60Hz
Technical manual
NRL 080-180
CHILLER
REVERSIBLE HEAT PUMP
• EXTERNAL UNIT
• HIGH EFFICENCY
• HOT WATER PRODUCING UP TO 131°F / 55°C
• POWER SUPPLY 60Hz
EN
INRLFTY. 14_09.4086981_04
