- Page 1 A S a f e F l e e t B r a n d Product Manual InstalIation Instructions Backup Camera System with License Plate Camera and 3.5" Display RVS-778607 © 2016 Rear View Safety Inc.
-
Page 2: Product Info
Product Info IMPORTANT NOTICE Please read this manual before installation. Monitor TV System NTSC Congratulations on After reading this manual Effective Pixel 628X586 pixels 656X462 pixels your purchase of a Rear you will be able to properly Electronic Shutter 1/50-1/100,000 sec 1/60-1/100,000 sec View Safety Backup install and operate this... -
Page 3: Product Includes
MT9V136 camera with night vision and all the wires, connectors and mounts you will need. The system is weatherproof, strong and reliable, shock resistant and comes with a full year warranty. Rear View Safety Inc. We reserve the right to change or modify product specifications or measurements without notice... - Page 4 Product Info Camera Camera MT9V136 Effective Pixels 668x576/668x512 TV System PAL/NTSC TV Lines Viewing angle 170° Weatherproof Rating IP68 Night Vision Usable Illumination 0.5 Lux Power Source DC 12V-24V (+/- 10%) S/N Ratio 48dB Electronic Iris 1/50, 160-1/100,000 sec Video Output 1Vp-p 75 Ω...
- Page 5 Product Info Monitor TV System NTSC Effective Pixel 628X586 pixels 656X462 pixels Electronic Shutter 1/50-1/100,000 sec 1/60-1/100,000 sec Scanning System 2:1 Interlace Sync System Internal Resolution 420 TV Lines Lens Angle 2.8mm/120 - 1.8mm/710 Sensor Area 5.961mm X 4.276mm Video Output 1.0Vp-p 75 Ohm S/N Ratio More than 48db...
-
Page 6: Installation
Installation Camera Video (in) Power (in) -12V To automatically have the camera & monitor turn ON when the vehicle is turned on, simply connect the red power line 12V+ to ignition power which can be an accessory switch/fuse line & connect the black power line to ground. -
Page 7: Troubleshooting
Troubleshooting No image on screen Monitor will not power up / Verify camera is on correct camera input. • no backlight on power button Verify cable is connected to monitor. • Check fuse • Verify camera is connected to cable. •... - Page 8 firmly fixed to secure location. Do not attempt to service should be situated The rear view system is intented to be on your own. If the syste direct sun light, heat, used when the vehicle is in reverse. problem, please disconn Please take special care to the isture.
