MULTIQUIP MAYCO LS400 Operation And Parts Manual page 136

HYDRAULIC PUMP ASSY.
NO. PART NO.
1 TBD
*
2 EM514719
3 EM492444
4 6109180
5 EM514718
6 EM515207
7 EM514623
8 EM514627
9 EM514628
10 EM510902
11 6109180
12%
13 EM98128
14 EM510902
16 EM517674
16 EM98256
17 EM98273
18 EM506953
19 EM16190
20 EM98107
21 EM963610
22 0166 A
23 EM25498
24 EM25429
25 EM514599
25 EM516875
26 EM25429
27 EM491372
29 EM25498
30 EM16524
31 506200
32 EM514601
33 EM517649
34 EM517038
35 EM509353
36$ TBD
37 EM514608
39 EM25459
40 EM25429
MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 135
PART NAME
O-RING
FLANGE, SUCTION PIPE .......................................... 2 ............ INCLUDES ITEMS W/
BOLT 1/2 X 1-1/4 IN.
WASHER, LOCK 1/2 IN. .............................................. 6 ............ REPLACES 492626
SUCTION PIPE ADAPTER, 40 SPECIAL
CLAMP 2 IN. ................................................................ 2
HOSE, SUCTION 2 IN.
ADAPTER, SUCTION PIPE 32
FLANGE, SUCTION PIPE .......................................... 1 ............ INCLUDES ITEMS W/%
BOLT 1/2 X 1-1/2 IN.
WASHER, LOCK 1/2 IN. .............................................. 4 ............ REPLACES 492626
O-RING
COUPLER, ENGINE ASSY.
BOLT 1/2 X 1-1/2 IN.
PUMP, MAIN 60CC, PARKER P1-60 SERIES ............ 1 ............ USED ON LS400 ONLY
PUMP, MAIN 75CC, PARKER P1-75 SERIES ............ 1 ............ USED ON LS500 ONLY
FLOW CONTROL VALVE
BOLT 7/16 X 3 IN.
GASKET
PUMP, SECONDARY
BOLT 3/8 X 1 IN. .......................................................... 2 ............ REPLACES 492375
WASHER, LOCK 3/8 IN. .............................................. 2 ............ REPLACES 492624
STRAIGHT ADAPTER
ELBOW ADAPTER
HOSE, 4000 PSI SENSOR ......................................... 1 ............ USED ON LS400 ONLY
HOSE, 4000 PSI SENSOR ......................................... 1 ............ USED ON LS500 ONLY
ELBOW ADAPTER
STRAIGHT ADAPTER
STRAIGHT ADAPTER
ELBOW ADAPTER 90° MALE
ELBOW ADAPTER
HOSE 2000 PSI, REMIX VALVE
MOTORIZED FLOW CONTROL MANIFOLD ASSY. 1
HOSE, MAIN MANIFOLD
ELBOW
VALVE, MAIN RELIEF
HOSE
ELBOW
ELBOW ADAPTER
LS400/LS500 PUMP — HYD. PUMP ASSY.
QTY.
1
4
1
1
1
4
1
1
2
1
4
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
REMARKS
*
