- Page 1 Instruction Manual G-Series Rear View Replacement Mirror Monitor with Built-in Dash Camera RVS-718-BB Rear View Safety, Inc. © 2015 Reverse With Confidence ™...
- Page 2 Troubleshooting......31 Warranty & Disclaimer......32-33 Rear View Safety...
- Page 3 NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle.
- Page 4 Rear View Camera System. If you back up while looking only at the monitor, you may cause Rear View Safety...
-
Page 5: Installation
INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified. - Page 6 If you have questions about this product, contact: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
- Page 7 Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly.
- Page 8 Do not run the cable over sharp edges, do not kink the cable and keep away from HOT and rotating parts. Fasten all cables and secure all excess cable. Connect camera to the camera extension cable which runs inside the vehicle. Figure 1.2 Rear View Safety...
- Page 9 Wiring After connecting the camera to the “camera cable” connect the camera cable to the input on the wiring harness using the RCA adapter. Connect the RED 12V power wire to an ignition power source and the BLACK 12V ground wire to a chassis ground. The GREEN wire is the REVERSE trigger wire.
- Page 10 There are many methods to remove the original rear-view mirror, however, please don’t force the mirror off the bracket. The manufacturer will not be responsible for any damage caused to your car by an incorrect installation of the mirror. Rear View Safety...
- Page 11 FIGURE 1.2 When a camera is to be installed at the rear of vehicle, a good position is usually at the top of the license plate where there is an under ledge. Reverse With Confidence ™...
- Page 12 FIGURE 2.2 Rear View Safety...
- Page 13 Reverse With Confidence ™...
- Page 14 0.2M space from the car. Accuracy The accuracy of the grid-lines can vary based on how you angle you cam- era. Therefore to compensate for inaccuracies, you can adjust the grid-lines to your camera angle. Rear View Safety...
- Page 15 Long press settings button (middle button) to enter into “guide line adjustment” mode.The settings on top are for the left grid line and the bottom are for the right. Press the “Settings” button (middle button) to toggle between the the two. The up, down , left and right buttons are to adjust the location of guide lines.
-
Page 16: Specifications
Screen Size: 4.3” Display Screen: TFT-LCD Display Resolution: 400(H)x234(V) Aspect Ratio: 16:9 Color Depth: 16.7M dithering Pixel Pitch (mm) 0.219x0.219 Power Consumption: Working Voltage: DC12V VIDEO-IN to GPS/DVD Video Input: (Default) Camera to backup camera Signal System: PAL/Auto/NTSC Rear View Safety... -
Page 17: Glass And Bracket
Glass and bracket The thickness of our mirror’s glass is 4mm. It is strong enough to bear impact and reach every country’s safety standards on rear view mirrors. OEM bracket for special rearview mirror monitor with 21mm- thickness pipe. FIGURE 2.1 RED- Power (+) YELLOW- Video GREEN- Mirror / Normal Imaging... -
Page 18: System Time
Stop recording and press “MENU” button twice to en- ter system setting menu. Find “System time” and set the exact date and time with “UP” and “DOWN” buttons. Press “REC” to switch to next setting. Rear View Safety... -
Page 19: Video Size
Video size The full HD DVR mirror can record video in four kinds of video quality. They are HDR 1920*1080 30FPS - 1920*1080 30FPS - 1280*720 60FPS and 1280*720 30FPS. To adjust this, first stop the recording. Press “MENU” button to enter system setting menu. - Page 20 Stop recording and press “MENU” button to enter video setting menu. Enter into menu of “Car on auto rec” by pressing “UP” and “DOWN” buttons. Press “MENU” to choose “Car on continuate rec”. Then mirror will auto start to record once mirror is turned on. Rear View Safety...
- Page 21 G sensor and event recording With the G-sensor function, when the system detects a strong acceleration, deceleration or excessive shaking, the mirror will automatically save the video as an “event file”. The event file will be locked and cannot be overwritten in re- cord cycle mode.
