Summary of Contents for Rear view safety RVS-950C
- Page 2 What’s in the Box? • Mount • Manual • Micro SD Card • USB cable • Car Charger (include the adapter 12V/24V transfers to 5V)
-
Page 3: Table Of Contents
Table of Contents Introduction ....................4 Functions....................5-9 Settings ....................10-13 Tips.........................14 Specifications....................15 Troubleshooting...................16-17 Warranty.......................18 Disclaimer ....................19... -
Page 4: Introduction
Thank you for purchasing Car black box (DVR) from our company. In order to help you operate it correctly, please read this instruc- tion carefully before using. We hope this product can satisfy your demand and can provide long-time service to you. ReaR VIeW SaFeTy... -
Page 5: Functions
Functions Product pictures and function: 9. Down button 10. Power / Mode button 1. Lens 11. Work (blue light), charging 2. Night vision lights (red light) and video (blue light) 3. Bracket indicator 4. Speaker 12. 2.0 inch display 5. LCD screen interface 13. - Page 6 Charging way: 1) Connect with car charger, 2) Connect USB cable to a computer for charge. Red indicator light will brighten during charging, will be off after battery is full. The battery icon on the screen will become charging icon. ReaR VIeW SaFeTy...
- Page 7 Functions B) Car charger after the vehicle is started, the device will automatically enter the recording mode, it can be charged while recording. after car power off, the device will shutdown in 10 seconds and save the files auto- matically. you also can manually turn off the camera, the recorded files will be saved automatically.
- Page 8 PC CaMeRa mode Focus function: Under the camera or record mode, press UP/DOWN key, then the screen will show the icon of FOCUS zoom, and press UP/DOWN to choose the Zoom multiple (1-4 ). ReaR VIeW SaFeTy...
-
Page 9: Functions
Functions ABOUT / HDMI output test: after power on, please connect DVR to LeD TV by a/V cable or HDMI cable, then the device will automatically switch to playback mode; Meantime, the DVR's screen don't show anything, only TV shows menu operation. -
Page 10: Settings
Press Up/Down buttons to select the listed settings, press OK button to enter the set function parameter interface, and then press Up / Down buttons to select specific pa- rameters, press the OK button to exit. ReaR VIeW SaFeTy... - Page 11 Settings 1) Capture mode: single shoot 2 seconds pacemaker 5 seconds pacemaker 10 seconds pacemaker 2) Resolution: 12M （4032*3024） 10M （3648*2736） 8M （3264*2448） 5M （2592*1944）3M （2048*1536）2M HD（1920*1080） VGa（640*480） 1.3M （1280*960） 3) Continuous shooting: Off/ On 4) Image quality: High, Medium, economy 5) Sharpness: Strong /Standard/ Soft 6) White Balance: auto/ Daylight/ Cloudy/ Tungsten/ Fluorescent...
- Page 12 2) Auto power off: off, 3 minutes, 5 minutes, 10 minutes 3) Key tone: Off / On 4) Language: english / Simplified Chinese / Traditional Chinese / Japanese / Russian / French / German / Italian / Spanish / Portuguese 5) Frequency: 50HZ 60HZ ReaR VIeW SaFeTy...
- Page 13 Settings 6) Screen saver: off, 3 minute, 5 minutes, 10minutes. 7) IR LED: Off/ On 8) Imagine rotation : On/ Off 9) Car plate: aaaaaaa 10) Format: SD card（Select SD card, press OK button to enter, press Up/Down button to select Cancel/Ok again, then press OK but- ton to exit.）...
-
Page 14: Tips
“Low Battery”. at this time, please charge the de- vice. Otherwise the device will automatically save files and turn off in 2 seconds. 7. When you need to reset the device, press the ReSeT button, DVR will automatically. ReaR VIeW SaFeTy... -
Page 15: Specifications
Specifications Zoom 4 X digital zoom Display 2.0 inch TFT screen Video Output aV (CVBS); Composite TV Photo PG format, Max: 4032x3024 Video H.264 compressed format Built in MIcrophone and Speaker audio (aaC) Memory Card Memory Card: 32M ROM; Support SDHC TF Card up to 32GB HDMI Support Motion Detection... -
Page 16: Troubleshooting
In the case of lower battery, fill light can’t be enabled. * The image is with horizontal stripes interference. Due to set the wrong light frequency, please set as "50Hz" or "60Hz" according to the local power supply frequency. ReaR VIeW SaFeTy... - Page 17 Troubleshooting * When screen saver, pressing POWER button can not wake up the screen Because POWeR button is for night lamp On/Off shortcut button at this time, you can not simultaneously achieve two functions, so pressing POWeR button can not wake up the screen. But pressing any other buttons can wake up the screen.
-
Page 18: Warranty
Rear View Safety, Inc. system after partial failure or use with im- proper accessories. -
Page 19: Disclaimer
Neither shall Rear View Safety and/or its affiliates have any re- sponsibility for any decision, action or inaction taken by any person in re- liance on Rear View Safety systems, or for any delays, inaccuracies and/or errors in connection with our systems functions. - Page 20 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 atlantic avenue Brooklyn, Ny 11233 800.764.1028 BeTTeR CaMeRaS. BeTTeR SeRVICe. IT’S OUR GUaRaNTee.
