- Page 1 Instruction Manual Quad View Backup Camera System with Built-In DVR RVS-2770-DVR Please read this manual before using system. The product may be different from how it is described based on what software version is being used. Reverse With Confidence ™...
-
Page 2: Table Of Contents
Troubleshooting....... . . 29 Warranty & Disclaimer......30-31 Rear View Safety... -
Page 3: Introduction
NOTE! Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System! With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle. -
Page 4: Safety Information
Rear View Camera System. If you back up while looking only at the monitor, you may cause Rear View Safety... - Page 5 INSTALLATION: • Electric shock or product or disconnected wire may cause a malfunction may occur if this fire. product is installed incorrectly. • While installing the Rear View System be careful with the wire • Use this product within positioning in order to avoid wire the voltage range specified.
- Page 6 If you have questions about this product, contact: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
-
Page 7: Before Beginning Installation
Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components. We recommend doing a benchmark test before installation to insure that all components are working properly. -
Page 8: Monitor Features
- Monitor OSD menu features: trigger delay setting, 4 channel image modes (NOR/MIR/UP/DOWN), adjustable display mode for each trig- ger cable - Shortcut key ( ) to each channel single image display - Some display modes can be turned ON/OFF, adjustable trigger priority Rear View Safety... -
Page 9: Precautions
Operating Precautions 1. The device may be powered by a 12/24 volt battery or the vehicle's electrical system. 2. Make sure all cables are connected properly. Improper cable connec- tions may damage the monitor. Remove power cable connections when not using monitor. 3. -
Page 10: Monitor Technical Parameters
Automobile storage battery (12V/24V) Automobile adapter Speaker 16Ω/1W Power Consumption 8W Max（Without load ） Connector DVI24+1 Operating temperature -20℃ ～+70℃ Storage temperature -30℃ ～+ 80℃ 185mm*123mm*50mm External dimension ( mm) Accessaries U-support bracket & screws Split cable Remote Rear View Safety... -
Page 11: Remote Control
Remote Control Operation Note: Make sure polarity is not reversed when installing CR2025 (3V) battery. This may cause damage. Reverse With Confidence ™... -
Page 12: Monitor Menu
"OK" button. These are the monitor options. 1. Picture: The Brightness/Contrast/Saturation may be adjusted from 0 - 100. The default is 50. Hue may be adjusted from -5 - 5. The default is 0. Rear View Safety... - Page 13 2. Channel Reverse Setting: Use this setting to toggle between normal and mirror views. Press to toggle the image view. Reverse With Confidence ™...
- Page 14 There are 9 display modes: single image (F, B, L, R), dual image (F/B, L/R), triplex image (B/L/R) and quad (F/B/L/R, "H" shaped) Use the channel switch to turn the 6 menu modes ON/OFF. Single image (B,F) and dual image (F/B) modes are always on. Rear View Safety...
- Page 15 4. Trigger Setting: Each trigger cable can be set to trigger any display mode. Trigger function isn’t available if there is "X" near the option. Note: Options cannot be changed while the system is triggered Reverse With Confidence ™...
- Page 16 Trig Priority 1 T1 B Trig Priority 2 T2 L Trig Priority 3 T3 R Trig Priority 4 Use this setting to change your trigger priority. Reverse priority isn’t permitted if there is "X" near the option. Rear View Safety...
- Page 17 5.Trigger Delay Setting: Trig Trig You may change how long a monitor stays in the view after a trigger is stopped. The options are 0 secs / 5 secs / 10 secs / 15 secs / 20 secs / 25 secs / 30 secs.
- Page 18 TRIG: Only show when the single channel (B/L/R/F) is triggered OFF: No distance indicator line Note: The distance indicator works only when there is a video signal input, it doesn’t work if there is no signal or if system is in multi-image display mode. Rear View Safety...
