MULTIQUIP MAYCO LS400 Operation And Parts Manual page 132

THROTTLE ASSY.
NO. PART NO.
1 510792
2 492356
3 EM167
4 EM923057
5 2101402
6 EM16465
7 EM98233
*
8 EM98228
*
9 EM98232
*
10 EM25429
11 EM25511
12 EM25576
13 EM50449
14 EM25504
15 EM50463
16 EM50449
17 EM50462
18 EM50449
19 EMCC700
20 492581
21 515812
22 513213
23 EM501102
24 EM491089
25 510229
26 492366
27 2105164
28 EM98168
MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 131
PART NAME
SUPPORT
BOLT 1/4' X 3/4 IN.
BOLT 1/4 X 1-3/4 IN.
LOCK WASHER 1/4 IN. ..................................... 4 .............. REPLACES 492596
WASHER 1/4 IN. ............................................... 4 .............. REPLACES 492622
PISTON SPACER
BLOCK
COIL, 12V
VALVE
ELBOW ADAPTER 90° MALE
STRAIGHT ADAPTER
HOSE 20 IN.
ELBOW ADAPTER 90° MALE
ELBOW ADAPTER 90° MALE
HOSE 17-1/2 IN.
ELBOW ADAPTER 90° MALE
HOSE 10 IN.
ELBOW ADAPTER 90° MALE
HYDRAULIC CYLINDER
NUT, HEX 1/4 IN.
THROTLE CONTROL PLATE
THROTTLE CABLE GUIDE
SLEEVE, THROTTLE
BOLT 8 X 1/4 IN.
CABLE, THROTTLE
BOLT 5/16 X 1-1/2 IN.
HEX NUT 5/16 IN. ............................................. 1 .............. REPLACES 492553
THROTTLE BLOCK ASSY. ............................... 1 ..............
LS400/LS500 PUMP — THROTTLE ASSY.
QTY.
1
3
4
2
1
1
1
3
1
2
1
1
1
1
1
1
1
2
1
1
1
1
1
1
REMARKS
INCLUDES ITEMS W/
*
