring element if the model is MA06)  ...
  • Page 10   8. Turn the knob [MODE] to the position.   9. Press and release [TEMP & TIME] knob the display automatically shows:  “Pr00”   Turn the knob [MODE] clockwise and check that the values correspond to the position of selector [Pr00 for 0, Pr01 for first, etc..] ...
  • Page 11             2000W                         2000W                       1000W 2000W                ...

  • Page 12: Description Of Electronic Control

    Technical Overview Description of Electronic Control  The drawing on the previous page explains how the electronic boards work. Each relay function is described and the connector of sensor is also shown.                  ...

  • Page 13: Fault Numbers

    Technical Overview Fault Numbers Faults N° Temperature sensor broken. Temperature sensor shorted. Temperature sensor circuit failure. Latch time-out overflow. Free. Free Mode selector disconnected. Cannot be reset. Sum of error codes simultaneously detected. OTHER The control is continuously checking the status of the system. If an abnormal condition is detected for more than 1 minute, a failure occurs: - The heaters and the other loads are disabled.

  • Page 14: Oven Safety Futures

    Technical Overview   Oven Safety Features     2.9.1 Child - safe locking system     All of our ovens are built-in child-safe locking systems. The feature is automatically enabled any time the appliance is connected to the power, any time the switch is turned on and any time the oven is programmed to run a self-cleaning of the cavity. ...

  • Page 15: Troubleshooting Guide

    the electronics will be still powered.  The reset is automatic when the cooling fan was replaced or the cooling fan problem was solved and the temperature is in the right functioning parameters.      Troubleshooting guide Error Message Code Error Description Possible Cause Corrective Action...

  • Page 16: Oven Not Operative

    Troubleshooting guide Oven not operative Anomaly Possible Cause Corrective Action section Oven does not run Main breaker or Replace the fuses No power supply main fuses Short circuit Find the short circuit and remove it. Check internal connections (short circuit, interruptions, etc..) Oven does not run Connections to the Replace Electronic Control...

  • Page 17: Convection Fan Problems

    Troubleshooting guide Convection Fan Problems Anomaly Possible Cause Corrective Action section Fan does not run Bad connection Check the connectors and the No power supply Mode selector not harness 7.17 switching Replace switch selector Fan does Not run Blocked rotor Replace fan Power supply ok.

  • Page 18: Oven Light Problems

    The control doesn’t Door lever mechanism Check lever mechanism of door unlock the door after self locked latch. cleaning and the lock Lubricate all working parts with symbol on the display is silicon grease always flashing.   Troubleshooting guide Oven Light Problems Anomaly Possible Cause Corrective Action...

  • Page 19: Display Problems

    Any or some cooking mode The contacts of Check the connections between the performed selector do not selectors and the Electronic Control. switch.. Check and eventually replace the selector itself. 7.17 Check and eventually replace the Electronic Control. 7.19   Troubleshooting guide Display Problems Anomaly...
  • Page 20 Check the contacts of the switch selector and replace it if needed. 7.17 Convection fan not See the convection fan problem working properly There is not sealing The hinges system or the hinges 7.15 between door and support in the box are damaged. gasket Replace the units 7.16...

  • Page 21: Component Replacement And Adjustment Procedure

      Component replacement and adjustment procedure Cooling fan motor substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the upper cover. Remove the screws on the attachment bar (four lateral & three on the top) [IF PRESENT].
  • Page 22   To Replace Door Insert the upper arms (3) of both hinges into the upper slots (6) and the lower arms (4) into the lower slots (7). The recesses (5) must hook on the lips (8). Move the hinge brackets (1) back down into position. Close and open the door slowly to assure that it is correctly and securely in place.

  • Page 23: Convection Fan Motor Substitution

    Component replacement and adjustment procedure Convection fan motor substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the rear covers. Disassemble the baffle by removing the four screws in the cavity. Remove the fan blade by using a 10mm socket, than remove 3 screws in the cavity.

  • Page 24: Ring Element Substitution

    Component replacement and adjustment procedure Ring element substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the rear covers. Disconnect the terminals of heating element. Disassemble the baffle by removing the four screws in the cavity.

  • Page 25: Upper Element Substitution

    Component replacement and adjustment procedure Upper element substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the rear covers. Disconnect the terminals of heating element. Remove the two screws near the external terminals, one of which is used for ground.