- Page 19 5. Reverse Priority Setting: Trig LANGUAGE ENGLISH Languages options are English/Chinese/French/German. English is the default language Reverse With Confidence ™...
- Page 20 DVR OSD Menu Operation MONITOR Pressing the "MENU" button will display MONITOR/DVR as shown above. Select an option by pressing the "OK" button. These are the DVR options. Rear View Safety...
- Page 21 1. DVR Image Setting: Image OK:√ After selecting icon, press the "OK" button to enter menu. Video Quality: High / Mid / Low Frame Rate: 30 FPS / 15 FPS / 5 FPS Resolution: D1/720X480, VGA/640X480, QUGA/320X240 Reverse With Confidence ™...
- Page 22 Select YES / NO. Clip Length: Length of individual recording clip. Select 15 min / 30 min / 60 min. Motion Detection: Mask area/sensitivity options Mask area: Change area of motion detection Sensitivity Options: High / Mid / Low Rear View Safety...
- Page 23 3. DVR REC Mode REC Setting OK:√ After selecting the icon, press the "OK" button to enter menu. Manual Mode: Record manually Schedule Mode: Record automatically at an adjustable predetermined time Motion Detection Mode: Automatically starts recording video when motion is detected in predetermined area Note: Pressing the "MENU"...
- Page 24 4. DVR Playback REC Setting OK:√ After selecting the icon, press the "OK" button to enter menu. Use this setting to playback or delete video files. Rear View Safety...
- Page 25 5. DVR System Setting REC Setting OK:√ After selecting the icon, press the "OK" button to enter menu. Language: Choose between English and Chinese Time: Set time on DVR Format: Format SD card/clear files Card Info: View SD card storage capacity Note: Save by pressing "OK"...
- Page 26 System Tips Insert SD Card! If the above image is displayed, the SD card is broken or not in the system. Please insert SD card to use the system. Rear View Safety...
-
Page 27: Camera Dimensions
Camera Dimensions • 18 Infra-red illuminators (enable you to see in total darkness) • 1/4 Sharp® Color CCD, 250k pixels • 2.1 mm wide lens with 130° viewing angle • 20G vibration and 100G shock rating • Built-in high gain microphone Reverse With Confidence ™... -
Page 28: Camera Specification
1Vp - p, 75 Ω IR Switch Control ACDS Automatic Control TROUBL Vibration and Shock Rating 20G / 100G SHOOTI Operating Temperature -40°C ~ +80°C / RH 95% Max Storage Temperature -40°C ~ +60°C / RH 95% Max Net Weight 22oz Rear View Safety... -
Page 29: Troubleshooting
Troubleshooting Troubleshooting Phenomena Possible Causes No Indicator Light/ Improper connection with automobile adapter. Use of No indicator light/ System is off. Improper adapter connection. Problem with power source. unauthorized power supply. Power switch is on OFF Picture No picture position. Brightness/contrast adjusted incorrectly. -
Page 30: Warranty & Disclaimer
OTHERS OR THE UNAUTHORIZED USE OF NONCONFORMING PARTS; THE DAMAGE IS DUE TO NORMAL WEAR AND TEAR, THIS DAMAGE IS DUE TO ABUSE, IMPROPER MAINTENANCE, NEGLECT OR ACCIDENT; OR THE DAMAGE IS DUE TO USE OF THE REAR VIEW SAFETY, INC. SYSTEM AFTER PARTIAL FAILURE OR USE WITH IMPROPER ACCESSORIES. - Page 31 FOR ANY INJURY, LOSS OR DAMAGE, INCIDENTAL OR CONSEQUENTIAL, ARISING OUT OF THE USE OR INTENDED USE OF THE PRODUCT. IN NO EVENT SHALL REAR VIEW SAFETY AND/OR ITS AFFILIATES HAVE ANY LIABILITY FOR ANY LOSSES (WHETHER DIRECT OR INDIRECT, IN...
- Page 32 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. Rear View Safety...