-
Page 22: Motion Detect
As memory of the SD card is limited, some may want to only record the most rel- evant video. The motion detect setting can achieve this. The DVR mirror will start recording when it detects any moving object. There are different levels of sensitivity you can choose from. Rear View Safety... - Page 23 Diagram of Sensitivity Level Parking Mode Safety Concerns of Parking Mode WARNING: Due to the system being on and drawing power even when the vehicle is off, parking mode will drain the battery on your vehicle. Please be sure not to use this function if you do not have a power regulator or backup power.
- Page 24 “NO”. You can choose “YES” by pressing “UP/Down” buttons. After this, you can find the third warning message: “Safe-guard recording mode is activated. DVR mirror will continue to record front views after you leave the car.” Parking mode is now on. Rear View Safety...
- Page 25 Video Watermark - Turn On/Turn Off/ Set Drive ID Stop recording and press “MENU” button to enter video setting menu. Find and choose “Driver ID Setting” with the “UP” and “DOWN” buttons. Press “UP”/ “Down” buttons to choose the right number and press “REC” button to switch the number to another. After setting the Driver ID number, press “DOWN”...
-
Page 26: Auto Power Off
This amount of time can be changed or turned off with the auto power off function. Stop recording and press “MENU” button to enter the video setting menu. Scroll to “Auto power off” using the “UP” and “DOWN” buttons. Press the “REC” button to choose from 1 min/3 mins/5 mins/Off. Rear View Safety... -
Page 27: Auto Screen Off
Auto Screen Off Why do you need auto screen off function? A bright screen can be distracting when driving at night. This function also uses less power. The mirror continues to record even if the screen is off. Set Auto Screen Off The screen can be set to automatically turn off after a set period of inactivity. -
Page 28: Video Recording
Under the stopping record mode, press “mode” can enter photograph mode, press “rec” to When not recording, press “MODE” to enter photography mode. Press “REC” to take a photograph, and press “menu” can set the photos resolution and quality. photo, and press “MENU” to change photo resolution or image quality. Rear View Safety... -
Page 29: File Browsing
File browsing When not recording, press “MODE” twice to enter the file browsing interface. Scroll “UP” and “DOWN” to switch between G-Sensor files, normal files, and photos. Press “REC” to enter a file list. Scroll “UP” or “DOWN” to switch between videos, press “REC” to select a video, and press “REC”... - Page 30 Focus: 12cm-infinite Photo Format: JPEG Video Format: Audio: Built in microphone and speaker Temperature: -30c° 70c° Language: English/ Japanese/ French/ Portuguese/ Italy/ Russian/ German/ Spanish Certifications: The DVR mirror has passed E-MARK/FCC/C-TICK and is compliant with ROHS. Rear View Safety...
- Page 31 Problems Diagnoses Solutions Recording frequently stops 1. Motion detection is on 1. Turn off motion detection 2. The SD card is too small to read and store information 2. Use a larger higher class SD card Camera input is working but no 1.
- Page 32 OTHERS OR THE UNAUTHORIZED USE OF NONCONFORMING PARTS; THE DAMAGE IS DUE TO NORMAL WEAR AND TEAR, THIS DAMAGE IS DUE TO ABUSE, IMPROPER MAINTENANCE, NEGLECT OR ACCIDENT; OR THE DAMAGE IS DUE TO USE OF THE REAR VIEW SAFETY, INC. SYSTEM AFTER PARTIAL FAILURE OR USE WITH IMPROPER ACCESSORIES.
- Page 33 FOR ANY INJURY, LOSS OR DAMAGE, INCIDENTAL OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INTENDED USE OF THE PRODUCT. IN NO EVENT SHALL REAR VIEW SAFETY AND/OR ITS AFFILIATES HAVE ANY LIABILITY FOR ANY LOSSES (WHETHER DIRECT OR INDIRECT, IN...
- Page 34 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. Rear View Safety...
