Kathrein 742270V03 Quick Start Manual

6-Port Antenna
Frequency Range
Dual Polarization
HPBW
Adjust. Electr. DT
set by hand or by optional RCU (Remote Control Unit)
6-Port Antenna 790–960/1710–1880/1920–2170 65°/65°/65° 15/17/17dBi 0°–14°/0°–8°/0°–8°T
Type No.
Low band
Frequency Range MHz
Gain at mid Tilt dBi
Gain over all Tilts dBi
Horizontal Pattern:
Azimuth Beamwidth
Front-to-Back Ratio,
dB
Total Power, ± 30°
Cross Polar Discrimination
dB
at Boresight
Cross Polar Discrimination
dB
over Sector
Azimuth Beam
dB
Port-to-Port Tracking
Vertical Pattern:
Elevation Beamwidth
Electrical Downtilt
continuously adjustable
Tilt Accuracy
First Upper Side Lobe
dB
Suppression
Cross Polar Isolation dB
Port to Port Isolation dB
Max. Effective Power
per Port
Max. Effective Power
Port 1–2
Values based on NGMN-P-BASTA (version 9.6) requirements.
Kathrein USA Greenway Plaza II, 2400 Lakeside Blvd., Suite 650, Richardson TX 75082
R1 R1 B1 B1
790–960 1710–1880
X X
65° 65°
0°–14° 0°–8°
790 – 862
14.3
14.3 ± 0.2
° 69 ± 1.0
> 25
> 24
> 13.5
< 1.0
° 16.8 ± 0.5
°
° < 0.6
> 15
W 300 (at 50 °C ambient temperature)
W 600 (at 50 °C ambient temperature)
All specifications are subject to change without notice.
The latest specifications are available at www.kathreinusa.com
Phone: 214.238.8800 Fax: 214.238.8801
B2 B2
1920–2170
X
65°
0°–8°
742270
V03
R1, connector 1– 2 R1, connector 1– 2
790–960
824 – 894
14.5
14.4 ± 0.3
68 ± 1.6
> 26
> 25
> 13.0
< 1.0
16.4 ± 0.9
0.0 – 14.0
< 0.5
> 17
> 30
> 45 (R1 // B1 // B2)
Email: info@kathrein.com
880 – 960
14.6
14.6 ± 0.3
67 ± 1.0
> 27
> 26
> 12.5
< 1.5
15.6 ± 0.9
< 0.7
> 18
742270 Page 1 of 4
V03
