- Page 1 Instruction Manual Hidden Dash Camera with WiFi RVS-880C RVS Systems© 2016 Reverse With Confidence ™...
-
Page 2: Table Of Contents
Products Specifications......10 Trouble shooting......11 Rear View Safety... -
Page 3: Button Control
Installation 1. Power off vehicle. 2. Insert TF card into the card slot. User must use high-speed TF card, Class10 above. 8GB maximum/32 GB maximum. 3. The red wire connects to the ACC power, the yellow cable con- nects to 12V+, and black cable connected to GND power. Yellow AV video cable connected to DVD navigation’s AV input. -
Page 4: Button And Interface Function Description
Standby/Video Mode: Short press opens Wifi, long press moves to time settings menu. At time setting menu, short press to toggle time down. Playback Mode: Short Press to toggle to next video. When WiFi is on a short press closes WiFi. Rear View Safety... - Page 5 Reset In the event of a camera failture, short press to restart machine. Indicator Light WiFi Off/Standby Mode: Blue light off, red light on WiFi Off/Recording Mode: Red light flashing WiFi Off/Standby Mode: Blue light on, red light off WiFi On/Recording Mode: Blue light flashing Automatic Recording When the vehicle turns on, recording will automatically begin.
-
Page 6: Special Function Description
Long press on “power on/off” button to start, Indicator light will shine when power on Then long press again “power on/off” button to shutdown and the indicator light go out Notice: camera will automatically power off when battery reaches critical level. Rear View Safety... - Page 7 • REC mode Short press on “M” button shift to REC mode, REC icon is on the top left corner Short press on “OK” mode to start recording, flashing red dot on REC icon indicates the recording is underway. • Photo mode Short press on “M”...
- Page 8 • USB mode Separate USB cable and computer, press “power on” button, car DVR will auto matically show USB menu, two mode are available: 1)USB-Disk In this mode we can access video files and photo files 2)PC-Camera Rear View Safety...
-
Page 9: Battery Instruction
Battery Instruction • Battery indication image: Full battery slightly low battery low battery battery empty There are three methods to charge, and the red indicator will light up when charging, a full charge will take about 180 minutes, and the red indicator light will automatically turn off when the charging is completed. -
Page 10: Products Specifications
5million Photo format JPEG Memory card TF (max 32GB) Support Built-in stereo Support Infrared night vision Support Video output AV-OUT/HDMI Video format PAL/NTSC Current frequency 50HZ/60HZ USB function 1:USB-Disk 2:PC-Camera Power interface 5V 800ma Battery Built-in 200mAh Rear View Safety... -
Page 11: Trouble Shooting
Trouble shooting: For problems in normal operating situation ,please try these methods below: • Can’t take photo and recording Check if the SD card has enough space or locked • Automatically stop when recording Use the compatible high-speed TF card with SDHC because of big HD video data, the high- speed TF card have identifying of C4 and C6 •... - Page 12 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 Better Cameras. Better Service. IT’S OUR GUARANTEE. Rear View Safety...
