MULTIQUIP MAYCO LS400 Operation And Parts Manual page 138

MANIFOLD ASSY.
NO. PART NO. PART NAME
1 EM963102 BOLT 1/2 X 1-1/4 IN. ................................................ 4 .......... REPLACES 492393
2 6109180 WASHER, LOCK 1/2 IN. ...........................................
3 EM98261 MANIFOLD ASSY COMPLETE ............................... 1 .......... REPLACES EM98109
............................................................................................... INCLUDES ITEMS W/ %
4% EM98220 CYCLING VALVE, SWING W/PILOTS ...................... 1 .......... INCLUDES ITEMS W/ #
5# EMBK227 BOLT, SHCS 1/2" x 2-1/4"
6# EM98223 PILOT VALVE, SHUTTLE
7# EMBK2097 BOLT, SHCS 1/2" X 1-1/4"
8 EM98221 CYCLING VALVE, MAIN ........................................... 1 .......... INCLUDES ITEM W/ &
9& EM98222 PILOT VALVE, MAIN CYLINDER
10% EM98227 CHECK VALVE
12% EM98228 COIL, 12VDC ACCUMULATOR
12A% EM98229 ACCUMULATOR UNLOADER CARTRIDGE ASSY 1
13 EM25498 ADAPTER
14 EM509401 ADAPTER
15 EM514488 ADAPTER
16 EM25459 ADAPTER
17 EM98226 UNLOADING RELIEF VALVE, SHUTTLE
18 EM514231 ADAPTER
19 EM514489 ADAPTER
20 EM491372 ADAPTER
21 506193 ADAPTER
22 EM25462 ADAPTER
23 EM509353 ADAPTER
24 EM25429 ADAPTER
25 TBD CHECK VALVE
MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 137
LS400/LS500 PUMP — MANIFOLD ASSY.
QTY.
4 .......... REPLACES
12
1
8
1
1
1
1
3
1
2
1
2
2
1
1
2
3
1
1
REMARKS
492626