  • Page 26: Lower Element Substitution

    Component replacement and adjustment procedure Lower element substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the rear covers. Disconnect the terminals of heating element. Remove the screws near the external terminals and the other four on the brackets.

  • Page 27: Lock Door Motor Substitution

    Component replacement and adjustment procedure Lock door motor substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the upper cover. Remove the rear cover. Disconnect the cables. Pay attention to the sequence of wiring of the motor (micro). Remove the lateral screws and internal attachment screws.

  • Page 28: Lock Door Motor Switch Substitution Solution

    Component replacement and adjustment procedure Lock door motor switch substitution solution To disassemble the motor see section 7.8. Disassemble the motor by removing the two screws and remove also the brackets. Remove the micro switch by the two screws. Replace the new switch by reversing the previous steps see section 7.8.

  • Page 29: Door Gasket Substitution

    Component replacement and adjustment procedure 7.10 Door Gasket substitution Open door and pull out the gasket by hands. Replace with a new one by reversing the previous steps.                          ...

  • Page 30: Cooking Safety Thermostat Substitution

    Component replacement and adjustment procedure 7.11 Cooking safety thermostats substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the upper cover. Unscrew the thermostat Replace with a new thermostat by reversing the previous steps. The connections must not be loose.

  • Page 31: Resistor 800Ω Substitution

      Component replacement and adjustment procedure 7.12 Resistor 800Ω substitution (if present) Disconnect the power supply cord and remove the Oven from the cabinet. Remove the upper cover. Remove the resistor screws. Replace with a new resistor by reversing the previous steps. The connections must not be loose.

  • Page 32: Piro Safety Thermostats Substitution

    Component replacement and adjustment procedure 7.13 Piro safety thermostats substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the upper cover. Unscrew the thermostat. Replace with a new thermostat by reversing the previous steps. The connections must not be loose.

  • Page 33: Probe Temperature Substitution

    Component replacement and adjustment procedure 7.14 Probe Temperature substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the rear covers. To replace the probe, disconnect it and remove the attachment screws. During operation, the ceramic fiber must be around the probe hole.

  • Page 34: Door Hinges Substitution

      Component replacement and adjustment procedure 7.15 Door hinges substitution Remove the Oven door following section 7.3. Put the door on a flat surface with a soft cloth to prevent scratching of the aesthetics. Unscrew the door external glass A. Remove the hinges unscrewing its screws B.

  • Page 35: Door Hinges Box Substitution

    Component replacement and adjustment procedure 7.16 Door hinges box substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the door following section 7.3. Unscrew the boxes to change support. Disassembling the hinges box. To replace the new hinge box, reverse the previous steps.

  • Page 36: Switch Or Selectors Of Functions Substitution

    Component replacement and adjustment procedure 7.17 Switch or Selectors of functions substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the upper cover. Remove the knobs and the glass. Disconnect the bad switch or selector and remove it by the screws.

  • Page 37: Temperature Selector Substitution

    Component replacement and adjustment procedure 7.18 Temperature Selector substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the upper cover. Remove the knobs and the glass. Disconnect the bad selector and remove it by the screws. Replace the new selector by reversing the previous steps DURING MOUNTING, THE WIRES...

  • Page 38: Electronic Control Substitution

    Component replacement and adjustment procedure 7.19 Electronic Control substitution Disconnect the power supply cord and remove the Oven from the cabinet. Remove the upper cover. Remove the knobs and the glass. Disconnect the bad electronic control board and remove it by the its plastic brackets.

  • Page 39: Door External Glass Substitution

    Component replacement and adjustment procedure 7.20 Door external glass substitution Remove the door from the oven section 7.3. Put the door on a flat surface with a soft cloth to prevent scratching of the aesthetics. Remove the external glass from the door unscrewing two screws on the corner and two screws on the bottom.

  • Page 40: Door Internal Glass Substitution

    Component replacement and adjustment procedure 7.21 Door internal glass substitution Remove the door from the oven (see MANUAL). Put the door on a flat surface with a soft cloth to prevent scratching of the aesthetics. Remove the external glass from the door unscrewing two screws on the corner and three screws on the bottom...
